Meg Stoves 4.5 Pod Instructions And Installation Manual

Meg Solid Fuel Stoves Manual Version 1.2. Issued 18/02/2014
Meg 4.5 Pod / Sirius 450 Qube
Glass-Fronted Contemporary
Solid Fuel Heating Stove
This document is to be left with the householder after installation.
All Meg stoves exceed the safety and performance requirements of European Standards.
Independently tested by SGS (Notified Laboratory No: 0608) in 2013.
Intermittent burning solid fuel roomheaters for installation with a single dedicated
chimney.
Fuel
Test Standard
Test Cycle
Settings
Flue Draft Pa (ins WG)
Efficiency %
Recommended Rating kW
Mean Flue Gas Temp Rise °K
Minimum air entry requirement
Minimum clearance to
combustibles
Hearth
Weight
Flue outlet size
Emissions as if O2 = 13%
Nox mg/mᶟ
CO %
CxHy mg/m²
Gas Flow g/sec
Smoke emission mg/mᶟ
Smoke emission g/hr
This stove must be installed and commissioned by a fully qualified registered engineer, or the building inspector must be informed. For more details contact your local
authority.
This document, when completed by the installer, constitutes part of a 'Hearth Notice' for purposes of Building Law. It must be left with the householder and placed
where it can easily be found.
Installed at Location: ....................................................................................................
I definitively assert that this installation is safe, has been lit and demonstrated to the householder, conforms with current building regulations and with these
instructions.
Signed:............................................................................................................................. Date:.......................................................................................................................
Flue Draught measured on commissioning: .....................................................................
Fuel used on commissioning:...........................................................................................
Installers; Please return the transit skids to the retailer so they can be returned to the manufacturer for re-use.
The Clean Air Act 1993 and Smoke Control Areas
Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area. It is an offence to emit smoke from a chimney of a building, from a furnace or from any fixed
boiler if located in a designated smoke control area. It is also an offence to acquire an "unauthorised fuel" for use within a smoke control area unless it is used in an "exempt" appliance ("exempted" from the controls which
generally apply in the smoke control area).
The Secretary of State for Environment, Food and Rural Affairs has powers under the Act to authorise smokeless fuels or exempt appliances for use in smoke control areas in England. In Scotland and Wales this power rests with
Ministers in the devolved administrations for those countries. Separate legislation, the Clean Air (Northern Ireland) Order 1981, applies in Northern Ireland. Therefore it is a requirement that fuels burnt or obtained for use in
smoke control areas have been "authorised" in Regulations and that appliances used to burn solid fuel in those areas (other than "authorised" fuels) have been exempted by an Order made and signed by the Secretary of State
or Minister in the devolved administrations.
Further information on the requirements of the Clean Air Act can be found here: http://smokecontrol.defra.gov.uk/
Your local authority is responsible for implementing the Clean Air Act 1993 including designation and supervision of smoke control areas and you can contact them for details of Clean Air Act requirements
The Meg 7.5 / Sirius 750 and Meg 4.5 / Sirius 450 stoves may be used in smoke control areas strictly in accordance with these instructions, when burning:
UK: Untreated wood logs, natural anthracite or authorised smokeless fuels (authorised under s20(6) of the clean air act 1993)
RoI: Wood logs, smokeless fuels or peat briquettes, but not petroleum coke (Control of Atmospheric Pollution Regulations 1970)
Wood (Beech)
EN 13240:2001 + A2 2004
0.98kg over 0.76hrs
Primary 0%, 2
12 (0.05)
84.0
4.5
192
2500 mm²
105
0.23
231
4.1
89
1.98
Read these instructions! Use only recommended fuels!
Meg 4.5 Pod / Sirius 450 Qube
nd
0%
300mm at sides 600mm at rear
Not suitable for a light duty hearth
55 kg
125 mm
By:........................................................................................................................
4.5 Pod / 450 Qube
Mineral Fuel (Anthracite)
EN 13240:2001 + A2 2004
0.9kg over 1hr
nd
Primary 50%, 2 0%
12 (0.05)
80.0
4.5
294
2500 mm²
0.16
3.7
32
