  • Page 1 Service Manual SB-9015D...
  • Page 3: Liability Disclaimer

    Copyrights ©2010 Logic Controls Technology Corp. All rights reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. This document contains proprietary information protected by copyright.
  • Page 4: Table Of Contents

    Contents Copyrights ....................i Liability Disclaimer ...................i Contents....................ii 1. Before You Start ...................1 2. Opening the Device................2 Mainboard side Components Replacement...........4 3. Mainboard Layout ................4 4. HDD Replacement ................9 5. LCD Inverter Replacement ..............10 6. LCD Panel Replacement..............11 Contents...
  • Page 5: Before You Start

    Before You Start 1. Please unplug the power cable before you start to work. 2. Please read and follow the instructions in this document carefully. Failure to follow these instructions could damage your device and void the warranty. 1.1. Tools Suggested All procedures in this document require the following tools: #0 Phillips screwdriver #1 Phillips screwdriver...
  • Page 6: Opening The Device

    Opening the Device 1. Loosen the screw as shown. 2. Separate the device from the base. 3. Un-tighten the four screws on the back panel anticlockwise.
  • Page 7 4. Separate the back panel from the front panel by lifting up and lay it down carefully.
  • Page 8: Mainboard Side Components Replacement

    Mainboard side Components Replacement Mainboard Layout For relative location of onboard connectors, please refer to the pictures below.
  • Page 9 1. Open the two ejectors on the slot by pushing them, and remove the RAM from the slot. 2. Align and insert the new RAM into the slot and push both ends of the RAM down until the ejectors snap into place. 3.
  • Page 10 Disconnect: 1. Parallel port cable and 2. Touch panel cable. 6. Loosen the two screws by 1.5 mm hexagon socket spanner as shown below. 7. Loosen the four screws fixing the mainboard.
  • Page 11 8. Remove the mainboard. 9. Loosen the four screws by 1.5 mm hexagon socket spanner as shown below, and then you can remove the VGA port cable and the parallel port cable. 10. Loosen the two screws as shown and remove the IO bracket. Chapter 3...
  • Page 12 11. Remove the power switch.
  • Page 13: Hdd Replacement

    HDD Replacement 1. Loosen the four screws by #1 Phillips screwdriver and Unplug the SATA cable and power cable from the HDD, then you can remove the HDD assembly. 2. Loosen the four screws fixing the HDD on the both side, and then you can remove the HDD.
  • Page 14: Lcd Inverter Replacement

    LCD Inverter Replacement 1. Disconnect three connecters shown below. 2. Disconnect three connecters and three screws from LCD inverter as shown below, and then you can remove the LCD inverter. 3. Install the new LCD inverter in the reverse procedure.
  • Page 15: Lcd Panel Replacement

    LCD Panel Replacement 1. Unplug the LED indicator. 2. Disconnect the touch panel cable. 3. Loosen the two screws and remove the led indicator len. 4. Remove the black tape and then disconnect the LCD cable.
  • Page 16 5. Loosen the six screws as shown and remove the LCD assembly from the front bezel. 6. Loosen the four screws as shown, and then you can remove the LCD from the LCD chassis.
