BENADO EFFECTS PB1 User Manual

Thank you for purchasing the BENADO EFFECTS pedalboard. Owning this unit will give you
the ability to free yourself from clutter, weight and many other frustrations we guitar players have
suffered for years without losing the quality of sound and build.
On this pedalboard there are five basic effects that most guitar players use, and the effects are
all analog. How cool is that? Oh, not to mention it's already buffered on the input level, so
you can look at it as six pedals in your board. Every pedal was carefully designed to be the best
and achieve a complete purity of the sound without diminishing your tone one little bit.
A brief description of the effects is as follows: Compressor (can act as a clean boost if needed),
Distortion gives you that vintage warm great raw tube amp sound, Overdrive with wide range of
options, Analog Delay and Spring Style Reverb.
Below I'm including my favorite settings, which I'm using almost exclusively:
• Compressor: all knobs set to 12:00 o'clock. (level knob changes from time to time to set
volume right). This setting I'm using as my boost.
• Distortion:
o'clock, gain 1:00 o'clock.
• OD: tone 1:00 o'clock, bass 11:00 o'clock, switch set to cream, volume 10:00-11:00
o'clock, gain 8:00-9:00 o'clock.
• Delay: delay all the way up, tone all the way down, repeats 9:00-10:00 o'clock, level set
to bring the overall sound to match my reverb so I get an echo type of sound.
• Reverb: tone 12:00 o'clock, level 10:00-11:00 o'clock, depth 12:00 o'clock.
Do not use an adaptor with a higher output voltage than the specified 9V
DC center pin negative. An adapter with an AC voltage output should
never be used with the unit as it will permanently damage the unit.
I recommend using the Visual Sound 1 Spot 9V DC Power Supply.
Warranty
Warranty is in effect for 2 years from day of purchase. Repairs during this time
will be free of charge due to manufacturing defect and not caused by the end
user. Upon receiving the unit, warranty repairs will be granted pending inspection
of the unit. (There is a 7 day, no questions asked return policy, beginning on the
date you receive your pedalboard. The cost of shipping will be at your expense,
and any damages caused by end user will be deducted from the refund. Units
purchased from a dealer do not qualify for this 7-day no questions asked policy.
If you purchased your pedalboard from a dealer contact them for store warranty
policies). Any unauthorized modifications to the pedalboard will void your
warranty. Any damage caused by using the incorrect adapters mentioned above
will void your warranty.
You must register your board to validate the warranty on the website.
BENADO EFFECTS
treble all the way up, mids 3/4 way up, bass 10-12 o'clock, volume 10
