- Page 1 SRL-6005 PAR LAMP USER MANUAL...
- Page 2 SRL-6005 PAR LAMP Table of Contents Introduction-------------------------------------------------------------------------------------------------3 Specification------------------------------------------------------------------------------------------------3 Safety Information----------------------------------------------------------------------------------------3 Installation--------------------------------------------------------------------------------------------------4 Operation---------------------------------------------------------------------------------------------------4 Rear Panel----------------------------------------------------------------------------------------4 Fuse Replacement------------------------------------------------------------------------------4 DMX Mode----------------------------------------------------------------------------------------5 Auto Mode----------------------------------------------------------------------------------------7...
-
Page 3: Safety Information
SRL-6005 PAR LAMP Introduction Thank you for purchasing SRL-6005 LED PAR. This product is featured with balanced mix of RGB LED, and operated via DMX, and AUTO. It will provide you splendid vision enjoyment. Specification Voltage Input： 220V/50Hz Power：50W LED: 196PCS LED Φ5 Fuse: 2A/250V Weight：2.8Kg... -
Page 4: Rear Panel
SRL-6005 PAR LAMP Installation SRL-6005 comes equipped with a yoke for hanging installations. The yoke will provide for a static mount or installation. It is important never to obstruct the fan or vents pathway. Mount the fixture using the safety hook. Adjust the angle of the fixture by loosening both knobs and tilting the fixture. -
Page 5: Dmx Mode
SRL-6005 PAR LAMP DMX Mode 1. DMX Setting and DMX Value Operating in a DMX Control mode environment gives the user the greatest flexibility when it comes to customizing or creating a show. In this mode you will be able to control each individual trait of the fixture independently. -
Page 6: Auto Mode
SRL-6005 PAR LAMP E. DMX mode enables the use of a universal DMX controller device. Each fixture requires a "start address" from 1 to 511. A fixture requiring one or more channels for control begin to read the data on the channel indicated by the start address.
