Goodman GMS95 Installation Instructions Manual

Goodman GMS95 Installation Instructions Manual

Goodman gms95 gas-fired warm air furnace
Hide thumbs Also See for GMS95:
Table of Contents

Advertisement

Quick Links

G
(Type FSP CATEGORY IV Direct or Non Direct Vent Air Furnace)
ATTENTION INSTALLING PERSONNEL
As a professional installer you have an obligation to know the product better than the customer. This includes all safety
Prior to actual installation, thoroughly familiarize yourself with this Instruction Manual. Pay special attention to all safety
warnings. Often during installation or repair it is possible to place yourself in a position which is more hazardous than
Remember, it is your responsibility to install the product safely and to know it well enough to be able to instruct a customer
Safety is a matter of common sense...a matter of thinking before acting. Most dealers have a list of specific good safety
The precautions listed in this Installation Manual are intended as supplemental to existing practices. However, if there is
a direct conflict between existing practices and the content of this manual, the precautions listed here take precedence.
IO-277C
GMS95
-F
W
AS
IRED
I
NSTALLATION
Installer: Affix all manuals adjacent to the unit.
These furnaces comply with requirements
embodied in the American National Stan-
dard / National Standard of Canada ANSI
Z21.47·CSA-2.3 Gas Fired Central Fur-
naces.
RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION.
precautions and related items.
when the unit is in operation.
*NOTE: Please contact your distributor or our
website for the applicable product data book
referred to in this manual.
Goodman Manufacturing Company, L.P.
2550 North Loop West, Suite 400, Houston, TX 77092
www.goodmanmfg.com
2005-2006 Goodman Manufacturing Company, L.P.
©
A
ARM
IR
I
NSTRUCTIONS
in its safe use.
practices...follow them.
F
URNACE
®
C
US
07/06
