Federal Series - User's Manual

DVR-FE032960-DH

PTZ

960H

Control

View From

Motion

Anywhere

Resolution

Activated

Warranty

Recording

Table of Contents

Need help?

Do you have a question about the Federal Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Techpro Federal Series

Page 1 Federal Series - User's Manual DVR-FE032960-DH 960H Control View From Motion Anywhere Resolution Activated Warranty Recording...
Page 2: Table Of Contents
Table of Contents FEATURES AND SPECIFICATIONS ............1 Overview ..........................1 Features ..........................1 Specifications ........................2 DVR-FE032960-DH Series 1.3.3 ..................10 OVERVIEW AND CONTROLS ............... 15 Front Panel ........................15 DVR-FE032960-DH Series 2.1.2 ..................16 Rear Panel ........................19 DVR-FE032960-DH Series 2.2.3 ..................
Page 3 INSTALLATION AND CONNECTIONS ..........31 Check Unpacked DVR ..................... 31 About Front Panel and Rear Panel ................. 31 3.2.1 HDD Installation ......................31 3.2.2 Rack Installation ......................33 Connecting Power Supply ....................33 Connecting Video Input and Output Devices ..............33 3.4.1 Connecting Video Input ....................
Page 4 Startup Wizard ........................41 Manual Record ......................... 44 4.3.1 Live Viewing ......................... 44 Right-Click Menu ......................46 4.4.1 Window Switch ......................46 4.4.2 PIP ..........................47 4.4.3 PTZ Control ........................48 4.4.4 Auto Focus ........................54 4.4.5 Color ..........................54 4.4.6 Search ..........................
Page 5 4.8.1 Search .......................... 62 4.8.2 Backup .......................... 69 4.8.3 Shut Down ........................72 Information ........................72 4.9.1 System Info ........................72 4.9.2 Event..........................76 4.9.3 Network ........................76 4.9.4 Log ..........................79 4.10 Setting ..........................81 4.10.1 Camera ........................81 4.10.2 Network ........................
Page 6 5.8.1 Camera ........................169 5.8.2 Network ........................177 5.8.3 Event........................... 192 5.8.4 Storage ........................202 5.8.5 Setting ........................207 Information ........................223 5.9.1 Version ........................223 5.9.2 Log ..........................223 5.9.3 Connection Log ......................224 5.9.4 Online User ........................ 225 5.10 Playback .........................
Page 7 Appendix B-4 Compatible USB DVD List ................242 Appendix B-5 Compatible SATA DVD List ................242 Appendix B-6 Compatible SATA HDD List ................243 APPENDIX C COMPATIBLE CD/DVD BURNER LIST ......247 APPENDIX D COMPATIBLE DISPLAYER LIST ........248 APPENDIX E COMPATIBLE SWITCHER ........... 249 APPENDIX F COMPATIBLE WIRELESS MOUSE LIST ......
Page 8 Welcome Thank you for purchasing our DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series hybrid standalone DVR features and functions. Before installation and operation please read the following safeguards and warnings carefully!
Page 9: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electric shock caused by improper handling or installation.
Page 10: Features And Specifications
FEATURES AND SPECIFICATIONS 1.1 Overview The hybrid standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detailed analysis.
Page 11: Specifications
Client-end user can download the file to local HDD to backup via network. Support eSATA, SATA port backup (eSATA port can connect to burner or HDD, SATA port can connect to burner.)  Record & playback function Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc.
Page 12: Dvr-Fe032960-Dh Series
DVR-FE032960-DH Series 1.3.3 32-ch Series Parameter Main High-performance industrial embedded micro controller System Processor Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices Front panel, USB mouse, remote control Arabic number, English character, donation and extension Chinese Input Method (optional)
Page 13 Privacy mask Support one privacy mask of user-defined size in full screen. Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video. Channel Lock Cover secret channel with black screen though system is encoding normally.
Page 14 function Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.) Support peripheral eSATA backup device. Support network download and save View monitor channel remotely. DVR configuration through client-end and web browser Upgrade via client or browser to realize remote maintenance. Network View alarm information such as external alarm, motion detection and Function...
Page 15 On-line user Display current on-line user User Multi-lever user management; various management modes Management Integrated management for local user, serial port user and network User user. Configurable user power. Management Support user /group and its corresponding rights modification. No limit to the user or group amount. Password modification Administrator can modify other user’s password.
Page 16: Overview And Controls
2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel DVR-FE032960-DH Series 2.1.2 Name Icon Function Power button, press this button for three seconds to boot up or Power button shut down DVR.
Page 17 Go to previous menu, or cancel current operation. When playback, click it to restore real-time monitor mode. Confirm current operation Enter ENTER Go to default button Go to menu One-window monitor mode, click this button to display assistant function: PTZ control and image color. Backspace function: in numeral control or text control, press it for 1.5 seconds to delete the previous character before the cursor.
Page 18: Rear Panel
2.2 Rear Panel DVR-FE032960-DH Series 2.2.3 The 32-channel series DVR rear panel is shown as below. See Figure 2-5. Figure 2-5 Please refer to the following sheet for detailed information. Icon Name Function Ground port Power switch Power on/off button. VIDEO IN VIDEO IN Video input port...
Page 19 USB2.0 port Connect to mouse, USB storage media, USB-burner and etc. High definition HDMI1 High definition audio and video media interface signal output port. It transmits the same video signal VGA/TV. Support mouse operation. HDMI2 HD video matrix output. Support zero-channel encoding matrix output.
Page 20: Connection Sample
devices such as speed dome communication port PTZ. RS485_B.It is the cable B. You connect control devices such as speed dome PTZ. Alarm input ground end. Alarm input port ground end T+,T-, R+, R- Four-cable T+, T-: Send out cable. full-duplex 485 port.
Page 21: Remote Control
2.4 Remote Control The remote control interface is shown as in Figure 2-7. Please note remote control is not our standard accessory and it is not included in the accessory bag. Figure 2-7 Serial Number Name Function Power button Click it to boot up or shut down the device.
Page 22 In normal playback click this button to pause playback. In real-time monitor mode, click this button to enter video search menu. Reverse/pause Reverse playback pause mode, click this button to realize normal playback. In reverse playback click this button to pause playback. Esc.
Page 23: Mouse Control
2.5 Mouse Control Left click System pops up password input dialogue box if you have not logged in. mouse In real-time monitor mode, you can go to the main menu. When you have selected one menu item, left click mouse to view menu content.
Page 24: Virtual Keyboard & Front Panel
Right click In real-time monitor mode, pops up shortcut menu: one-window, mouse four-window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel. If you are in multiple-window mode, system automatically switches to the corresponding channel.
Page 25: Installation And Connections
3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.
Page 26 DVR-FE032960-DH Series 3.2.1.2 This series DVR max supports 8 SATA HDDs. Please use HDD of 7200rpm or higher. 3. Now you can see the bottom 2. Remove the HDD upper Loosen the screws of the bracket bracket upper cover. 4. Line up the HDD to the 5.
Page 27: Rack Installation
7. Unfasten the HDD power Insert the HDD power Use the special data cable to cable. cable. connect the HDD and the SATA port. Close the chassis and fix the screws to secure firmly. Important: If the HDD amount is less than four, you do not need to install the HDD bracket. When there is a bracket, please make sure the installation direction of HDDs is the same.
Page 28: Connecting Video Output
The camera shall be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc. The camera and the DVR should have the same grounding to ensure the normal operation of the camera. Guarantee stability and reliability of the transmission line BTT TB Please use high quality, sound shielded BNC.
Page 29: Alarm Input And Output Connection
3.6 Alarm Input and Output Connection Please read the followings before connecting. 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c. Alarm input needs the low level voltage signal. d.
Page 30 Figure 3-1 Figure 3-2 Figure 3-3 Please refer to the following sheet for detailed information. : 1，2，3，4，5，6， ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 7，8，9，10，11， 12，13，14，15，16 NO1 C1， The first four are four groups of normal open activation output (on/off NO2 C2，...
Page 31: Alarm Input Port
device power to cancel the alarm. +12V It is external power input. Need the peripheral equipment to provide +12V power (below 1A). Earth cable. 485 A/B 485 communication port. They are used to control devices such as decoder. T+,T-,R+,R- They are four-wire double duplex RS485 port T+ T-: output wire R+ R-: input wire 3.6.2 Alarm Input Port...
Page 32 Rating Rated switch capacity 30VDC 2A, 125VAC 1A （Resistance Maximum switch power 125VA 160W Load） Maximum switch voltage 250VAC, 220VDC Maximum switch currency Insulation Between touches with same 1000VAC 1minute polarity 1000VAC 1minute Between touches with different polarity Between touch and winding 1000VAC 1minute Between touches with same Surge voltage...
Page 33: Other Interfaces
Figure 3-5 485 Port Figure 3-6 Figure 3-7 485 Port 3.8 Other Interfaces There are still other interfaces on the DVR, such as USB ports.
Page 34: Overview Of Navigation And Controls
4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...
Page 35: Startup Wizard
4.2 Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time.
Page 36 Note: For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Click OK button, you can go to General interface. See Figure 4-3. For detailed information, please refer to chapter 4.10.5.1.
Page 37 Figure 4-4 Click Next button, you can go to Schedule interface. See Figure 4-5. For detailed information, please refer to chapter 4.10.4.1.1. Figure 4-5 Click Finish button, system pops up a dialogue box. Click the OK button, the startup...
Page 38: Manual Record
wizard is complete. See Figure 4-6. Figure 4-6 4.3 Manual Record 4.3.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->System->General).
Page 39  Support digital zoom function.  Support real-time backup function. You can follow the contents listed below for the operation instruction. Preview control interface Move you mouse to the top centre of the video of current channel, you can see system pops up the preview control interface.
Page 40: Right-Click Menu
Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device. System can not backup the video of multiple-channel at the same time. Click button , system begins recording.
Page 41: Pip
Figure 4-11 4.4.2 PIP It is to realize picture in picture function in 1-window mode. The small window supports instance playback, digital zoom and etc.  Window switch: Double click the small window, you can switch the position of the large window and the small window.
Page 42: Ptz Control
Figure 4-12 Figure 4-13 Go to the 1-winode mode, on the navigation bar, click , you can see the video on the large window and the video from the next channel is the default video on the small window. If you have set PIP function, you can click to view the last edited PIP video.
Page 43 Please note the commend name is grey once device does not support this function. The PTZ operation is only valid in one-window mode. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc. Speed is to control PTZ movement speed.
Page 44: Ptz Function Setup
etc. See Figure 4-16. Figure 4-16 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4-14.
Page 45 Figure 4-17 Preset Setup In Figure 4-17, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-18. Click Set button and then input preset number. Click Set button to save current preset. Figure 4-18 Tour Setup In Figure 4-17, click tour button.
Page 46 Figure 4-19 Pattern Setup In Figure 4-17, click Pattern button and input pattern number. Click Begin button to start direction operation. Or you can go back to Figure 4-14 to operate zoom/focus/iris/direction operation. In Figure 4-17, click End button. Figure 4-20 Scan Setup In Figure 4-17, click Scan button.
Page 47 Figure 4-21 4.4.3.2 Call PTZ Function Call Preset In Figure 4-16, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-16, input pattern value and then click to call a pattern. Click again to stop call.
Page 48: Auto Focus
Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-22. Figure 4-22 4.4.4 Auto Focus It is to set auto focus function. Please make sure the camera supports this function. 4.4.5 Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
Page 49 Item Note periods. Effective Time Check the box here to enable this function and then set period time. The value here is to adjust the edge of the video. The value ranges from 0 to 100. The larger the value is, the clear the edge is and vice versa.
Page 50: Search
Item Note gentle. Select a color mode, the sharpness, brightness, contrast automatically switch corresponding setup. 4.4.6 Search Please refer to chapter 4.8.1 for detailed information. 4.4.7 Record Control Please refer to chapter 4.10.4.3 for detailed information. 4.4.8 Remote Device Please refer to chapter 4.10.1.1 for detailed information. 4.4.9 Manual Record Please refer to chapter 4.4.9 for detailed information.
Page 51 Figure 4-25 In Figure 4-25, click Add to favorites; you can see the following interface. See Figure 4-26 . Here you can input customized favorites name. System max supports 31-character. Click OK button, you can save current favorites name. Figure 4-26 In Figure 4-25, click Edit favorites;...
Page 52: Channel Tree
Figure 4-27 Double click a name; you can change its name. See Figure 4-28. Input a new name and then click OK button. Figure 4-28 4.5.4 Channel Tree It is to set channel setup. The interface is shown as below. See Figure 4-29.
Page 53: Tour
Figure 4-29 The one level includes 16 channels. See Figure 4-30. You can left click to select a channel on the tree and then drag it to the preview window on the left pane. Once the channel is on the preview window, the channel number on the channel tree becomes grey and it is null now (can not be selected).
Page 54: Search
4.5.8 Search Click button , system goes to search interface. Please refer to chapter 4.8.1 4.5.9 Alarm Status Click button , system goes to alarm status interface. It is to view device status and channel status. Please refer to chapter 4.10.3. 4.5.10 Channel Info Click button , system goes to the channel information setup interface.
Page 55: Usb Device Auto Pop-Up
， system goes to the USB Manager interface. It is to view USB information, Click backup and update. Please refer to chapter 4.8.2, chapter 4.9.4, chapter 4.10.5.10, and chapter 4.10.5.12 for detailed information. 4.6 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box.
Page 56: Operation
Figure 4-33 4.8 Operation 4.8.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4-34. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file...
Page 57 Figure 4-34 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
Page 58  selection In 9-window playback mode, you can switch between 1-8 and 9-16 channels.  pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels.  The time bar will change once you modify the playback mode or the channel option.
Page 59 ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward  In playback mode, click to realize various fast play modes such as fast play 1,fast play 2 and etc.
Page 60  For one device, if there is a backup in process, you can not start a new backup operation.  It is to edit the file. ●Please play the file you want to edit and then click this button when you want to edit.
Page 61 channel This function is null if there is no record file or system is in smart search process. when playback 4.8.1.1 Smart Search During the multiple-channel playback mode, double click one channel and then click the button, system begins smart search. System supports 396(22*18 PAL) and 330(22*15 NTSC) zones.
Page 62: Mark Playback
 After you searched files, system implement accurate playback once you click Play for the first time.  System does not support accurate playback for picture.  System supports synchronization playback and non-synchronous playback. The synchronization playback supports all channels and non-synchronous playback only supports accurately playback of current select channel.
Page 63: Backup
Here you can set to begin playback from previous N seconds of the mark time. Note Usually, system can playbacks previous N seconds record if there is such kind of record file. Otherwise, system playbacks from the previous X seconds when there is such as kind of record.
Page 64 Client Operation for network download backup operation. Click backup button, you can see an interface is shown as in Figure 4-39. Here is for you to view devices information. You can view backup device name and its total space and free space. The device includes CD-RW, DVD burner, USB device, flash disk, eSATA backup.
Page 65 Figure 4-40 √ before channel name. You can use Fn or cancel System only backup files with a button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.
Page 66: Shut Down
When the system completes backup, you can see a dialogue box prompting successful backup.  File format: Click the file format; you can see there are two options: DAV/ASF. The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S.
Page 67: Hdd Information
Figure 4-43 4.9.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-44.  SATA: 1-8 here means system max supports 8 HDDS (It depends on the product you purchased).
Page 68: Record Info
Figure 4-44 Double click one HDD information; you can see the HDD SMART information. See Figure 4-45. Figure 4-45 4.9.1.2 Record Info It is to view record start time and end time. See Figure 4-46.
Page 69 Figure 4-46 4.9.1.3 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-47. Figure 4-47 4.9.1.4 Version Here is for you to view some version information such as version number, built date, serial number and etc.
Page 70: Event
Figure 4-48 4.9.2 Event It is to display device status and channel status. See Figure 4-49. Figure 4-49 4.9.3 Network...
Page 71: Online Users
4.9.3.1 Online Users Here is for you to manage online users. See Figure 4-50. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
Page 72: Network Test
Figure 4-51 4.9.3.3 Network Test Network test interface is shown as in Figure 4-52.  Destination IP: Please input valid IPV4 address or domain name.  Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.
Page 73: Log
Figure 4-52 4.9.4 Log Here is for you to view system log file. System lists the following information. See Figure 4-53. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log.
Page 74: Remote Log
Figure 4-53 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-54. Figure 4-54 4.9.4.1 Remote Log In this interface, you can search the IPC log information of the corresponding channel.
Page 75: Setting
select another channel (doe not need to click Search button again), you can view remote connection log. Figure 4-55 4.10 Setting 4.10.1 Camera 4.10.1.1 Remote Device (For digital channel only) 4.10.1.1.1 Remote Device In the main menu, from Camera ->Remote, you can go to an interface shown as in Figure 4-56.
Page 76  Delete: Please select one device in the Added device list and then click remove.  Status: means connection is OK and means connection failed.  Delete；Select a device on the Added device list, click Delete button, system disconnect device first and then remove its name from the list. ...
Page 77 Figure 4-57 4.10.1.1.2 Channel Status Here you can view the IPC status of the corresponding channel such as motion detect, video loss, tampering, alarm and etc. See Figure 4-58.  IPC status: : Front-end does not support. : Front-end supports. There is alarm event from current front-end.
Page 78 Figure 4-59 4.10.1.1.4 Remote Upgrade It is to update the camera. From main menu->setting->camera->remote, the interface is shown as below. See Figure 4-60. Click Browse button and then select the upgrade file. Then select a channel (or you can select device type filter to select several devices at the same time.) Click Start upgrade button to update.
Page 79 4.10.1.2 Image The image interface is shown as below. See Figure 4-61(analog channel) and Figure 4-62(digital channel).  Channel: Select a channel from the dropdown list.  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50.
Page 80  Auto: The auto white balance is on. System can auto compensate the color temperature to make sure the vide color is proper.  Sunny: The threshold of the white balance is in the sunny mode.  Night: The threshold of the white balance is in the night mode. ...
Page 81 Figure 4-62 4.10.1.3 Encode It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.10.1.3.1 Video Video setting includes the following items. See Figure 4-63.  Channel: Select the channel you want.  Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm.
Page 82 Figure 4-63 4.10.1.3.2 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-64.  Snapshot mode: There are two modes: regular and trigger. If you set timing mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation.
Page 83 4.10.1.3.3 Overlay Overlay interface is shown as in Figure 4-65.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. ...
Page 84 Figure 4-66 4.10.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-67. Figure 4-67 4.10.1.3.5 Channel Type It is to set channel type. Each channel supports analog connection/analog HD connection/network camera connection (Slight function difference may be found). The network camera connection shall begin with the last channel.
Page 85 Figure 4-68 4.10.2 Network 4.10.2.1 TCP/IP The single network adapter interface is shown as in Figure 4-69 and the dual network adapters interface is shown as in Figure 4-70  Network Mode : Includes multiple access, fault tolerance, and load balancing ...
Page 86  Main Network Card: Please select eth0/eth1 (optional).after enable multiple access function. Note: Some series support the above three configurations and supports functions as multiple-access, fault-tolerance and load balancing.  IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them.
Page 87 Figure 4-69 Figure 4-70 4.10.2.2 Connection The connection setup interface is shown as in Figure 4-71.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777.  UDP port: Default value is 37778.
Page 88  HTTP port: Default value is 80.  HTTPS port: Default value is 443.  RTSP port: Default value is 554. Important: System needs to reboot after you changed and saved any setup of the above four ports. Please make sure the port values here do not conflict. Figure 4-71 4.10.2.3 WIFI The WIFI interface is shown as below.
Page 89 Figure 4-72  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
Page 90  AUTH: It is the authentication mode. It supports PAP/CHAP.  Dial number: Please input 3G network dialup number you got from your ISP.  User name: It is the user name for you to login the 3G network.  Password: It is the password for you to login the 3G network.
Page 91: Ddns Setup
Figure 4-74 4.10.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-75. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
Page 92 Figure 4-75 Please note NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
Page 93  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. ...
Page 94  Default: Click it to restore default setup. In this case, the trusted sites and blocked sites are both null. Note:  If you enabled trusted sites, only the IP in the trusted sites list can access the device.  If you enabled blocked sites, the IP in the blocked sites can not access the device.
Page 95  Title: Please input email subject here. System support English character and Arabic number. Max 32-digit.  Receiver: Please input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly.
Page 96 -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See Figure 4-79. Figure 4-79 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify...
Page 97 After completed channel and weekday setup, you can set two periods for one each channel. Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not. Figure 4-81 4.10.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN. Please input the router IP address in the LAN in Figure 4-69.
Page 98 Important: When you are setting the router external port, please use 1024~5000 port. Do not use well-known port 1~255 and the system port 256~1023 to avoid conflict. For the TCP and UDP, please make sure the internal port and external port are the same to guarantee the proper data transmission.
Page 99 You can set in the following interface. See Figure 4-84. Figure 4-84 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection.
Page 100 Figure 4-85 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...
Page 101: Alarm Centre
Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only. 4.10.2.13 Alarm Centre This interface is reserved for you to develop.
Page 102 Figure 4-87 2) The proxy server software developed from the SDK. Please open the software and input the global setup. Please make sure the auto connection port here is the same as the port you set in the previous step. 3) Now you can add device.
Page 103 Figure 4-88 4.10.3 Event 4.10.3.1 Detect In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-89. There are three detection types: motion detection, video loss, tampering.  The video loss has no detection region and sensitivity setup and tampering has no detection region setup.
Page 104 click ENTER button to exit current setup. Do remember click save button to save current setup. If you click ESC button to exit the region setup interface system will not save your zone setup. The analog channel supports 4 zones. For the digital channel, please make sure your network camera supports 4 zones.
Page 105  PTZ activation: Here you can set PTZ movement when an alarm occurs. Such as go to preset, tour &pattern when there is an alarm. Click “select” button, you can see an interface is shown as in Figure 4-91  Record Delay: System can delay the record for specified time after alarm ended.
Page 106 Figure 4-90 Figure 4-91...
Page 107 Figure 4-92 Figure 4-93 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.3.1.2 Video Loss In Figure 4-89, select video loss from the type list. You can see the interface is shown as in Figure 4-94.This function allows you to be informed when video loss phenomenon occurred.
Page 108 Please refer to chapter 4.10.3.1.1 motion detection for detailed information. Figure 4-94 4.10.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-95.
Page 109 Figure 4-95 4.10.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. See Figure 4-96. There are four alarm types. See Figure 4-96 to Figure 4-99. ...
Page 110  Period: Click set button, you can see an interface is shown as in Figure 4-101. There are two ways for you to set periods. There are max 6 periods in one day. There are four record types: regular, motion detection (MD), Alarm, MD & alarm. ...
Page 111 activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.  Video matrix: Check the box here to enable this function. When an alarm occurs, SPOT OUT port displays device video output. It displays video (1-window tour) from alarm activation channel you select at the Record channel item.
Page 112 Figure 4-97 Figure 4-98...
Page 113 Figure 4-99 Figure 4-100...
Page 114 Figure 4-101 Figure 4-102 4.10.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-103 and Figure 4-104.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-105.  Alarm output: Please select alarm activation output port (multiple choices). ...
Page 115  Latch: Here you can set corresponding delaying time. The value ranges from 1s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.  Show message: system can pop up the message in the local screen to alert you when alarm occurs.
Page 116 Figure 4-104 Figure 4-105...
Page 117: Alarm Output
4.10.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-106.
Page 118  : Click it to delete a record type from one period.  Record Type: Please check the box to select corresponding record type. There are four types: Regular/MD (motion detect)/Alarm/MD&Alarm.  Week day: There are eight options: ranges from Saturday to Sunday and all. ...
Page 119 Figure 4-109 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording. The white means the MD and alarm record is valid.
Page 120 Figure 4-110 Figure 4-111 4.10.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-112. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
Page 121 Figure 4-112 4.10.4.1.1.2 Redundancy Redundancy function allows you to memorize record file in several disks. When there is file damage occurred in one disk, there is a spare one in the other disk. You can use this function to maintain data reliability and safety. ...
Page 122  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as regular, size, quality and frequency. See Figure 4-114.  In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See interface on the right of Figure 4-115. Please refer to the following figure for detailed information.
Page 123 Figure 4-115 4.10.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
Page 124 Figure 4-117 Figure 4-118 4.10.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
Page 125 In the main menu, from Setting->Network->FTP, you can set FTP server information. Please enable FTP function and then click save button. See Figure 4-119. Please boot up corresponding FTP server. Please enable schedule snapshot (Chapter 4.10.4.1.2.1) or activation snapshot (Chapter 4.10.4.1.2.2) first, now system can upload the image file to the FTP server. Please input corresponding...
Page 126 Figure 4-120 4.10.4.3 Record 4.10.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu. ...
Page 127 Figure 4-121 4.10.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-122. Figure 4-122 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function.
Page 128 4.10.4.4 Advanced It is to set HDD group, and HDD group setup for main stream, sub stream and snapshot operation 4.10.4.4.1 HDD Important HDD group and quota mode can not be valid at the same time. System needs to restart once you change the mode here. The HDD group mode is shown as in Figure 4-123.
Page 129 Figure 4-124 Figure 4-125...
Page 130 Figure 4-126 4.10.4.5 Quota Here you can set channel storage capacity. See Figure 4-127. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 4-127...
Page 131: Hdd Detect
Click Quota Statistics, you can go to the following interface. You can view HDD capacity you set for each channel. See Figure 4-128. Figure 4-128 4.10.4.6 HDD Detect The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD.
Page 132 Figure 4-129 4.10.4.6.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-130. Figure 4-130...
Page 133 Click View, you can see the detailed information such as detect result, backup and S.M.A.R.T. See Figure 4-131 and Figure 4-132. Figure 4-131 Figure 4-132...
Page 134 4.10.5 System 4.10.5.1 General 4.10.5.1.1 Device General setting includes the following items. See Figure 4-133.  Device ID: Please input a corresponding device name here.  Device No: Here you can set device number.  Language: System supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional.
Page 135 Figure 4-133 4.10.5.1.2 Date and Time The interface is shown as in Figure 4-134.  Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY.  Date separator: There are three denotations to separate date: dot, beeline and solidus.  DST: Here you can set DST time and date.
Page 136 Figure 4-134 4.10.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-135. Click Add new holiday button, you can input new holiday information. See Figure 4-136. Here you can set holiday name, repeat mode and start/end time. Note  When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.
Page 137 Figure 4-135 Figure 4-136 4.10.5.2 Display 4.10.5.2.1 Display Display setup interface is shown as below. See Figure 4-137.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
Page 138  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end. You need to open web or client end to refresh channel name.
Page 139 Figure 4-138 4.10.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-139  Enable tour: Highlight box here to enable this function.  Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
Page 140  On the navigation bar, click to enable/disable tour function. Figure 4-139 4.10.5.2.4 Zero-channel Encoding Click zero-channel encoding button, you can go to the following interface. See Figure 4-140.Here you can enable and set zero-channel encoding function so that you can view several video sources at one channel.
Page 141 Figure 4-140 4.10.5.3 Video Matrix 4.10.5.3.1 BNC Here you can set matrix output channel and its interval. System supports 1/4-window (and etc) SPOT tour. See Figure 4-141.
Page 142 Figure 4-141 4.10.5.3.2 HDMI This function is for some series only. The HDMI interface is shown as in Figure 5-85. It is to set the HD video matrix output tour function of the HDMI port 2. You can set tour channel, resolution, and interval. System support 1/4-window tour.
Page 143 Figure 4-142 4.10.5.4 RS232 RS232 interface is shown as below. There are five items. See Figure 4-143.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboar d is for you to control the device via the special keyboard.
Page 144 Figure 4-143 4.10.5.5 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-144.  PTZ type: There are two options: local/remote. Please select remote if you are connecting to the network PTZ.  Protocol: Select corresponding PTZ protocol such as PELCOD. ...
Page 145 Figure 4-144 4.10.5.6 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.10.5.6.1 COM Type The COM interface is shown as below. See Figure 4-145. ...
Page 146 Figure 4-145 4.10.5.6.2 Network Type The network type interface is shown as below. See Figure 4-146. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
Page 147 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-147. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 148 Figure 4-148 Click Add button, you can add audio file and import the audio file via the USB device. See Figure 4-149. Figure 4-149 4.10.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods.
Page 149 Figure 4-150 4.10.5.8 Account Here is for you to implement account management. See Figure 4-151. Here you can:  Add new user  Modify user  Add group  Modify group  Modify password. For account management please note:  For the user account name and the user group, the string max length is 6-byte.
Page 150  About user account and MAC. When you add a new user, you can input the MAC address of current user. Only the user of the same MAC address can access the device remotely.(MAC address is for the device of the same LAN.) If you leave MAC address item in blank when you add a new user, the user of any MAC address can access the device remotely.
Page 151 4.10.5.8.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-152. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
Page 152: Auto Maintain
Click add user button, the interface is shown as in Figure 4-153. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.
Page 153: Config Backup
Figure 4-154 4.10.5.10 Config Backup The configuration file backup interface is shown as below. See Figure 4-155. This function allows you to import/export system configuration. You can use this function when there are several devices need the same setup.  Export: Please connect the peripheral device first and then go to the following interface.
Page 154 Figure 4-155 4.10.5.11 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 5-26.  Camera  Network  Event  Storage  System Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu.
Page 155 Figure 4-156 4.10.5.12 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-48.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.
Page 156: Web Operation
5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...
Page 157: Lan Mode
Figure 5-2 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  Section 1: there are five function buttons: Live（chapter 5.4）, setup (chapter 5.8), search (chapter 5.10), alarm (chapter 5.11), and logout (chapter 5.12).
Page 158: Section 3: Start Dialogue Button
 Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 5-4. Figure 5-4 Please refer to Figure 5-5 for main stream and extra stream switch information. Figure 5-5 ...
Page 159: Real-Time Monitor
Figure 5-8  Section 6: From the left to the right ,you can see video quality/fluency/ full screen/1-window/4-window/6-window/8-window/9-window/13-window/16-window/20- window/25-window/36-window.. You can set video fluency and real-time feature priority.  Section 7: PTZ operation panel. Please refer to chapter 5.5 for detailed information. ...
Page 160  1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted.
Page 161: Relay Output
Parameter Function You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-11 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-12.
Page 162: Wan Login
Figure 5-13 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-14. Figure 5-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.
Page 163 Figure 5-15 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
Page 164 Figure 5-16 Figure 5-17 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.
Page 165 Parameter Function Delete Click , you can delete the remote connection of the corresponding channel. : Connection succeeded. Connection status : Connection failed. Delete Select a device in the Added device list and then click Delete button, system can disconnect the device and remove it from the Added device list.
Page 166 Figure 5-19 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level.
Page 167 Gain The gain adjust is to set the gain value. The smaller the value is, the low the noise is. But the brightness is also too low in the dark environments. It can enhance the video brightness if the value is high.
Page 168 video according to the device feature (The general bright of the video or there is IR light or not.)  B/W: The device outputs the black and white video.  Sensor: It is to set when there is peripheral connected IR light.
Page 169 dropdown list. Please note the option may vary due to different series. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is , the better the quality is. Please refer to recommend bit rate for the detailed information.
Page 170 Click it; you can copy current channel setup to other channel(s). Copy 5.8.1.3.3 Video Overlay The video overlay interface is shown as in Figure 5-22. Figure 5-22 Please refer to the following sheet for detailed information. Parameter Function Cover-area Check Preview or Monitor first. Click Set button, you can privacy mask the specified video in the preview or monitor video.
Page 171 Please click the Save button to save current setup. Figure 5-23 5.8.1.4 Channel Name Here you can set channel name. See Figure 5-24. Please note this function is for analog channel only. Figure 5-24 5.8.2 Network 5.8.2.1 TCP/IP The TCP/IP interface is shown as in Figure 5-25. Figure 5-25 Please refer to the following sheet for detailed information.
Page 172 DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.  If you select the DHCP mode, you can view the IP/submask/gateway from the DHCP.  If you switch from the DHCP mode to the static mode, you need to reset the IP parameters.
Page 173 number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary. HTTPS The default value is 443. You can input the actual port number if necessary. RTSP port The default value is 554. 5.8.2.3 WIFI Please note this function is for the device of WIFI module.
Page 174 Please refer to the following sheet for detailed information. Parameter Function WLAN type Here you can select 3G network type to distinguish the 3G module from different ISP. The types include WCDMA， CDMA1x and etc. APN/Dial No. Here is the important parameter of PPP. Authorization It includes PAP,CHAP,NO_AUTH.
Page 175 Figure 5-30 5.8.2.6 DDNS The DDNS interface is shown as in Figure 5-31. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
Page 176 2) Function Introduction The quick DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only. You need to refresh the bonding relationship of the domain and the IP regularly.
Page 177 5.8.2.8 Email The email interface is shown as in Figure 5-33. Figure 5-33 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25.
Page 178 Parameter Function function is very useful when there are too many emails activated by the abnormity events, which may result in heavy load for the email server. Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not.
Page 179 Figure 5-35 5.8.2.11 SNMP The SNMP interface is shown as in Figure 5-36. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 5-36 Please refer to the following sheet for detailed information.
Page 180: Auto Register
Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the proxy Trap address program of the device.
Page 181: Alarm Centre
5.8.2.14 Alarm Centre The alarm centre interface is shown as below. See Figure 5-39. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs. Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
Page 182 Figure 5-41 You can see the corresponding prompt. See Figure 5-42. Now the server certificate is successfully created. Figure 5-42 5.8.2.15.2 Download root certificate In Figure 5-40, click button, system pops up a dialogue box. See Figure 5-43. Figure 5-43 Click Open button, you can go to the following interface.
Page 183 Figure 5-44 Click Install certificate button, you can go to certificate wizard. See Figure 5-45. Figure 5-45 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-46.
Page 184 Figure 5-46 Click Next button, you can see the certificate import process is complete. See Figure 5-47. Figure 5-47 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-48.
Page 185 Figure 5-48 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-49. Figure 5-49 5.8.2.15.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-50. You can see HTTPS default value is 443.
Page 186 5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect The motion detect interface is shown as in Figure 5-51. Figure 5-51 Figure 5-52...
Page 187 Figure 5-53 Figure 5-54 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list.
Page 188 Parameter Function Period Motion detection function becomes activated in the specified periods. See Figure 5-52. There are six periods in one day. Please draw a circle to enable corresponding period. Click OK button, system goes back to motion detection interface, please click save button to exit.
Page 189 Here you can set PTZ movement when alarm occurs. Such as go Activation to preset X. See Figure 5-54. Video Matrix This function is for motion detect only. Check the box here to enable video matrix function. Right now system supports one-channel tour function.
Page 190 Figure 5-56 5.8.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.2.1 Local Alarm The local alarm interface is shown as in Figure 5-57. It refers to alarm from the local device.
Page 191 Figure 5-58 Figure 5-59 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
Page 192 Parameter Function whole week. Click OK button, system goes back to local alarm interface, please click save button to exit. System only memorizes one event during the anti-dither Anti-dither period. The value ranges from 5s to 600s. There are two options: NO/NC. Sensor type Record channel System auto activates motion detection channel(s) to...
Page 193 Figure 5-60 5.8.3.2.3 IPC External Alarm IPC external alarm interface is shown as below. See Figure 5-61. For setup information, please refer to chapter 5.8.3.2.1. Figure 5-61 5.8.3.2.4 IPC Offline Alarm IPC offline alarm is shown as in Figure 5-62 . For setup information, please refer to chapter 5.8.3.2.1.
Page 194: Alarm Output
Figure 5-62 5.8.3.3 Alarm Output It is to set alarm output mode. See Figure 5-63. Figure 5-63 5.8.3.4 Abnormality It includes two types: HDD error/Network error. HDD error: No disk, disk error, disk no space. See Figure 5-64 and Figure 5-65. Network error: Net disconnection, IP conflict and MAC conflict.
Page 195 Figure 5-64 Figure 5-65 Figure 5-66 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).
Page 196 Parameter Function Show System can pop up a message to alarm you in the local host screen if message you enabled this function. Alarm System can upload the alarm signal to the centre (Including alarm upload centre. Send If you enabled this function, System can send out an email to alert you Email when an alarm occurs.
Page 197 Figure 5-68 Figure 5-69 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30.
Page 198: Local Storage
Parameter Function Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD. Snapshot Check the box here to enable snapshot function. Holiday Check the box here to enable holiday function. Setup Click the Setup button, you can set record period.
Page 199 Figure 5-71 5.8.4.3 Manual Record The interface is shown as in Figure 5-72. Figure 5-72 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device.
Page 200 5.8.4.4.1 Main Stream The main stream interface is shown as in Figure 5-73. Here you can set corresponding HDD group to save main stream. Figure 5-73 5.8.4.4.2 Sub Stream The sub stream interface is shown as in Figure 5-74. Here you can set corresponding HDD group to save sub stream. Figure 5-74 5.8.4.4.3 Snapshot The snapshot interface is shown as in Figure 5-75.
Page 201 5.8.4.5 Quota It is to set channel storage capacity. See Figure 5-76. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 5-76 5.8.5 Setting 5.8.5.1 General The general interface includes general, date/time and holiday setup. 5.8.5.1.1 General The general interface is shown as in Figure 5-77.
Page 202 Standard Here is for you to select working mode when hard disk is full. There HDD full are two options: stop recording or rewrite. If current working HDD is overwritten or the current HDD is full while the next HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files.
Page 203 Holiday setup interface is shown as in Figure 5-79. Here you can click Add box to add a new holiday and then click Save button to save. Figure 5-79 5.8.5.2 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.2.1 GUI Here you can set background color and transparency level.
Page 204 Figure 5-81 5.8.5.2.3 Tour The tour interface is shown as in Figure 5-82. Here you can set tour interval, split mode, motion detect tour and alarm tour mode. Figure 5-82 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function.
Page 205: Video Matrix
Figure 5-83 Please refer to the following sheet for detailed information. Parameter Function This function is disabled by default. Check the box here to enable Enable this function so that you can control the zero-channel encoding function at the WEB. Compression System default setup is H.264.
Page 206 Figure 5-84 5.8.5.3.2 HDMI This function is for some series only. The HDMI interface is shown as in Figure 5-85. It is to set the HD video matrix output tour function of the HDMI port 2. You can set tour channel, resolution, and interval. System support 1/4-window tour.
Page 207 The RS232 interface is shown as in Figure 5-86. Figure 5-86 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200. Data Bit The value ranges from 5 to 8.
Page 208 Figure 5-87 Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel There are two modes:Local/remote. PTZ type Please select corresponding protocol from the dropdown list. Protocol Set corresponding dome address. Default value is 1. Please note Address your setup here shall comply with your dome address;...
Page 209  Overlay mode: There are two options: preview and encode. Preview means overlay the card number in the local monitor video. Encode means overlay the card number in the record file.  Overlay Position: Here you can select the proper overlay position from the dropdown list.
Page 210 For the ATM/POS without the protocol, the interface is shown as in Figure 5-90. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 211 Figure 5-92 5.8.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods. See Figure 5-93. Figure 5-93 5.8.5.8 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits.
Page 212  User management adopts group/user modes. The user name and the group name shall be unique. One user shall be included in only one group. 5.8.5.8.1 User name In this interface you can add/remove user and modify user name. See Figure 5-94. Figure 5-94 Add user: It is to add a name to group and set the user rights.
Page 213 Figure 5-95 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-96. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup. Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit.
Page 214 Figure 5-96 5.8.5.8.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-97. Figure 5-97 Add group: It is to add group and set its corresponding rights. See Figure 5-98. Please input the group name and then check the box to select the corresponding rights.
Page 215 includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-98 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-99. Here you can modify group information such as remarks and rights. Figure 5-99...
Page 216: Auto Maintain
5.8.5.9 Auto maintain The auto maintain interface is shown as in Figure 5-100. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.
Page 217 5.8.5.12 Upgrade The upgrade interface is shown as in Figure 5-103. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.
Page 218: Connection Log
Figure 5-105 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.
Page 219: Online User
Figure 5-106 5.9.4 Online User The online user interface is shown as in Figure 5-107. Figure 5-107 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-108. Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date.
Page 220 Figure 5-108 Then please click File list button, you can see the corresponding files in the list. See Figure 5-109. Figure 5-109 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not...
Page 221 playback and download at the same time. You can use the playback control bar to implement various operations such as play, pause, stop, slow play, fast play and etc. See Figure 5-110. Figure 5-110 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-111.
Page 222 Figure 5-111 HD Transcoding When the bandwidth is limited, you can use this function to transfer the HD bit stream to the specified lower resolution and then playback. It is to reduce network load. In Figure 5-108, select the playback period and then select playback mode and channel(s). Check the box to enable HD transcoding function and then click the Set button;...
Page 223 Figure 5-114 Watermark Watermark interface is shown as In Figure 5-113. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-115 5.11 Alarm Click alarm function, you can see an interface is shown as Figure 5-116. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.).
Page 224 Figure 5-116 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.
Page 225: Un-Install Web Control
Figure 5-117 5.13 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.
Page 226: Professional Surveillance System
6 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.
Page 227 7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
Page 228  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged. ...
Page 229  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
Page 230  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
Page 231  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...
Page 232: Daily Maintenance
29. After I connected to the IP channel, there multiple-window output is OK, but there is no one-window output. There are following possibilities:  Check there is video from the IP channel or not. Please go to the main menu->info->System->BPS to view bit stream real-time information. ...
Page 233: Appendix A Hdd Capacity Calculation
Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte. ...
Page 234 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...
Page 235: Appendix B-1 Compatible Usb List
Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...
Page 236 Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small Appendix B-3 Compatible Portable HDD list Brand Model Capacity...
Page 237 Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
Page 238 Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS SATA Seagate Seagate Constellation...
Page 239 Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G SATA Westem Digital...
Page 240 Hitachi HitachiCinemaStar™ HCP725050GLA380 500G SATA 5K500 Hitachi HitachiCinemaStar™ HCT721050SLA360 500G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721075SLA360 750G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...
Page 241: Compatible Cd/Dvd Burner List
Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...
Page 242: Appendix D Compatible Displayer List
Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...
Page 243: Appendix E Compatible Switcher
Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive...
Page 244: Appendix F Compatible Wireless Mouse List
Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...
Page 245 Appendix G Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
Page 246  Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
Page 247 conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
Page 248  The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2.  The ground cable of the monitor system can not short circuit or mixed connected with the strong alternative current cable.
Page 249 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.
Page 251: Appendix H Toxic Or Hazardous Materials Or Elements
Appendix H Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...
Page 252 DVR-FE032960-DH User’s Manual Our Units Do Not Suppord PAL V1.3.0...
Page 253 Table of Contents FEATURES AND SPECIFICATIONS ............1 Overview ..........................1 Features ..........................1 Specifications ........................2 DVR-FE032960-DH Series 1.3.3 ..................10 OVERVIEW AND CONTROLS ............... 15 Front Panel ........................15 DVR-FE032960-DH Series 2.1.2 ..................16 Rear Panel ........................19 DVR-FE032960-DH Series 2.2.3 ..................
Page 254 INSTALLATION AND CONNECTIONS ..........31 Check Unpacked DVR ..................... 31 About Front Panel and Rear Panel ................. 31 3.2.1 HDD Installation ......................31 3.2.2 Rack Installation ......................33 Connecting Power Supply ....................33 Connecting Video Input and Output Devices ..............33 3.4.1 Connecting Video Input ....................
Page 255 Startup Wizard ........................41 Manual Record ......................... 44 4.3.1 Live Viewing ......................... 44 Right-Click Menu ......................46 4.4.1 Window Switch ......................46 4.4.2 PIP ..........................47 4.4.3 PTZ Control ........................48 4.4.4 Auto Focus ........................54 4.4.5 Color ..........................54 4.4.6 Search ..........................
Page 256 4.8.1 Search .......................... 62 4.8.2 Backup .......................... 69 4.8.3 Shut Down ........................72 Information ........................72 4.9.1 System Info ........................72 4.9.2 Event..........................76 4.9.3 Network ........................76 4.9.4 Log ..........................79 4.10 Setting ..........................81 4.10.1 Camera ........................81 4.10.2 Network ........................
Page 257 5.8.1 Camera ........................169 5.8.2 Network ........................177 5.8.3 Event........................... 192 5.8.4 Storage ........................202 5.8.5 Setting ........................207 Information ........................223 5.9.1 Version ........................223 5.9.2 Log ..........................223 5.9.3 Connection Log ......................224 5.9.4 Online User ........................ 225 5.10 Playback .........................
Page 258 Appendix B-4 Compatible USB DVD List ................242 Appendix B-5 Compatible SATA DVD List ................242 Appendix B-6 Compatible SATA HDD List ................243 APPENDIX C COMPATIBLE CD/DVD BURNER LIST ......247 APPENDIX D COMPATIBLE DISPLAYER LIST ........248 APPENDIX E COMPATIBLE SWITCHER ........... 249 APPENDIX F COMPATIBLE WIRELESS MOUSE LIST ......
Page 259 Welcome Thank you for purchasing our DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series hybrid standalone DVR features and functions. Before installation and operation please read the following safeguards and warnings carefully!
Page 260: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electric shock caused by improper handling or installation.
Page 261: Features And Specifications
FEATURES AND SPECIFICATIONS 1.1 Overview The hybrid standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detailed analysis.
Page 262: Specifications
Client-end user can download the file to local HDD to backup via network. Support eSATA, SATA port backup (eSATA port can connect to burner or HDD, SATA port can connect to burner.)  Record & playback function Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc.
Page 263: Dvr-Fe032960-Dh Series
DVR-FE032960-DH Series 1.3.3 32-ch Series Parameter Main High-performance industrial embedded micro controller System Processor Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices Front panel, USB mouse, remote control Arabic number, English character, donation and extension Chinese Input Method (optional)
Page 264 Privacy mask Support one privacy mask of user-defined size in full screen. Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video. Channel Lock Cover secret channel with black screen though system is encoding normally.
Page 265 function Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.) Support peripheral eSATA backup device. Support network download and save View monitor channel remotely. DVR configuration through client-end and web browser Upgrade via client or browser to realize remote maintenance. Network View alarm information such as external alarm, motion detection and Function...
Page 266 On-line user Display current on-line user User Multi-lever user management; various management modes Management Integrated management for local user, serial port user and network User user. Configurable user power. Management Support user /group and its corresponding rights modification. No limit to the user or group amount. Password modification Administrator can modify other user’s password.
Page 267: Overview And Controls
2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel DVR-FE032960-DH Series 2.1.2 Name Icon Function Power button, press this button for three seconds to boot up or Power button shut down DVR.
Page 268 Go to previous menu, or cancel current operation. When playback, click it to restore real-time monitor mode. Confirm current operation Enter ENTER Go to default button Go to menu One-window monitor mode, click this button to display assistant function: PTZ control and image color. Backspace function: in numeral control or text control, press it for 1.5 seconds to delete the previous character before the cursor.
Page 269: Rear Panel
2.2 Rear Panel DVR-FE032960-DH Series 2.2.3 The 32-channel series DVR rear panel is shown as below. See Figure 2-5. Figure 2-5 Please refer to the following sheet for detailed information. Icon Name Function Ground port Power switch Power on/off button. VIDEO IN VIDEO IN Video input port...
Page 270 USB2.0 port Connect to mouse, USB storage media, USB-burner and etc. High definition HDMI1 High definition audio and video media interface signal output port. It transmits the same video signal VGA/TV. Support mouse operation. HDMI2 HD video matrix output. Support zero-channel encoding matrix output.
Page 271: Connection Sample
devices such as speed dome communication port PTZ. RS485_B.It is the cable B. You connect control devices such as speed dome PTZ. Alarm input ground end. Alarm input port ground end T+,T-, R+, R- Four-cable T+, T-: Send out cable. full-duplex 485 port.
Page 272: Remote Control
2.4 Remote Control The remote control interface is shown as in Figure 2-7. Please note remote control is not our standard accessory and it is not included in the accessory bag. Figure 2-7 Serial Number Name Function Power button Click it to boot up or shut down the device.
Page 273 In normal playback click this button to pause playback. In real-time monitor mode, click this button to enter video search menu. Reverse/pause Reverse playback pause mode, click this button to realize normal playback. In reverse playback click this button to pause playback. Esc.
Page 274: Mouse Control
2.5 Mouse Control Left click System pops up password input dialogue box if you have not logged in. mouse In real-time monitor mode, you can go to the main menu. When you have selected one menu item, left click mouse to view menu content.
Page 275: Virtual Keyboard & Front Panel
Right click In real-time monitor mode, pops up shortcut menu: one-window, mouse four-window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel. If you are in multiple-window mode, system automatically switches to the corresponding channel.
Page 276: Installation And Connections
3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.
Page 277 DVR-FE032960-DH Series 3.2.1.2 This series DVR max supports 8 SATA HDDs. Please use HDD of 7200rpm or higher. 3. Now you can see the bottom 2. Remove the HDD upper Loosen the screws of the bracket bracket upper cover. 4. Line up the HDD to the 5.
Page 278: Rack Installation
7. Unfasten the HDD power Insert the HDD power Use the special data cable to cable. cable. connect the HDD and the SATA port. Close the chassis and fix the screws to secure firmly. Important: If the HDD amount is less than four, you do not need to install the HDD bracket. When there is a bracket, please make sure the installation direction of HDDs is the same.
Page 279: Connecting Video Output
The camera shall be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc. The camera and the DVR should have the same grounding to ensure the normal operation of the camera. Guarantee stability and reliability of the transmission line BTT TB Please use high quality, sound shielded BNC.
Page 280: Alarm Input And Output Connection
3.6 Alarm Input and Output Connection Please read the followings before connecting. 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c. Alarm input needs the low level voltage signal. d.
Page 281 Figure 3-1 Figure 3-2 Figure 3-3 Please refer to the following sheet for detailed information. : 1，2，3，4，5，6， ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 7，8，9，10，11， 12，13，14，15，16 NO1 C1， The first four are four groups of normal open activation output (on/off NO2 C2，...
Page 282: Alarm Input Port
device power to cancel the alarm. +12V It is external power input. Need the peripheral equipment to provide +12V power (below 1A). Earth cable. 485 A/B 485 communication port. They are used to control devices such as decoder. T+,T-,R+,R- They are four-wire double duplex RS485 port T+ T-: output wire R+ R-: input wire 3.6.2 Alarm Input Port...
Page 283 Rating Rated switch capacity 30VDC 2A, 125VAC 1A （Resistance Maximum switch power 125VA 160W Load） Maximum switch voltage 250VAC, 220VDC Maximum switch currency Insulation Between touches with same 1000VAC 1minute polarity 1000VAC 1minute Between touches with different polarity Between touch and winding 1000VAC 1minute Between touches with same Surge voltage...
Page 284: Other Interfaces
Figure 3-5 485 Port Figure 3-6 Figure 3-7 485 Port 3.8 Other Interfaces There are still other interfaces on the DVR, such as USB ports.
Page 285: Overview Of Navigation And Controls
4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...
Page 286: Startup Wizard
4.2 Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time.
Page 287 Note: For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Click OK button, you can go to General interface. See Figure 4-3. For detailed information, please refer to chapter 4.10.5.1.
Page 288 Figure 4-4 Click Next button, you can go to Schedule interface. See Figure 4-5. For detailed information, please refer to chapter 4.10.4.1.1. Figure 4-5 Click Finish button, system pops up a dialogue box. Click the OK button, the startup...
Page 289: Manual Record
wizard is complete. See Figure 4-6. Figure 4-6 4.3 Manual Record 4.3.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->System->General).
Page 290  Support digital zoom function.  Support real-time backup function. You can follow the contents listed below for the operation instruction. Preview control interface Move you mouse to the top centre of the video of current channel, you can see system pops up the preview control interface.
Page 291: Right-Click Menu
Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device. System can not backup the video of multiple-channel at the same time. Click button , system begins recording.
Page 292: Pip
Figure 4-11 4.4.2 PIP It is to realize picture in picture function in 1-window mode. The small window supports instance playback, digital zoom and etc.  Window switch: Double click the small window, you can switch the position of the large window and the small window.
Page 293: Ptz Control
Figure 4-12 Figure 4-13 Go to the 1-winode mode, on the navigation bar, click , you can see the video on the large window and the video from the next channel is the default video on the small window. If you have set PIP function, you can click to view the last edited PIP video.
Page 294 Please note the commend name is grey once device does not support this function. The PTZ operation is only valid in one-window mode. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc. Speed is to control PTZ movement speed.
Page 295: Ptz Function Setup
etc. See Figure 4-16. Figure 4-16 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4-14.
Page 296 Figure 4-17 Preset Setup In Figure 4-17, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-18. Click Set button and then input preset number. Click Set button to save current preset. Figure 4-18 Tour Setup In Figure 4-17, click tour button.
Page 297 Figure 4-19 Pattern Setup In Figure 4-17, click Pattern button and input pattern number. Click Begin button to start direction operation. Or you can go back to Figure 4-14 to operate zoom/focus/iris/direction operation. In Figure 4-17, click End button. Figure 4-20 Scan Setup In Figure 4-17, click Scan button.
Page 298 Figure 4-21 4.4.3.2 Call PTZ Function Call Preset In Figure 4-16, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-16, input pattern value and then click to call a pattern. Click again to stop call.
Page 299: Auto Focus
Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-22. Figure 4-22 4.4.4 Auto Focus It is to set auto focus function. Please make sure the camera supports this function. 4.4.5 Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
Page 300 Item Note periods. Effective Time Check the box here to enable this function and then set period time. The value here is to adjust the edge of the video. The value ranges from 0 to 100. The larger the value is, the clear the edge is and vice versa.
Page 301: Search
Item Note gentle. Select a color mode, the sharpness, brightness, contrast automatically switch corresponding setup. 4.4.6 Search Please refer to chapter 4.8.1 for detailed information. 4.4.7 Record Control Please refer to chapter 4.10.4.3 for detailed information. 4.4.8 Remote Device Please refer to chapter 4.10.1.1 for detailed information. 4.4.9 Manual Record Please refer to chapter 4.4.9 for detailed information.
Page 302 Figure 4-25 In Figure 4-25, click Add to favorites; you can see the following interface. See Figure 4-26 . Here you can input customized favorites name. System max supports 31-character. Click OK button, you can save current favorites name. Figure 4-26 In Figure 4-25, click Edit favorites;...
Page 303: Channel Tree
Figure 4-27 Double click a name; you can change its name. See Figure 4-28. Input a new name and then click OK button. Figure 4-28 4.5.4 Channel Tree It is to set channel setup. The interface is shown as below. See Figure 4-29.
Page 304: Tour
Figure 4-29 The one level includes 16 channels. See Figure 4-30. You can left click to select a channel on the tree and then drag it to the preview window on the left pane. Once the channel is on the preview window, the channel number on the channel tree becomes grey and it is null now (can not be selected).
Page 305: Search
4.5.8 Search Click button , system goes to search interface. Please refer to chapter 4.8.1 4.5.9 Alarm Status Click button , system goes to alarm status interface. It is to view device status and channel status. Please refer to chapter 4.10.3. 4.5.10 Channel Info Click button , system goes to the channel information setup interface.
Page 306: Usb Device Auto Pop-Up
， system goes to the USB Manager interface. It is to view USB information, Click backup and update. Please refer to chapter 4.8.2, chapter 4.9.4, chapter 4.10.5.10, and chapter 4.10.5.12 for detailed information. 4.6 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box.
Page 307: Operation
Figure 4-33 4.8 Operation 4.8.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4-34. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file...
Page 308 Figure 4-34 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
Page 309  selection In 9-window playback mode, you can switch between 1-8 and 9-16 channels.  pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels.  The time bar will change once you modify the playback mode or the channel option.
Page 310 ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward  In playback mode, click to realize various fast play modes such as fast play 1,fast play 2 and etc.
Page 311  For one device, if there is a backup in process, you can not start a new backup operation.  It is to edit the file. ●Please play the file you want to edit and then click this button when you want to edit.
Page 312 channel This function is null if there is no record file or system is in smart search process. when playback 4.8.1.1 Smart Search During the multiple-channel playback mode, double click one channel and then click the button, system begins smart search. System supports 396(22*18 PAL) and 330(22*15 NTSC) zones.
Page 313: Mark Playback
 After you searched files, system implement accurate playback once you click Play for the first time.  System does not support accurate playback for picture.  System supports synchronization playback and non-synchronous playback. The synchronization playback supports all channels and non-synchronous playback only supports accurately playback of current select channel.
Page 314: Backup
Here you can set to begin playback from previous N seconds of the mark time. Note Usually, system can playbacks previous N seconds record if there is such kind of record file. Otherwise, system playbacks from the previous X seconds when there is such as kind of record.
Page 315 Client Operation for network download backup operation. Click backup button, you can see an interface is shown as in Figure 4-39. Here is for you to view devices information. You can view backup device name and its total space and free space. The device includes CD-RW, DVD burner, USB device, flash disk, eSATA backup.
Page 316 Figure 4-40 √ before channel name. You can use Fn or cancel System only backup files with a button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.
Page 317: Shut Down
When the system completes backup, you can see a dialogue box prompting successful backup.  File format: Click the file format; you can see there are two options: DAV/ASF. The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S.
Page 318: Hdd Information
Figure 4-43 4.9.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-44.  SATA: 1-8 here means system max supports 8 HDDS (It depends on the product you purchased).
Page 319: Record Info
Figure 4-44 Double click one HDD information; you can see the HDD SMART information. See Figure 4-45. Figure 4-45 4.9.1.2 Record Info It is to view record start time and end time. See Figure 4-46.
Page 320 Figure 4-46 4.9.1.3 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-47. Figure 4-47 4.9.1.4 Version Here is for you to view some version information such as version number, built date, serial number and etc.
Page 321: Event
Figure 4-48 4.9.2 Event It is to display device status and channel status. See Figure 4-49. Figure 4-49 4.9.3 Network...
Page 322: Online Users
4.9.3.1 Online Users Here is for you to manage online users. See Figure 4-50. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
Page 323: Network Test
Figure 4-51 4.9.3.3 Network Test Network test interface is shown as in Figure 4-52.  Destination IP: Please input valid IPV4 address or domain name.  Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.
Page 324: Log
Figure 4-52 4.9.4 Log Here is for you to view system log file. System lists the following information. See Figure 4-53. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log.
Page 325: Remote Log
Figure 4-53 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-54. Figure 4-54 4.9.4.1 Remote Log In this interface, you can search the IPC log information of the corresponding channel.
Page 326: Setting
select another channel (doe not need to click Search button again), you can view remote connection log. Figure 4-55 4.10 Setting 4.10.1 Camera 4.10.1.1 Remote Device (For digital channel only) 4.10.1.1.1 Remote Device In the main menu, from Camera ->Remote, you can go to an interface shown as in Figure 4-56.
Page 327  Delete: Please select one device in the Added device list and then click remove.  Status: means connection is OK and means connection failed.  Delete；Select a device on the Added device list, click Delete button, system disconnect device first and then remove its name from the list. ...
Page 328 Figure 4-57 4.10.1.1.2 Channel Status Here you can view the IPC status of the corresponding channel such as motion detect, video loss, tampering, alarm and etc. See Figure 4-58.  IPC status: : Front-end does not support. : Front-end supports. There is alarm event from current front-end.
Page 329 Figure 4-59 4.10.1.1.4 Remote Upgrade It is to update the camera. From main menu->setting->camera->remote, the interface is shown as below. See Figure 4-60. Click Browse button and then select the upgrade file. Then select a channel (or you can select device type filter to select several devices at the same time.) Click Start upgrade button to update.
Page 330 4.10.1.2 Image The image interface is shown as below. See Figure 4-61(analog channel) and Figure 4-62(digital channel).  Channel: Select a channel from the dropdown list.  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50.
Page 331  Auto: The auto white balance is on. System can auto compensate the color temperature to make sure the vide color is proper.  Sunny: The threshold of the white balance is in the sunny mode.  Night: The threshold of the white balance is in the night mode. ...
Page 332 Figure 4-62 4.10.1.3 Encode It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.10.1.3.1 Video Video setting includes the following items. See Figure 4-63.  Channel: Select the channel you want.  Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm.
Page 333 Figure 4-63 4.10.1.3.2 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-64.  Snapshot mode: There are two modes: regular and trigger. If you set timing mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation.
Page 334 4.10.1.3.3 Overlay Overlay interface is shown as in Figure 4-65.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. ...
Page 335 Figure 4-66 4.10.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-67. Figure 4-67 4.10.1.3.5 Channel Type It is to set channel type. Each channel supports analog connection/analog HD connection/network camera connection (Slight function difference may be found). The network camera connection shall begin with the last channel.
Page 336: Network
Figure 4-68 4.10.2 Network 4.10.2.1 TCP/IP The single network adapter interface is shown as in Figure 4-69 and the dual network adapters interface is shown as in Figure 4-70  Network Mode : Includes multiple access, fault tolerance, and load balancing ...
Page 337  Main Network Card: Please select eth0/eth1 (optional).after enable multiple access function. Note: Some series support the above three configurations and supports functions as multiple-access, fault-tolerance and load balancing.  IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them.
Page 338 Figure 4-69 Figure 4-70 4.10.2.2 Connection The connection setup interface is shown as in Figure 4-71.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777.  UDP port: Default value is 37778.
Page 339  HTTP port: Default value is 80.  HTTPS port: Default value is 443.  RTSP port: Default value is 554. Important: System needs to reboot after you changed and saved any setup of the above four ports. Please make sure the port values here do not conflict. Figure 4-71 4.10.2.3 WIFI The WIFI interface is shown as below.
Page 340 Figure 4-72  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
Page 341  AUTH: It is the authentication mode. It supports PAP/CHAP.  Dial number: Please input 3G network dialup number you got from your ISP.  User name: It is the user name for you to login the 3G network.  Password: It is the password for you to login the 3G network.
Page 342: Ddns Setup
Figure 4-74 4.10.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-75. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
Page 343 Figure 4-75 Please note NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
Page 344  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. ...
Page 345  Default: Click it to restore default setup. In this case, the trusted sites and blocked sites are both null. Note:  If you enabled trusted sites, only the IP in the trusted sites list can access the device.  If you enabled blocked sites, the IP in the blocked sites can not access the device.
Page 346  Title: Please input email subject here. System support English character and Arabic number. Max 32-digit.  Receiver: Please input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly.
Page 347 -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See Figure 4-79. Figure 4-79 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify...
Page 348 After completed channel and weekday setup, you can set two periods for one each channel. Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not. Figure 4-81 4.10.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN. Please input the router IP address in the LAN in Figure 4-69.
Page 349 Important: When you are setting the router external port, please use 1024~5000 port. Do not use well-known port 1~255 and the system port 256~1023 to avoid conflict. For the TCP and UDP, please make sure the internal port and external port are the same to guarantee the proper data transmission.
Page 350 You can set in the following interface. See Figure 4-84. Figure 4-84 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection.
Page 351 Figure 4-85 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...
Page 352: Alarm Centre
Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only. 4.10.2.13 Alarm Centre This interface is reserved for you to develop.
Page 353 Figure 4-87 2) The proxy server software developed from the SDK. Please open the software and input the global setup. Please make sure the auto connection port here is the same as the port you set in the previous step. 3) Now you can add device.
Page 354: Event
Figure 4-88 4.10.3 Event 4.10.3.1 Detect In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-89. There are three detection types: motion detection, video loss, tampering.  The video loss has no detection region and sensitivity setup and tampering has no detection region setup.
Page 355 click ENTER button to exit current setup. Do remember click save button to save current setup. If you click ESC button to exit the region setup interface system will not save your zone setup. The analog channel supports 4 zones. For the digital channel, please make sure your network camera supports 4 zones.
Page 356  PTZ activation: Here you can set PTZ movement when an alarm occurs. Such as go to preset, tour &pattern when there is an alarm. Click “select” button, you can see an interface is shown as in Figure 4-91  Record Delay: System can delay the record for specified time after alarm ended.
Page 357 Figure 4-90 Figure 4-91...
Page 358 Figure 4-92 Figure 4-93 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.3.1.2 Video Loss In Figure 4-89, select video loss from the type list. You can see the interface is shown as in Figure 4-94.This function allows you to be informed when video loss phenomenon occurred.
Page 359 Please refer to chapter 4.10.3.1.1 motion detection for detailed information. Figure 4-94 4.10.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-95.
Page 360 Figure 4-95 4.10.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. See Figure 4-96. There are four alarm types. See Figure 4-96 to Figure 4-99. ...
Page 361  Period: Click set button, you can see an interface is shown as in Figure 4-101. There are two ways for you to set periods. There are max 6 periods in one day. There are four record types: regular, motion detection (MD), Alarm, MD & alarm. ...
Page 362 activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.  Video matrix: Check the box here to enable this function. When an alarm occurs, SPOT OUT port displays device video output. It displays video (1-window tour) from alarm activation channel you select at the Record channel item.
Page 363 Figure 4-97 Figure 4-98...
Page 364 Figure 4-99 Figure 4-100...
Page 365 Figure 4-101 Figure 4-102 4.10.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-103 and Figure 4-104.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-105.  Alarm output: Please select alarm activation output port (multiple choices). ...
Page 366  Latch: Here you can set corresponding delaying time. The value ranges from 1s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.  Show message: system can pop up the message in the local screen to alert you when alarm occurs.
Page 367 Figure 4-104 Figure 4-105...
Page 368: Alarm Output
4.10.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-106.
Page 369  : Click it to delete a record type from one period.  Record Type: Please check the box to select corresponding record type. There are four types: Regular/MD (motion detect)/Alarm/MD&Alarm.  Week day: There are eight options: ranges from Saturday to Sunday and all. ...
Page 370 Figure 4-109 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording. The white means the MD and alarm record is valid.
Page 371 Figure 4-110 Figure 4-111 4.10.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-112. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
Page 372 Figure 4-112 4.10.4.1.1.2 Redundancy Redundancy function allows you to memorize record file in several disks. When there is file damage occurred in one disk, there is a spare one in the other disk. You can use this function to maintain data reliability and safety. ...
Page 373  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as regular, size, quality and frequency. See Figure 4-114.  In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See interface on the right of Figure 4-115. Please refer to the following figure for detailed information.
Page 374 Figure 4-115 4.10.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
Page 375 Figure 4-117 Figure 4-118 4.10.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
Page 376 In the main menu, from Setting->Network->FTP, you can set FTP server information. Please enable FTP function and then click save button. See Figure 4-119. Please boot up corresponding FTP server. Please enable schedule snapshot (Chapter 4.10.4.1.2.1) or activation snapshot (Chapter 4.10.4.1.2.2) first, now system can upload the image file to the FTP server. Please input corresponding...
Page 377 Figure 4-120 4.10.4.3 Record 4.10.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu. ...
Page 378 Figure 4-121 4.10.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-122. Figure 4-122 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function.
Page 379 4.10.4.4 Advanced It is to set HDD group, and HDD group setup for main stream, sub stream and snapshot operation 4.10.4.4.1 HDD Important HDD group and quota mode can not be valid at the same time. System needs to restart once you change the mode here. The HDD group mode is shown as in Figure 4-123.
Page 380 Figure 4-124 Figure 4-125...
Page 381 Figure 4-126 4.10.4.5 Quota Here you can set channel storage capacity. See Figure 4-127. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 4-127...
Page 382: Hdd Detect
Click Quota Statistics, you can go to the following interface. You can view HDD capacity you set for each channel. See Figure 4-128. Figure 4-128 4.10.4.6 HDD Detect The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD.
Page 383 Figure 4-129 4.10.4.6.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-130. Figure 4-130...
Page 384 Click View, you can see the detailed information such as detect result, backup and S.M.A.R.T. See Figure 4-131 and Figure 4-132. Figure 4-131 Figure 4-132...
Page 385: System
4.10.5 System 4.10.5.1 General 4.10.5.1.1 Device General setting includes the following items. See Figure 4-133.  Device ID: Please input a corresponding device name here.  Device No: Here you can set device number.  Language: System supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional.
Page 386 Figure 4-133 4.10.5.1.2 Date and Time The interface is shown as in Figure 4-134.  Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY.  Date separator: There are three denotations to separate date: dot, beeline and solidus.  DST: Here you can set DST time and date.
Page 387 Figure 4-134 4.10.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-135. Click Add new holiday button, you can input new holiday information. See Figure 4-136. Here you can set holiday name, repeat mode and start/end time. Note  When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.
Page 388 Figure 4-135 Figure 4-136 4.10.5.2 Display 4.10.5.2.1 Display Display setup interface is shown as below. See Figure 4-137.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
Page 389  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end. You need to open web or client end to refresh channel name.
Page 390 Figure 4-138 4.10.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-139  Enable tour: Highlight box here to enable this function.  Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
Page 391  On the navigation bar, click to enable/disable tour function. Figure 4-139 4.10.5.2.4 Zero-channel Encoding Click zero-channel encoding button, you can go to the following interface. See Figure 4-140.Here you can enable and set zero-channel encoding function so that you can view several video sources at one channel.
Page 392 Figure 4-140 4.10.5.3 Video Matrix 4.10.5.3.1 BNC Here you can set matrix output channel and its interval. System supports 1/4-window (and etc) SPOT tour. See Figure 4-141.
Page 393 Figure 4-141 4.10.5.3.2 HDMI This function is for some series only. The HDMI interface is shown as in Figure 5-85. It is to set the HD video matrix output tour function of the HDMI port 2. You can set tour channel, resolution, and interval. System support 1/4-window tour.
Page 394 Figure 4-142 4.10.5.4 RS232 RS232 interface is shown as below. There are five items. See Figure 4-143.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboar d is for you to control the device via the special keyboard.
Page 395 Figure 4-143 4.10.5.5 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-144.  PTZ type: There are two options: local/remote. Please select remote if you are connecting to the network PTZ.  Protocol: Select corresponding PTZ protocol such as PELCOD. ...
Page 396 Figure 4-144 4.10.5.6 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.10.5.6.1 COM Type The COM interface is shown as below. See Figure 4-145. ...
Page 397 Figure 4-145 4.10.5.6.2 Network Type The network type interface is shown as below. See Figure 4-146. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
Page 398 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-147. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 399 Figure 4-148 Click Add button, you can add audio file and import the audio file via the USB device. See Figure 4-149. Figure 4-149 4.10.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods.
Page 400 Figure 4-150 4.10.5.8 Account Here is for you to implement account management. See Figure 4-151. Here you can:  Add new user  Modify user  Add group  Modify group  Modify password. For account management please note:  For the user account name and the user group, the string max length is 6-byte.
Page 401  About user account and MAC. When you add a new user, you can input the MAC address of current user. Only the user of the same MAC address can access the device remotely.(MAC address is for the device of the same LAN.) If you leave MAC address item in blank when you add a new user, the user of any MAC address can access the device remotely.
Page 402 4.10.5.8.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-152. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
Page 403: Auto Maintain
Click add user button, the interface is shown as in Figure 4-153. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.
Page 404: Config Backup
Figure 4-154 4.10.5.10 Config Backup The configuration file backup interface is shown as below. See Figure 4-155. This function allows you to import/export system configuration. You can use this function when there are several devices need the same setup.  Export: Please connect the peripheral device first and then go to the following interface.
Page 405 Figure 4-155 4.10.5.11 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 5-26.  Camera  Network  Event  Storage  System Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu.
Page 406 Figure 4-156 4.10.5.12 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-48.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.
Page 407: Web Operation
5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...
Page 408: Lan Mode
Figure 5-2 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  Section 1: there are five function buttons: Live（chapter 5.4）, setup (chapter 5.8), search (chapter 5.10), alarm (chapter 5.11), and logout (chapter 5.12).
Page 409: Section 3: Start Dialogue Button
 Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 5-4. Figure 5-4 Please refer to Figure 5-5 for main stream and extra stream switch information. Figure 5-5 ...
Page 410: Real-Time Monitor
Figure 5-8  Section 6: From the left to the right ,you can see video quality/fluency/ full screen/1-window/4-window/6-window/8-window/9-window/13-window/16-window/20- window/25-window/36-window.. You can set video fluency and real-time feature priority.  Section 7: PTZ operation panel. Please refer to chapter 5.5 for detailed information. ...
Page 411: Ptz
 1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted.
Page 412: Image
Parameter Function You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-11 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-12.
Page 413: Wan Login
Figure 5-13 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-14. Figure 5-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.
Page 414: Setup
Figure 5-15 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
Page 415 Figure 5-16 Figure 5-17 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.
Page 416 Parameter Function Delete Click , you can delete the remote connection of the corresponding channel. : Connection succeeded. Connection status : Connection failed. Delete Select a device in the Added device list and then click Delete button, system can disconnect the device and remove it from the Added device list.
Page 417 Figure 5-19 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level.
Page 418 Gain The gain adjust is to set the gain value. The smaller the value is, the low the noise is. But the brightness is also too low in the dark environments. It can enhance the video brightness if the value is high.
Page 419 video according to the device feature (The general bright of the video or there is IR light or not.)  B/W: The device outputs the black and white video.  Sensor: It is to set when there is peripheral connected IR light.
Page 420 dropdown list. Please note the option may vary due to different series. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is , the better the quality is. Please refer to recommend bit rate for the detailed information.
Page 421 Click it; you can copy current channel setup to other channel(s). Copy 5.8.1.3.3 Video Overlay The video overlay interface is shown as in Figure 5-22. Figure 5-22 Please refer to the following sheet for detailed information. Parameter Function Cover-area Check Preview or Monitor first. Click Set button, you can privacy mask the specified video in the preview or monitor video.
Page 422 Please click the Save button to save current setup. Figure 5-23 5.8.1.4 Channel Name Here you can set channel name. See Figure 5-24. Please note this function is for analog channel only. Figure 5-24 5.8.2 Network 5.8.2.1 TCP/IP The TCP/IP interface is shown as in Figure 5-25. Figure 5-25 Please refer to the following sheet for detailed information.
Page 423 DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.  If you select the DHCP mode, you can view the IP/submask/gateway from the DHCP.  If you switch from the DHCP mode to the static mode, you need to reset the IP parameters.
Page 424 number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary. HTTPS The default value is 443. You can input the actual port number if necessary. RTSP port The default value is 554. 5.8.2.3 WIFI Please note this function is for the device of WIFI module.
Page 425 Please refer to the following sheet for detailed information. Parameter Function WLAN type Here you can select 3G network type to distinguish the 3G module from different ISP. The types include WCDMA， CDMA1x and etc. APN/Dial No. Here is the important parameter of PPP. Authorization It includes PAP,CHAP,NO_AUTH.
Page 426 Figure 5-30 5.8.2.6 DDNS The DDNS interface is shown as in Figure 5-31. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
Page 427 2) Function Introduction The quick DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only. You need to refresh the bonding relationship of the domain and the IP regularly.
Page 428 5.8.2.8 Email The email interface is shown as in Figure 5-33. Figure 5-33 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25.
Page 429 Parameter Function function is very useful when there are too many emails activated by the abnormity events, which may result in heavy load for the email server. Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not.
Page 430 Figure 5-35 5.8.2.11 SNMP The SNMP interface is shown as in Figure 5-36. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 5-36 Please refer to the following sheet for detailed information.
Page 431: Auto Register
Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the proxy Trap address program of the device.
Page 432: Alarm Centre
5.8.2.14 Alarm Centre The alarm centre interface is shown as below. See Figure 5-39. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs. Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
Page 433 Figure 5-41 You can see the corresponding prompt. See Figure 5-42. Now the server certificate is successfully created. Figure 5-42 5.8.2.15.2 Download root certificate In Figure 5-40, click button, system pops up a dialogue box. See Figure 5-43. Figure 5-43 Click Open button, you can go to the following interface.
Page 434 Figure 5-44 Click Install certificate button, you can go to certificate wizard. See Figure 5-45. Figure 5-45 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-46.
Page 435 Figure 5-46 Click Next button, you can see the certificate import process is complete. See Figure 5-47. Figure 5-47 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-48.
Page 436 Figure 5-48 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-49. Figure 5-49 5.8.2.15.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-50. You can see HTTPS default value is 443.
Page 437 5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect The motion detect interface is shown as in Figure 5-51. Figure 5-51 Figure 5-52...
Page 438 Figure 5-53 Figure 5-54 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list.
Page 439 Parameter Function Period Motion detection function becomes activated in the specified periods. See Figure 5-52. There are six periods in one day. Please draw a circle to enable corresponding period. Click OK button, system goes back to motion detection interface, please click save button to exit.
Page 440 Here you can set PTZ movement when alarm occurs. Such as go Activation to preset X. See Figure 5-54. Video Matrix This function is for motion detect only. Check the box here to enable video matrix function. Right now system supports one-channel tour function.
Page 441 Figure 5-56 5.8.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.2.1 Local Alarm The local alarm interface is shown as in Figure 5-57. It refers to alarm from the local device.
Page 442 Figure 5-58 Figure 5-59 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
Page 443 Parameter Function whole week. Click OK button, system goes back to local alarm interface, please click save button to exit. System only memorizes one event during the anti-dither Anti-dither period. The value ranges from 5s to 600s. There are two options: NO/NC. Sensor type Record channel System auto activates motion detection channel(s) to...
Page 444 Figure 5-60 5.8.3.2.3 IPC External Alarm IPC external alarm interface is shown as below. See Figure 5-61. For setup information, please refer to chapter 5.8.3.2.1. Figure 5-61 5.8.3.2.4 IPC Offline Alarm IPC offline alarm is shown as in Figure 5-62 . For setup information, please refer to chapter 5.8.3.2.1.
Page 445: Alarm Output
Figure 5-62 5.8.3.3 Alarm Output It is to set alarm output mode. See Figure 5-63. Figure 5-63 5.8.3.4 Abnormality It includes two types: HDD error/Network error. HDD error: No disk, disk error, disk no space. See Figure 5-64 and Figure 5-65. Network error: Net disconnection, IP conflict and MAC conflict.
Page 446 Figure 5-64 Figure 5-65 Figure 5-66 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).
Page 447 Parameter Function Show System can pop up a message to alarm you in the local host screen if message you enabled this function. Alarm System can upload the alarm signal to the centre (Including alarm upload centre. Send If you enabled this function, System can send out an email to alert you Email when an alarm occurs.
Page 448 Figure 5-68 Figure 5-69 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30.
Page 449: Local Storage
Parameter Function Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD. Snapshot Check the box here to enable snapshot function. Holiday Check the box here to enable holiday function. Setup Click the Setup button, you can set record period.
Page 450 Figure 5-71 5.8.4.3 Manual Record The interface is shown as in Figure 5-72. Figure 5-72 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device.
Page 451 5.8.4.4.1 Main Stream The main stream interface is shown as in Figure 5-73. Here you can set corresponding HDD group to save main stream. Figure 5-73 5.8.4.4.2 Sub Stream The sub stream interface is shown as in Figure 5-74. Here you can set corresponding HDD group to save sub stream. Figure 5-74 5.8.4.4.3 Snapshot The snapshot interface is shown as in Figure 5-75.
Page 452 5.8.4.5 Quota It is to set channel storage capacity. See Figure 5-76. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 5-76 5.8.5 Setting 5.8.5.1 General The general interface includes general, date/time and holiday setup. 5.8.5.1.1 General The general interface is shown as in Figure 5-77.
Page 453 Standard Here is for you to select working mode when hard disk is full. There HDD full are two options: stop recording or rewrite. If current working HDD is overwritten or the current HDD is full while the next HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files.
Page 454 Holiday setup interface is shown as in Figure 5-79. Here you can click Add box to add a new holiday and then click Save button to save. Figure 5-79 5.8.5.2 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.2.1 GUI Here you can set background color and transparency level.
Page 455 Figure 5-81 5.8.5.2.3 Tour The tour interface is shown as in Figure 5-82. Here you can set tour interval, split mode, motion detect tour and alarm tour mode. Figure 5-82 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function.
Page 456: Video Matrix
Figure 5-83 Please refer to the following sheet for detailed information. Parameter Function This function is disabled by default. Check the box here to enable Enable this function so that you can control the zero-channel encoding function at the WEB. Compression System default setup is H.264.
Page 457 Figure 5-84 5.8.5.3.2 HDMI This function is for some series only. The HDMI interface is shown as in Figure 5-85. It is to set the HD video matrix output tour function of the HDMI port 2. You can set tour channel, resolution, and interval. System support 1/4-window tour.
Page 458 The RS232 interface is shown as in Figure 5-86. Figure 5-86 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200. Data Bit The value ranges from 5 to 8.
Page 459 Figure 5-87 Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel There are two modes:Local/remote. PTZ type Please select corresponding protocol from the dropdown list. Protocol Set corresponding dome address. Default value is 1. Please note Address your setup here shall comply with your dome address;...
Page 460  Overlay mode: There are two options: preview and encode. Preview means overlay the card number in the local monitor video. Encode means overlay the card number in the record file.  Overlay Position: Here you can select the proper overlay position from the dropdown list.
Page 461 For the ATM/POS without the protocol, the interface is shown as in Figure 5-90. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 462 Figure 5-92 5.8.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods. See Figure 5-93. Figure 5-93 5.8.5.8 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits.
Page 463  User management adopts group/user modes. The user name and the group name shall be unique. One user shall be included in only one group. 5.8.5.8.1 User name In this interface you can add/remove user and modify user name. See Figure 5-94. Figure 5-94 Add user: It is to add a name to group and set the user rights.
Page 464 Figure 5-95 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-96. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup. Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit.
Page 465 Figure 5-96 5.8.5.8.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-97. Figure 5-97 Add group: It is to add group and set its corresponding rights. See Figure 5-98. Please input the group name and then check the box to select the corresponding rights.
Page 466 includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-98 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-99. Here you can modify group information such as remarks and rights. Figure 5-99...
Page 467: Auto Maintain
5.8.5.9 Auto maintain The auto maintain interface is shown as in Figure 5-100. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.
Page 468: Information
5.8.5.12 Upgrade The upgrade interface is shown as in Figure 5-103. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.
Page 469: Connection Log
Figure 5-105 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.
Page 470: Online User
Figure 5-106 5.9.4 Online User The online user interface is shown as in Figure 5-107. Figure 5-107 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-108. Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date.
Page 471 Figure 5-108 Then please click File list button, you can see the corresponding files in the list. See Figure 5-109. Figure 5-109 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not...
Page 472 playback and download at the same time. You can use the playback control bar to implement various operations such as play, pause, stop, slow play, fast play and etc. See Figure 5-110. Figure 5-110 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-111.
Page 473 Figure 5-111 HD Transcoding When the bandwidth is limited, you can use this function to transfer the HD bit stream to the specified lower resolution and then playback. It is to reduce network load. In Figure 5-108, select the playback period and then select playback mode and channel(s). Check the box to enable HD transcoding function and then click the Set button;...
Page 474: Alarm
Figure 5-114 Watermark Watermark interface is shown as In Figure 5-113. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-115 5.11 Alarm Click alarm function, you can see an interface is shown as Figure 5-116. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.).
Page 475: Log Out
Figure 5-116 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.
Page 476: Un-Install Web Control
Figure 5-117 5.13 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.
Page 477: Professional Surveillance System
6 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.
Page 478: Faq
7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
Page 479  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged. ...
Page 480  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
Page 481  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
Page 482  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...
Page 483: Daily Maintenance
29. After I connected to the IP channel, there multiple-window output is OK, but there is no one-window output. There are following possibilities:  Check there is video from the IP channel or not. Please go to the main menu->info->System->BPS to view bit stream real-time information. ...
Page 484: Appendix A Hdd Capacity Calculation
Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte. ...
Page 485 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...
Page 486: Appendix B Compatible Backup Devices
Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...
Page 487: Appendix B-2 Compatible Sd Card List
Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small Appendix B-3 Compatible Portable HDD list Brand Model Capacity...
Page 488 Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
Page 489 Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS SATA Seagate Seagate Constellation...
Page 490 Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G SATA Westem Digital...
Page 491 Hitachi HitachiCinemaStar™ HCP725050GLA380 500G SATA 5K500 Hitachi HitachiCinemaStar™ HCT721050SLA360 500G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721075SLA360 750G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...
Page 492: Compatible Cd/Dvd Burner List
Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...
Page 493: Appendix D Compatible Displayer List
Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...
Page 494: Appendix E Compatible Switcher
Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive...
Page 495: Appendix Fcompatible Wireless Mouse List
Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...
Page 496: Appendix G Earthing
Appendix G Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
Page 497  Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
Page 498 conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
Page 499  The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2.  The ground cable of the monitor system can not short circuit or mixed connected with the strong alternative current cable.
Page 500 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.
Page 502: Appendix H Toxic Or Hazardous Materials Or Elements
Appendix H Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...
Page 503 Table of Contents FEATURES AND SPECIFICATIONS ............1 Overview ..........................1 Features ..........................1 Specifications ........................2 DVR-FE032960-DH Series 1.3.3 ..................10 OVERVIEW AND CONTROLS ............... 15 Front Panel ........................15 DVR-FE032960-DH Series 2.1.2 ..................16 Rear Panel ........................19 DVR-FE032960-DH Series 2.2.3 ..................
Page 504 INSTALLATION AND CONNECTIONS ..........31 Check Unpacked DVR ..................... 31 About Front Panel and Rear Panel ................. 31 3.2.1 HDD Installation ......................31 3.2.2 Rack Installation ......................33 Connecting Power Supply ....................33 Connecting Video Input and Output Devices ..............33 3.4.1 Connecting Video Input ....................
Page 505 Startup Wizard ........................41 Manual Record ......................... 44 4.3.1 Live Viewing ......................... 44 Right-Click Menu ......................46 4.4.1 Window Switch ......................46 4.4.2 PIP ..........................47 4.4.3 PTZ Control ........................48 4.4.4 Auto Focus ........................54 4.4.5 Color ..........................54 4.4.6 Search ..........................
Page 506 4.8.1 Search .......................... 62 4.8.2 Backup .......................... 69 4.8.3 Shut Down ........................72 Information ........................72 4.9.1 System Info ........................72 4.9.2 Event..........................76 4.9.3 Network ........................76 4.9.4 Log ..........................79 4.10 Setting ..........................81 4.10.1 Camera ........................81 4.10.2 Network ........................
Page 507 5.8.1 Camera ........................169 5.8.2 Network ........................177 5.8.3 Event........................... 192 5.8.4 Storage ........................202 5.8.5 Setting ........................207 Information ........................223 5.9.1 Version ........................223 5.9.2 Log ..........................223 5.9.3 Connection Log ......................224 5.9.4 Online User ........................ 225 5.10 Playback .........................
Page 508 Appendix B-4 Compatible USB DVD List ................242 Appendix B-5 Compatible SATA DVD List ................242 Appendix B-6 Compatible SATA HDD List ................243 APPENDIX C COMPATIBLE CD/DVD BURNER LIST ......247 APPENDIX D COMPATIBLE DISPLAYER LIST ........248 APPENDIX E COMPATIBLE SWITCHER ........... 249 APPENDIX F COMPATIBLE WIRELESS MOUSE LIST ......
Page 509 Welcome Thank you for purchasing our DVR! This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series hybrid standalone DVR features and functions. Before installation and operation please read the following safeguards and warnings carefully!
Page 510 Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. The product must be grounded to reduce the risk of electric shock. We assume no liability or responsibility for all the fires or electric shock caused by improper handling or installation.
Page 511: Features And Specifications
FEATURES AND SPECIFICATIONS 1.1 Overview The hybrid standalone series DVR is an excellent digital monitor product designed for security field. It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression algorithm and G.711 audio compression technology realize high quality, low bit stream. Unique frame by frame play function is suitable for detailed analysis.
Page 512: Specifications
Client-end user can download the file to local HDD to backup via network. Support eSATA, SATA port backup (eSATA port can connect to burner or HDD, SATA port can connect to burner.)  Record & playback function Support each channel real-time record independently, and at the same time it can support search, forward play, network monitor, record search, download and etc.
Page 513: Dvr-Fe032960-Dh Series
DVR-FE032960-DH Series 1.3.3 32-ch Series Parameter Main High-performance industrial embedded micro controller System Processor Embedded LINUX System Multiplex operations: Multiple-channel record, multiple-channel Resources playback and network operation simultaneously Interface User-friendly graphical user interface Input Devices Front panel, USB mouse, remote control Arabic number, English character, donation and extension Chinese Input Method (optional)
Page 514 Privacy mask Support one privacy mask of user-defined size in full screen. Support max 4 zones. Image Channel information, time information and privacy mask zone. Information TV Adjust Adjust TV output zone suitable to anamorphic video. Channel Lock Cover secret channel with black screen though system is encoding normally.
Page 515 function Support peripheral USB backup device. (Flash disk, portable disk, USB burner and etc.) Support peripheral eSATA backup device. Support network download and save View monitor channel remotely. DVR configuration through client-end and web browser Upgrade via client or browser to realize remote maintenance. Network View alarm information such as external alarm, motion detection and Function...
Page 516 On-line user Display current on-line user User Multi-lever user management; various management modes Management Integrated management for local user, serial port user and network User user. Configurable user power. Management Support user /group and its corresponding rights modification. No limit to the user or group amount. Password modification Administrator can modify other user’s password.
Page 517: Overview And Controls
2 Overview and Controls This section provides information about front panel and rear panel. When you install this series DVR for the first time, please refer to this part first. 2.1 Front Panel DVR-FE032960-DH Series 2.1.2 Name Icon Function Power button, press this button for three seconds to boot up or Power button shut down DVR.
Page 518 Go to previous menu, or cancel current operation. When playback, click it to restore real-time monitor mode. Confirm current operation Enter ENTER Go to default button Go to menu One-window monitor mode, click this button to display assistant function: PTZ control and image color. Backspace function: in numeral control or text control, press it for 1.5 seconds to delete the previous character before the cursor.
Page 519: Rear Panel
2.2 Rear Panel DVR-FE032960-DH Series 2.2.3 The 32-channel series DVR rear panel is shown as below. See Figure 2-5. Figure 2-5 Please refer to the following sheet for detailed information. Icon Name Function Ground port Power switch Power on/off button. VIDEO IN VIDEO IN Video input port...
Page 520 USB2.0 port Connect to mouse, USB storage media, USB-burner and etc. High definition HDMI1 High definition audio and video media interface signal output port. It transmits the same video signal VGA/TV. Support mouse operation. HDMI2 HD video matrix output. Support zero-channel encoding matrix output.
Page 521: Connection Sample
devices such as speed dome communication port PTZ. RS485_B.It is the cable B. You connect control devices such as speed dome PTZ. Alarm input ground end. Alarm input port ground end T+,T-, R+, R- Four-cable T+, T-: Send out cable. full-duplex 485 port.
Page 522: Remote Control
2.4 Remote Control The remote control interface is shown as in Figure 2-7. Please note remote control is not our standard accessory and it is not included in the accessory bag. Figure 2-7 Serial Number Name Function Power button Click it to boot up or shut down the device.
Page 523 In normal playback click this button to pause playback. In real-time monitor mode, click this button to enter video search menu. Reverse/pause Reverse playback pause mode, click this button to realize normal playback. In reverse playback click this button to pause playback. Esc.
Page 524: Mouse Control
2.5 Mouse Control Left click System pops up password input dialogue box if you have not logged in. mouse In real-time monitor mode, you can go to the main menu. When you have selected one menu item, left click mouse to view menu content.
Page 525: Virtual Keyboard & Front Panel
Right click In real-time monitor mode, pops up shortcut menu: one-window, mouse four-window, nine-window and sixteen-window, Pan/Tilt/Zoom, color setting, search, record, alarm input, alarm output, main menu. Among which, Pan/Tilt/Zoom and color setting applies for current selected channel. If you are in multiple-window mode, system automatically switches to the corresponding channel.
Page 526: Installation And Connections
3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 Check Unpacked DVR When you receive the DVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the DVR can protect most accidental clashes during transportation.
Page 527 DVR-FE032960-DH Series 3.2.1.2 This series DVR max supports 8 SATA HDDs. Please use HDD of 7200rpm or higher. 3. Now you can see the bottom 2. Remove the HDD upper Loosen the screws of the bracket bracket upper cover. 4. Line up the HDD to the 5.
Page 528: Rack Installation
7. Unfasten the HDD power Insert the HDD power Use the special data cable to cable. cable. connect the HDD and the SATA port. Close the chassis and fix the screws to secure firmly. Important: If the HDD amount is less than four, you do not need to install the HDD bracket. When there is a bracket, please make sure the installation direction of HDDs is the same.
Page 529: Connecting Video Output
The camera shall be installed in a cool, dry place away from direct sunlight, inflammable, explosive substances and etc. The camera and the DVR should have the same grounding to ensure the normal operation of the camera. Guarantee stability and reliability of the transmission line BTT TB Please use high quality, sound shielded BNC.
Page 530: Alarm Input And Output Connection
3.6 Alarm Input and Output Connection Please read the followings before connecting. 1. Alarm input a. Please make sure alarm input mode is grounding alarm input. b. Grounding signal is needed for alarm input. c. Alarm input needs the low level voltage signal. d.
Page 531 Figure 3-1 Figure 3-2 Figure 3-3 Please refer to the following sheet for detailed information. : 1，2，3，4，5，6， ALARM 1 to ALARM 16. The alarm becomes active in low voltage. 7，8，9，10，11， 12，13，14，15，16 NO1 C1， The first four are four groups of normal open activation output (on/off NO2 C2，...
Page 532: Alarm Input Port
device power to cancel the alarm. +12V It is external power input. Need the peripheral equipment to provide +12V power (below 1A). Earth cable. 485 A/B 485 communication port. They are used to control devices such as decoder. T+,T-,R+,R- They are four-wire double duplex RS485 port T+ T-: output wire R+ R-: input wire 3.6.2 Alarm Input Port...
Page 533 Rating Rated switch capacity 30VDC 2A, 125VAC 1A （Resistance Maximum switch power 125VA 160W Load） Maximum switch voltage 250VAC, 220VDC Maximum switch currency Insulation Between touches with same 1000VAC 1minute polarity 1000VAC 1minute Between touches with different polarity Between touch and winding 1000VAC 1minute Between touches with same Surge voltage...
Page 534: Other Interfaces
Figure 3-5 485 Port Figure 3-6 Figure 3-7 485 Port 3.8 Other Interfaces There are still other interfaces on the DVR, such as USB ports.
Page 535: Overview Of Navigation And Controls
4 Overview of Navigation and Controls 4.1 Boot up and Shutdown 4.1.1 Boot up Before the boot up, please make sure:  The rated input voltage matches the device power on-off button. Please make sure the power wire connection is OK. Then click the power on-off button. ...
Page 536: Startup Wizard
4.2 Startup Wizard After device successfully booted up, it goes to startup wizard. Click Cancel/Next button, you can see system goes to login interface. Tips Check the box Startup button here, system goes to startup wizard again when it boots up the next time.
Page 537 Note: For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Click OK button, you can go to General interface. See Figure 4-3. For detailed information, please refer to chapter 4.10.5.1.
Page 538 Figure 4-4 Click Next button, you can go to Schedule interface. See Figure 4-5. For detailed information, please refer to chapter 4.10.4.1.1. Figure 4-5 Click Finish button, system pops up a dialogue box. Click the OK button, the startup...
Page 539: Manual Record
wizard is complete. See Figure 4-6. Figure 4-6 4.3 Manual Record 4.3.1 Live Viewing After you logged in, the system is in live viewing mode. You can see system date, time, channel name and window No. If you want to change system date and time, you can refer to general settings (Main Menu->Setting->System->General).
Page 540  Support digital zoom function.  Support real-time backup function. You can follow the contents listed below for the operation instruction. Preview control interface Move you mouse to the top centre of the video of current channel, you can see system pops up the preview control interface.
Page 541: Right-Click Menu
Right click mouse to cancel zoom and go back to the original interface. Manual record function It is to backup the video of current channel to the USB device. System can not backup the video of multiple-channel at the same time. Click button , system begins recording.
Page 542: Pip
Figure 4-11 4.4.2 PIP It is to realize picture in picture function in 1-window mode. The small window supports instance playback, digital zoom and etc.  Window switch: Double click the small window, you can switch the position of the large window and the small window.
Page 543: Ptz Control
Figure 4-12 Figure 4-13 Go to the 1-winode mode, on the navigation bar, click , you can see the video on the large window and the video from the next channel is the default video on the small window. If you have set PIP function, you can click to view the last edited PIP video.
Page 544 Please note the commend name is grey once device does not support this function. The PTZ operation is only valid in one-window mode. Here you can control PTZ direction, speed, zoom, focus, iris, preset, tour, scan, pattern aux function, light and wiper, rotation and etc. Speed is to control PTZ movement speed.
Page 545 etc. See Figure 4-16. Figure 4-16 Please refer to the following sheet for detailed information. Please note the above interface may vary due to different protocols. The button is grey and can not be selected once the current function is null. Right click mouse or click the ESC button at the front panel to go back to the Figure 4-14.
Page 546 Figure 4-17 Preset Setup In Figure 4-17, click preset button and use eight direction arrows to adjust camera to the proper position. The interface is shown as in Figure 4-18. Click Set button and then input preset number. Click Set button to save current preset. Figure 4-18 Tour Setup In Figure 4-17, click tour button.
Page 547 Figure 4-19 Pattern Setup In Figure 4-17, click Pattern button and input pattern number. Click Begin button to start direction operation. Or you can go back to Figure 4-14 to operate zoom/focus/iris/direction operation. In Figure 4-17, click End button. Figure 4-20 Scan Setup In Figure 4-17, click Scan button.
Page 548 Figure 4-21 4.4.3.2 Call PTZ Function Call Preset In Figure 4-16, input preset value and then click to call a preset. Click again to stop call. Call Pattern In Figure 4-16, input pattern value and then click to call a pattern. Click again to stop call.
Page 549: Auto Focus
Click , system goes to the following interface. The options here are defined by the protocol. The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-22. Figure 4-22 4.4.4 Auto Focus It is to set auto focus function. Please make sure the camera supports this function. 4.4.5 Color Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
Page 550 Item Note periods. Effective Time Check the box here to enable this function and then set period time. The value here is to adjust the edge of the video. The value ranges from 0 to 100. The larger the value is, the clear the edge is and vice versa.
Page 551: Search
Item Note gentle. Select a color mode, the sharpness, brightness, contrast automatically switch corresponding setup. 4.4.6 Search Please refer to chapter 4.8.1 for detailed information. 4.4.7 Record Control Please refer to chapter 4.10.4.3 for detailed information. 4.4.8 Remote Device Please refer to chapter 4.10.1.1 for detailed information. 4.4.9 Manual Record Please refer to chapter 4.4.9 for detailed information.
Page 552 Figure 4-25 In Figure 4-25, click Add to favorites; you can see the following interface. See Figure 4-26 . Here you can input customized favorites name. System max supports 31-character. Click OK button, you can save current favorites name. Figure 4-26 In Figure 4-25, click Edit favorites;...
Page 553: Channel Tree
Figure 4-27 Double click a name; you can change its name. See Figure 4-28. Input a new name and then click OK button. Figure 4-28 4.5.4 Channel Tree It is to set channel setup. The interface is shown as below. See Figure 4-29.
Page 554: Tour
Figure 4-29 The one level includes 16 channels. See Figure 4-30. You can left click to select a channel on the tree and then drag it to the preview window on the left pane. Once the channel is on the preview window, the channel number on the channel tree becomes grey and it is null now (can not be selected).
Page 555: Search
4.5.8 Search Click button , system goes to search interface. Please refer to chapter 4.8.1 4.5.9 Alarm Status Click button , system goes to alarm status interface. It is to view device status and channel status. Please refer to chapter 4.10.3. 4.5.10 Channel Info Click button , system goes to the channel information setup interface.
Page 556: Usb Device Auto Pop-Up
， system goes to the USB Manager interface. It is to view USB information, Click backup and update. Please refer to chapter 4.8.2, chapter 4.9.4, chapter 4.10.5.10, and chapter 4.10.5.12 for detailed information. 4.6 USB Device Auto Pop-up After you inserted the USB device, system can auto detect it and pop up the following dialogue box.
Page 557: Operation
Figure 4-33 4.8 Operation 4.8.1 Search Click search button in the main menu, search interface is shown as below. See Figure 4-34. Usually there are three file types:  R: Regular recording file.  A: External alarm recording file.  M: Motion detection recording file...
Page 558 Figure 4-34 Please refer to the following sheet for more information. Name Function  Display Here is to display the searched picture or file.  window Support 1/4/9/16-window playback.  Here you can select to search the picture or the recorded file. ...
Page 559  selection In 9-window playback mode, you can switch between 1-8 and 9-16 channels.  pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels.  The time bar will change once you modify the playback mode or the channel option.
Page 560 ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward  In playback mode, click to realize various fast play modes such as fast play 1,fast play 2 and etc.
Page 561  For one device, if there is a backup in process, you can not start a new backup operation.  It is to edit the file. ●Please play the file you want to edit and then click this button when you want to edit.
Page 562 channel This function is null if there is no record file or system is in smart search process. when playback 4.8.1.1 Smart Search During the multiple-channel playback mode, double click one channel and then click the button, system begins smart search. System supports 396(22*18 PAL) and 330(22*15 NTSC) zones.
Page 563  After you searched files, system implement accurate playback once you click Play for the first time.  System does not support accurate playback for picture.  System supports synchronization playback and non-synchronous playback. The synchronization playback supports all channels and non-synchronous playback only supports accurately playback of current select channel.
Page 564: Backup
Here you can set to begin playback from previous N seconds of the mark time. Note Usually, system can playbacks previous N seconds record if there is such kind of record file. Otherwise, system playbacks from the previous X seconds when there is such as kind of record.
Page 565 Client Operation for network download backup operation. Click backup button, you can see an interface is shown as in Figure 4-39. Here is for you to view devices information. You can view backup device name and its total space and free space. The device includes CD-RW, DVD burner, USB device, flash disk, eSATA backup.
Page 566 Figure 4-40 √ before channel name. You can use Fn or cancel System only backup files with a button to delete √ after file serial number. Click Start button, system begins copy. At the same time, the backup button becomes stop button.
Page 567: Shut Down
When the system completes backup, you can see a dialogue box prompting successful backup.  File format: Click the file format; you can see there are two options: DAV/ASF. The file name format usually is: Channel number+Record type+Time. In the file name, the YDM format is Y+M+D+H+M+S.
Page 568 Figure 4-43 4.9.1.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status. See Figure 4-44.  SATA: 1-8 here means system max supports 8 HDDS (It depends on the product you purchased).
Page 569 Figure 4-44 Double click one HDD information; you can see the HDD SMART information. See Figure 4-45. Figure 4-45 4.9.1.2 Record Info It is to view record start time and end time. See Figure 4-46.
Page 570 Figure 4-46 4.9.1.3 BPS Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h). See Figure 4-47. Figure 4-47 4.9.1.4 Version Here is for you to view some version information such as version number, built date, serial number and etc.
Page 571: Event
Figure 4-48 4.9.2 Event It is to display device status and channel status. See Figure 4-49. Figure 4-49 4.9.3 Network...
Page 572 4.9.3.1 Online Users Here is for you to manage online users. See Figure 4-50. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds. System detects there is any newly added or deleted user in each five seconds and refresh the list automatically.
Page 573 Figure 4-51 4.9.3.3 Network Test Network test interface is shown as in Figure 4-52.  Destination IP: Please input valid IPV4 address or domain name.  Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.
Page 574: Log
Figure 4-52 4.9.4 Log Here is for you to view system log file. System lists the following information. See Figure 4-53. Log types include system operation, configuration operation, data management, alarm event, record operation, account manager, log clear, file operation and etc. It optimized reboot log.
Page 575 Figure 4-53 Select an item on the list and then click the Details button or double click the log item, you can view the detailed information such as log time, log type, log user, IP address and etc. See Figure 4-54. Figure 4-54 4.9.4.1 Remote Log In this interface, you can search the IPC log information of the corresponding channel.
Page 576: Setting
select another channel (doe not need to click Search button again), you can view remote connection log. Figure 4-55 4.10 Setting 4.10.1 Camera 4.10.1.1 Remote Device (For digital channel only) 4.10.1.1.1 Remote Device In the main menu, from Camera ->Remote, you can go to an interface shown as in Figure 4-56.
Page 577  Delete: Please select one device in the Added device list and then click remove.  Status: means connection is OK and means connection failed.  Delete；Select a device on the Added device list, click Delete button, system disconnect device first and then remove its name from the list. ...
Page 578 Figure 4-57 4.10.1.1.2 Channel Status Here you can view the IPC status of the corresponding channel such as motion detect, video loss, tampering, alarm and etc. See Figure 4-58.  IPC status: : Front-end does not support. : Front-end supports. There is alarm event from current front-end.
Page 579 Figure 4-59 4.10.1.1.4 Remote Upgrade It is to update the camera. From main menu->setting->camera->remote, the interface is shown as below. See Figure 4-60. Click Browse button and then select the upgrade file. Then select a channel (or you can select device type filter to select several devices at the same time.) Click Start upgrade button to update.
Page 580 4.10.1.2 Image The image interface is shown as below. See Figure 4-61(analog channel) and Figure 4-62(digital channel).  Channel: Select a channel from the dropdown list.  Saturation: It is to adjust monitor window saturation. The value ranges from 0 to 100. The default value is 50.
Page 581  Auto: The auto white balance is on. System can auto compensate the color temperature to make sure the vide color is proper.  Sunny: The threshold of the white balance is in the sunny mode.  Night: The threshold of the white balance is in the night mode. ...
Page 582 Figure 4-62 4.10.1.3 Encode It is to set video bit stream, picture bit stream, video overlay parameter and etc. 4.10.1.3.1 Video Video setting includes the following items. See Figure 4-63.  Channel: Select the channel you want.  Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm.
Page 583 Figure 4-63 4.10.1.3.2 Snapshot Here you can set snapshot mode, picture size, quality and frequency. See Figure 4-64.  Snapshot mode: There are two modes: regular and trigger. If you set timing mode, you need to set snapshot frequency. If you set trigger snapshot, you need to set snapshot activation operation.
Page 584 4.10.1.3.3 Overlay Overlay interface is shown as in Figure 4-65.  Cover area: Here is for you to set cover area. You can drag you mouse to set proper section size. In one channel video, system max supports 4 zones in one channel. ...
Page 585 Figure 4-66 4.10.1.3.4 Channel Name It is to modify channel name. It max supports 31-character. See Figure 4-67. Figure 4-67 4.10.1.3.5 Channel Type It is to set channel type. Each channel supports analog connection/analog HD connection/network camera connection (Slight function difference may be found). The network camera connection shall begin with the last channel.
Page 586: Network
Figure 4-68 4.10.2 Network 4.10.2.1 TCP/IP The single network adapter interface is shown as in Figure 4-69 and the dual network adapters interface is shown as in Figure 4-70  Network Mode : Includes multiple access, fault tolerance, and load balancing ...
Page 587  Main Network Card: Please select eth0/eth1 (optional).after enable multiple access function. Note: Some series support the above three configurations and supports functions as multiple-access, fault-tolerance and load balancing.  IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them.
Page 588 Figure 4-69 Figure 4-70 4.10.2.2 Connection The connection setup interface is shown as in Figure 4-71.  Max connection: system support maximal 128 users. 0 means there is no connection limit.  TCP port: Default value is 37777.  UDP port: Default value is 37778.
Page 589  HTTP port: Default value is 80.  HTTPS port: Default value is 443.  RTSP port: Default value is 554. Important: System needs to reboot after you changed and saved any setup of the above four ports. Please make sure the port values here do not conflict. Figure 4-71 4.10.2.3 WIFI The WIFI interface is shown as below.
Page 590 Figure 4-72  WIFI working status: Here you can view current connection status. Please note:  After successful connection, you can see WIFI connection icon at the top right corner of the preview interface.  When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.
Page 591  AUTH: It is the authentication mode. It supports PAP/CHAP.  Dial number: Please input 3G network dialup number you got from your ISP.  User name: It is the user name for you to login the 3G network.  Password: It is the password for you to login the 3G network.
Page 592 Figure 4-74 4.10.2.6 DDNS Setup DDNS setup interface is shown as in Figure 4-75. You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item.
Page 593 Figure 4-75 Please note NNDS type includes: CN99 DDNS, NO-IP DDNS, Quick DDNS, Dyndns DDNS and sysdns DDNS. All the DDNS can be valid at the same time, you can select as you requirement. Private DDNS function shall work with special DDNS server and special Professional Surveillance Software (PSS).
Page 594  Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.) After successful registration, you can use domain name to login installed of the device IP. ...
Page 595  Default: Click it to restore default setup. In this case, the trusted sites and blocked sites are both null. Note:  If you enabled trusted sites, only the IP in the trusted sites list can access the device.  If you enabled blocked sites, the IP in the blocked sites can not access the device.
Page 596  Title: Please input email subject here. System support English character and Arabic number. Max 32-digit.  Receiver: Please input receiver email address here. System max supports 3 email boxes. System automatically filters same addresses if you input one receiver repeatedly.
Page 597 -> Serv-U Administator. Now you can set user password and FTP folder. Please note you need to grant write right to FTP upload user. See Figure 4-79. Figure 4-79 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to FTP://10.10.7.7 and then test it can modify...
Page 598 After completed channel and weekday setup, you can set two periods for one each channel. Click the Test button, you can see the corresponding dialogue box to see the FTP connection is OK or not. Figure 4-81 4.10.2.10 UPnP The UPNP protocol is to establish a mapping relationship between the LAN and the WAN. Please input the router IP address in the LAN in Figure 4-69.
Page 599 Important: When you are setting the router external port, please use 1024~5000 port. Do not use well-known port 1~255 and the system port 256~1023 to avoid conflict. For the TCP and UDP, please make sure the internal port and external port are the same to guarantee the proper data transmission.
Page 600 You can set in the following interface. See Figure 4-84. Figure 4-84 Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, DVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection.
Page 601 Figure 4-85 Here you can set a multiple cast group. Please refer to the following sheet for detailed information.  IP multiple cast group address -224.0.0.0-239.255.255.255 -“D” address space  The higher four-bit of the first byte=”1110”  Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example...
Page 602: Alarm Centre
Multiple cast PORT: 3666. After you logged in the Web, the Web can automatically get multiple cast address and add it to the multiple cast groups. You can enable real-time monitor function to view the view. Please note multiple cast function applies to special series only. 4.10.2.13 Alarm Centre This interface is reserved for you to develop.
Page 603 Figure 4-87 2) The proxy server software developed from the SDK. Please open the software and input the global setup. Please make sure the auto connection port here is the same as the port you set in the previous step. 3) Now you can add device.
Page 604: Event
Figure 4-88 4.10.3 Event 4.10.3.1 Detect In the main menu, from Setting->Event->Detect, you can see motion detect interface. See Figure 4-89. There are three detection types: motion detection, video loss, tampering.  The video loss has no detection region and sensitivity setup and tampering has no detection region setup.
Page 605 click ENTER button to exit current setup. Do remember click save button to save current setup. If you click ESC button to exit the region setup interface system will not save your zone setup. The analog channel supports 4 zones. For the digital channel, please make sure your network camera supports 4 zones.
Page 606  PTZ activation: Here you can set PTZ movement when an alarm occurs. Such as go to preset, tour &pattern when there is an alarm. Click “select” button, you can see an interface is shown as in Figure 4-91  Record Delay: System can delay the record for specified time after alarm ended.
Page 607 Figure 4-90 Figure 4-91...
Page 608 Figure 4-92 Figure 4-93 Motion detect here only has relationship with the sensitivity and region setup. It has no relationship with other setups. 4.10.3.1.2 Video Loss In Figure 4-89, select video loss from the type list. You can see the interface is shown as in Figure 4-94.This function allows you to be informed when video loss phenomenon occurred.
Page 609 Please refer to chapter 4.10.3.1.1 motion detection for detailed information. Figure 4-94 4.10.3.1.3 Tampering When someone viciously masks the lens, or the output video is in one-color due to the environments light change, the system can alert you to guarantee video continuity. Tampering interface is shown as in Figure 4-95.
Page 610 Figure 4-95 4.10.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. In the main menu, from Setting->Event->Alarm, you can see alarm setup interface. See Figure 4-96. There are four alarm types. See Figure 4-96 to Figure 4-99. ...
Page 611  Period: Click set button, you can see an interface is shown as in Figure 4-101. There are two ways for you to set periods. There are max 6 periods in one day. There are four record types: regular, motion detection (MD), Alarm, MD & alarm. ...
Page 612 activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.  Video matrix: Check the box here to enable this function. When an alarm occurs, SPOT OUT port displays device video output. It displays video (1-window tour) from alarm activation channel you select at the Record channel item.
Page 613 Figure 4-97 Figure 4-98...
Page 614 Figure 4-99 Figure 4-100...
Page 615 Figure 4-101 Figure 4-102 4.10.3.3 Abnormality There are two types: HDD/Network.  HDD: HDD error, no disk, no space. See Figure 4-103 and Figure 4-104.  Network: Disconnection, IP conflict, MAC conflict. See Figure 4-105.  Alarm output: Please select alarm activation output port (multiple choices). ...
Page 616  Latch: Here you can set corresponding delaying time. The value ranges from 1s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.  Show message: system can pop up the message in the local screen to alert you when alarm occurs.
Page 617 Figure 4-104 Figure 4-105...
Page 618: Alarm Output
4.10.3.4 Alarm Output Here is for you to set proper alarm output such as schedule, manual. Please highlight icon to select the corresponding alarm output. After all the setups please click OK button, system goes back to the previous menu. See Figure 4-106.
Page 619  : Click it to delete a record type from one period.  Record Type: Please check the box to select corresponding record type. There are four types: Regular/MD (motion detect)/Alarm/MD&Alarm.  Week day: There are eight options: ranges from Saturday to Sunday and all. ...
Page 620 Figure 4-109 Please highlight icon to select the corresponding function. After completing all the setups please click save button, system goes back to the previous menu. There are color bars for your reference. Green color stands for regular recording, yellow color stands for motion detection and red color stands for alarm recording. The white means the MD and alarm record is valid.
Page 621 Figure 4-110 Figure 4-111 4.10.4.1.1.1 Quick Setup Copy function allows you to copy one channel setup to another. After setting in channel 1, click Copy button, you can go to interface Figure 4-112. You can see current channel name is grey such as channel 1. Now you can select the channel you wan to paste such as channel 5/6/7.
Page 622 Figure 4-112 4.10.4.1.1.2 Redundancy Redundancy function allows you to memorize record file in several disks. When there is file damage occurred in one disk, there is a spare one in the other disk. You can use this function to maintain data reliability and safety. ...
Page 623  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as regular, size, quality and frequency. See Figure 4-114.  In main menu, from Setting->Camera->Encode->Schedule interface, please enable snapshot function. See interface on the right of Figure 4-115. Please refer to the following figure for detailed information.
Page 624 Figure 4-115 4.10.4.1.2.2 Trigger Snapshot Please follow the steps listed below to enable the activation snapshot function. After you enabled this function, system can snapshot when the corresponding alarm occurred.  In main menu, from Setting->Camera->Encode->Snapshot interface, here you can input snapshot mode as trigger, size, quality and frequency.
Page 625 Figure 4-117 Figure 4-118 4.10.4.1.2.3 Priority Please note the activation snapshot has the higher priority than schedule snapshot. If you have enabled these two types at the same time, system can activate the activation snapshot when alarm occurs, and otherwise system just operates the schedule snapshot.
Page 626 In the main menu, from Setting->Network->FTP, you can set FTP server information. Please enable FTP function and then click save button. See Figure 4-119. Please boot up corresponding FTP server. Please enable schedule snapshot (Chapter 4.10.4.1.2.1) or activation snapshot (Chapter 4.10.4.1.2.2) first, now system can upload the image file to the FTP server. Please input corresponding...
Page 627 Figure 4-120 4.10.4.3 Record 4.10.4.3.1 Record Control Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. There are three ways for you to go to manual record menu. ...
Page 628 Figure 4-121 4.10.4.3.2 Snapshot Operation Check the corresponding box to enable/disable schedule snapshot function. See Figure 4-122. Figure 4-122 Tips You can check All button after the corresponding status to enable/disable all-channel snapshot function.
Page 629 4.10.4.4 Advanced It is to set HDD group, and HDD group setup for main stream, sub stream and snapshot operation 4.10.4.4.1 HDD Important HDD group and quota mode can not be valid at the same time. System needs to restart once you change the mode here. The HDD group mode is shown as in Figure 4-123.
Page 630 Figure 4-124 Figure 4-125...
Page 631 Figure 4-126 4.10.4.5 Quota Here you can set channel storage capacity. See Figure 4-127. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 4-127...
Page 632 Click Quota Statistics, you can go to the following interface. You can view HDD capacity you set for each channel. See Figure 4-128. Figure 4-128 4.10.4.6 HDD Detect The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD.
Page 633 Figure 4-129 4.10.4.6.2 Detect Report After the detect operation, you can go to the detect report to view corresponding information. The detect report interface is shown as below. See Figure 4-130. Figure 4-130...
Page 634 Click View, you can see the detailed information such as detect result, backup and S.M.A.R.T. See Figure 4-131 and Figure 4-132. Figure 4-131 Figure 4-132...
Page 635: System
4.10.5 System 4.10.5.1 General 4.10.5.1.1 Device General setting includes the following items. See Figure 4-133.  Device ID: Please input a corresponding device name here.  Device No: Here you can set device number.  Language: System supports various languages: Chinese (simplified), Chinese (Traditional), English, Italian, Japanese, French, Spanish (All languages listed here are optional.
Page 636 Figure 4-133 4.10.5.1.2 Date and Time The interface is shown as in Figure 4-134.  Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY.  Date separator: There are three denotations to separate date: dot, beeline and solidus.  DST: Here you can set DST time and date.
Page 637 Figure 4-134 4.10.5.1.3 Holiday Holiday setup interface is shown as in Figure 4-135. Click Add new holiday button, you can input new holiday information. See Figure 4-136. Here you can set holiday name, repeat mode and start/end time. Note  When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.
Page 638 Figure 4-135 Figure 4-136 4.10.5.2 Display 4.10.5.2.1 Display Display setup interface is shown as below. See Figure 4-137.  Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
Page 639  Channel name: Here is for you to modify channel name. System max support 25-digit (The value may vary due to different series). Please note all your modification here only applies to DVR local end. You need to open web or client end to refresh channel name.
Page 640 Figure 4-138 4.10.5.2.3 Tour Here you can activate tour function. Click Setup button, you can see an interface shown as in Figure 4-139  Enable tour: Highlight box here to enable this function.  Interval: System supports 1/8/-window tour. Input proper interval value here. The value ranges from 5-120 seconds.
Page 641  On the navigation bar, click to enable/disable tour function. Figure 4-139 4.10.5.2.4 Zero-channel Encoding Click zero-channel encoding button, you can go to the following interface. See Figure 4-140.Here you can enable and set zero-channel encoding function so that you can view several video sources at one channel.
Page 642 Figure 4-140 4.10.5.3 Video Matrix 4.10.5.3.1 BNC Here you can set matrix output channel and its interval. System supports 1/4-window (and etc) SPOT tour. See Figure 4-141.
Page 643 Figure 4-141 4.10.5.3.2 HDMI This function is for some series only. The HDMI interface is shown as in Figure 5-85. It is to set the HD video matrix output tour function of the HDMI port 2. You can set tour channel, resolution, and interval. System support 1/4-window tour.
Page 644 Figure 4-142 4.10.5.4 RS232 RS232 interface is shown as below. There are five items. See Figure 4-143.  Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboar d is for you to control the device via the special keyboard.
Page 645 Figure 4-143 4.10.5.5 PTZ The pan/tilt/zoom setup includes the following items. Please select channel first. See Figure 4-144.  PTZ type: There are two options: local/remote. Please select remote if you are connecting to the network PTZ.  Protocol: Select corresponding PTZ protocol such as PELCOD. ...
Page 646 Figure 4-144 4.10.5.6 ATM/POS The ATM/POS function is for financial areas. It includes Sniffer, information analysis and title overlay function. The Sniffer mode includes COM and network. 4.10.5.6.1 COM Type The COM interface is shown as below. See Figure 4-145. ...
Page 647 Figure 4-145 4.10.5.6.2 Network Type The network type interface is shown as below. See Figure 4-146. Here we take the ATM/POS protocol to continue. There are two types: with or without the protocol according to client’s requirements. With the protocol For ATM/POS with the protocol, you just need to set the source IP, destination IP (sometimes you need to input corresponding port number).
Page 648 Without the protocol For the ATM/POS without the protocol, the interface is shown as in Figure 4-147. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 649 Figure 4-148 Click Add button, you can add audio file and import the audio file via the USB device. See Figure 4-149. Figure 4-149 4.10.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods.
Page 650 Figure 4-150 4.10.5.8 Account Here is for you to implement account management. See Figure 4-151. Here you can:  Add new user  Modify user  Add group  Modify group  Modify password. For account management please note:  For the user account name and the user group, the string max length is 6-byte.
Page 651  About user account and MAC. When you add a new user, you can input the MAC address of current user. Only the user of the same MAC address can access the device remotely.(MAC address is for the device of the same LAN.) If you leave MAC address item in blank when you add a new user, the user of any MAC address can access the device remotely.
Page 652 4.10.5.8.1 Add/Modify Group Click add group button, the interface is shown as below. See Figure 4-152. Here you can input group name and then input some memo information if necessary. There are total 98 rights such as control panel, shut down, real-time monitor, playback, record, record file backup, PTZ, user account, system information view, alarm input/output setup, system setup, log view, clear log, upgrade system, control device and etc.
Page 653: Auto Maintain
Click add user button, the interface is shown as in Figure 4-153. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.
Page 654 Figure 4-154 4.10.5.10 Config Backup The configuration file backup interface is shown as below. See Figure 4-155. This function allows you to import/export system configuration. You can use this function when there are several devices need the same setup.  Export: Please connect the peripheral device first and then go to the following interface.
Page 655 Figure 4-155 4.10.5.11 Default Click default icon, system pops up a dialogue box. You can highlight to restore default factory setup. See Figure 5-26.  Camera  Network  Event  Storage  System Please highlight icon to select the corresponding function. After all the setups please click save button, system goes back to the previous menu.
Page 656 Figure 4-156 4.10.5.12 Update Here is for you to view hardware features, software version, built date, release SN information and etc. You can also update system here. See Figure 4-48.  Start: Please insert the USB device that have the update file to the device and then click the Start button to begin the update.
Page 657: Login
5 WEB OPERATION Slightly difference may be found in the interface due to different series. 5.1 Network Connection Before web client operation, please check the following items:  Network connection is right  DVR and PC network setup is right. Please refer to network setup(main menu->Setting->Network) ...
Page 658 Figure 5-2 5.3 LAN Mode For the LAN mode, after you logged in, you can see the main window. See Figure 5-3. Figure 5-3 This main window can be divided into the following sections.  Section 1: there are five function buttons: Live（chapter 5.4）, setup (chapter 5.8), search (chapter 5.10), alarm (chapter 5.11), and logout (chapter 5.12).
Page 659  Section 2: There are channel number and one button: Start all. Start all button is to enable/disable all-channel real-time monitor. Click it the button becomes yellow. See Figure 5-4. Figure 5-4 Please refer to Figure 5-5 for main stream and extra stream switch information. Figure 5-5 ...
Page 660 Figure 5-8  Section 6: From the left to the right ,you can see video quality/fluency/ full screen/1-window/4-window/6-window/8-window/9-window/13-window/16-window/20- window/25-window/36-window.. You can set video fluency and real-time feature priority.  Section 7: PTZ operation panel. Please refer to chapter 5.5 for detailed information. ...
Page 661: Ptz
 1: Digital zoom: Click this button and then left drag the mouse in the zone to zoom in. right click mouse system restores original status.  2: Local record. When you click local record button, the system begins recording and this button becomes highlighted.
Page 662: Image
Parameter Function You can turn on or turn off the light/wiper. Light and wiper 3D Intelligent Positioning You can click this icon to display or hide the PTZ control platform. Figure 5-11 5.6 Image/Relay-out Select one monitor channel video and then click Image button in section 8, the interface is shown as Figure 5-12.
Page 663 Figure 5-13 5.7 WAN Login In WAN mode, after you logged in, the interface is shown as below. See Figure 5-14. Figure 5-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default.
Page 664: Setup
Figure 5-15 Important The window display mode and the channel number are by default. For example, for the 16-channel, the max window split mode is 16. 3) Multiple-channel monitor, system adopts extra stream to monitor by default. Double click one channel, system switches to single channel and system uses main stream to monitor.
Page 665 Figure 5-16 Figure 5-17 Please refer to the following sheet for log parameter information. Parameter Function Click Device search button, you can view the searched device Device search information on the list. It includes device IP address, port, device name, manufacturer and type. Select a device in the list and then click Add button, system can connect the device automatically and add it to the Added device list.
Page 666 Parameter Function Delete Click , you can delete the remote connection of the corresponding channel. : Connection succeeded. Connection status : Connection failed. Delete Select a device in the Added device list and then click Delete button, system can disconnect the device and remove it from the Added device list.
Page 667 Figure 5-19 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Period It divides one day (24 hours) to two periods. You can set different hue, brightness, and contrast for different periods. It is to adjust monitor video brightness and darkness level.
Page 668 Gain The gain adjust is to set the gain value. The smaller the value is, the low the noise is. But the brightness is also too low in the dark environments. It can enhance the video brightness if the value is high.
Page 669 video according to the device feature (The general bright of the video or there is IR light or not.)  B/W: The device outputs the black and white video.  Sensor: It is to set when there is peripheral connected IR light.
Page 670 dropdown list. Please note the option may vary due to different series. Frame Rate PAL：1～25f/s；NTSC：1～30f/s.  Bit Rate Main stream: You can set bit rate here to change video quality. The large the bit rate is , the better the quality is. Please refer to recommend bit rate for the detailed information.
Page 671 Click it; you can copy current channel setup to other channel(s). Copy 5.8.1.3.3 Video Overlay The video overlay interface is shown as in Figure 5-22. Figure 5-22 Please refer to the following sheet for detailed information. Parameter Function Cover-area Check Preview or Monitor first. Click Set button, you can privacy mask the specified video in the preview or monitor video.
Page 672 Please click the Save button to save current setup. Figure 5-23 5.8.1.4 Channel Name Here you can set channel name. See Figure 5-24. Please note this function is for analog channel only. Figure 5-24 5.8.2 Network 5.8.2.1 TCP/IP The TCP/IP interface is shown as in Figure 5-25. Figure 5-25 Please refer to the following sheet for detailed information.
Page 673 DHCP mode to auto search the IP.  If you select the static mode, you need to set the IP/submask/gateway manually.  If you select the DHCP mode, you can view the IP/submask/gateway from the DHCP.  If you switch from the DHCP mode to the static mode, you need to reset the IP parameters.
Page 674 number if necessary. HTTP port The default value is 80. You can input the actual port number if necessary. HTTPS The default value is 443. You can input the actual port number if necessary. RTSP port The default value is 554. 5.8.2.3 WIFI Please note this function is for the device of WIFI module.
Page 675 Please refer to the following sheet for detailed information. Parameter Function WLAN type Here you can select 3G network type to distinguish the 3G module from different ISP. The types include WCDMA， CDMA1x and etc. APN/Dial No. Here is the important parameter of PPP. Authorization It includes PAP,CHAP,NO_AUTH.
Page 676 Figure 5-30 5.8.2.6 DDNS The DDNS interface is shown as in Figure 5-31. The DDNS is to set to connect the various servers so that you can access the system via the server. Please go to the corresponding service website to apply a domain name and then access the system via the domain.
Page 677 2) Function Introduction The quick DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only. You need to refresh the bonding relationship of the domain and the IP regularly.
Page 678 5.8.2.8 Email The email interface is shown as in Figure 5-33. Figure 5-33 Please refer to the following sheet for detailed information. Parameter Function Please check the box here to enable email function. Enable Input server address and then enable this function. SMTP Server Port Default value is 25.
Page 679 Parameter Function function is very useful when there are too many emails activated by the abnormity events, which may result in heavy load for the email server. Please check the box here to enable this function. Health mail enable This function allows the system to send out the test email to Update period check the connection is OK or not.
Page 680 Figure 5-35 5.8.2.11 SNMP The SNMP interface is shown as in Figure 5-36. The SNMP allows the communication between the network management work station software and the proxy of the managed device. It is reserved for the 3 party to develop. Figure 5-36 Please refer to the following sheet for detailed information.
Page 681 Parameter Function and one group of the managers. Please make sure the device and the proxy are the same. The read community will read/write/access all the objects the SNMP supported in the specified name. The default setup is write. The destination address of the Trap information from the proxy Trap address program of the device.
Page 682 5.8.2.14 Alarm Centre The alarm centre interface is shown as below. See Figure 5-39. This interface is reserved for you to develop. System can upload alarm signal to the alarm centre when local alarm occurs. Before you use alarm centre, please set server IP, port and etc. When an alarm occurs, system can send out data as the protocol defined, so the client-end can get the data.
Page 683 Figure 5-41 You can see the corresponding prompt. See Figure 5-42. Now the server certificate is successfully created. Figure 5-42 5.8.2.15.2 Download root certificate In Figure 5-40, click button, system pops up a dialogue box. See Figure 5-43. Figure 5-43 Click Open button, you can go to the following interface.
Page 684 Figure 5-44 Click Install certificate button, you can go to certificate wizard. See Figure 5-45. Figure 5-45 Click Next button to continue. Now you can select a location for the certificate. See Figure 5-46.
Page 685 Figure 5-46 Click Next button, you can see the certificate import process is complete. See Figure 5-47. Figure 5-47 Click Finish button, you can see system pops up a security warning dialogue box. See Figure 5-48.
Page 686 Figure 5-48 Click Yes button, system pops up the following dialogue box, you can see the certificate download is complete. See Figure 5-49. Figure 5-49 5.8.2.15.3 View and set HTTPS port From Setup->Network->Connection, you can see the following interface. See Figure 5-50. You can see HTTPS default value is 443.
Page 687 5.8.3 Event 5.8.3.1 Video detect 5.8.3.1.1 Motion Detect The motion detect interface is shown as in Figure 5-51. Figure 5-51 Figure 5-52...
Page 688 Figure 5-53 Figure 5-54 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable motion detection function. Please select a channel from the dropdown list.
Page 689 Parameter Function Period Motion detection function becomes activated in the specified periods. See Figure 5-52. There are six periods in one day. Please draw a circle to enable corresponding period. Click OK button, system goes back to motion detection interface, please click save button to exit.
Page 690 Here you can set PTZ movement when alarm occurs. Such as go Activation to preset X. See Figure 5-54. Video Matrix This function is for motion detect only. Check the box here to enable video matrix function. Right now system supports one-channel tour function.
Page 691 Figure 5-56 5.8.3.2 Alarm Before operation, please make sure you have properly connected alarm devices such as buzzer. The input mode includes local alarm and network alarm. 5.8.3.2.1 Local Alarm The local alarm interface is shown as in Figure 5-57. It refers to alarm from the local device.
Page 692 Figure 5-58 Figure 5-59 Please refer to the following sheet for detailed information. Parameter Function Enable You need to check the box to enable this function. Please select a channel from the dropdown list. Period This function becomes activated in the specified periods. There are six periods in one day.
Page 693 Parameter Function whole week. Click OK button, system goes back to local alarm interface, please click save button to exit. System only memorizes one event during the anti-dither Anti-dither period. The value ranges from 5s to 600s. There are two options: NO/NC. Sensor type Record channel System auto activates motion detection channel(s) to...
Page 694 Figure 5-60 5.8.3.2.3 IPC External Alarm IPC external alarm interface is shown as below. See Figure 5-61. For setup information, please refer to chapter 5.8.3.2.1. Figure 5-61 5.8.3.2.4 IPC Offline Alarm IPC offline alarm is shown as in Figure 5-62 . For setup information, please refer to chapter 5.8.3.2.1.
Page 695 Figure 5-62 5.8.3.3 Alarm Output It is to set alarm output mode. See Figure 5-63. Figure 5-63 5.8.3.4 Abnormality It includes two types: HDD error/Network error. HDD error: No disk, disk error, disk no space. See Figure 5-64 and Figure 5-65. Network error: Net disconnection, IP conflict and MAC conflict.
Page 696 Figure 5-64 Figure 5-65 Figure 5-66 Please refer to the following sheet for detailed information. Parameter Function Event The abnormal events include: No disk, disk error, disk no space, net Type disconnection, IP conflict and MAC conflict. You can set one or more items here. Less than: You can set the minimum percentage value here (For disk not space only).
Page 697 Parameter Function Show System can pop up a message to alarm you in the local host screen if message you enabled this function. Alarm System can upload the alarm signal to the centre (Including alarm upload centre. Send If you enabled this function, System can send out an email to alert you Email when an alarm occurs.
Page 698 Figure 5-68 Figure 5-69 Please refer to the following sheet for detailed information. Parameter Function Channel Please select a channel from the dropdown list. Pre-record Please input pre-record time here. The value ranges from 0 to 30.
Page 699 Parameter Function Redundancy Check the box here to enable redundancy function. Please note this function is null if there is only one HDD. Snapshot Check the box here to enable snapshot function. Holiday Check the box here to enable holiday function. Setup Click the Setup button, you can set record period.
Page 700 Figure 5-71 5.8.4.3 Manual Record The interface is shown as in Figure 5-72. Figure 5-72 Please refer to the following sheet for detailed information. Parameter Function Here you can view channel number. Channel The number displayed here is the max channel amount of your device.
Page 701 5.8.4.4.1 Main Stream The main stream interface is shown as in Figure 5-73. Here you can set corresponding HDD group to save main stream. Figure 5-73 5.8.4.4.2 Sub Stream The sub stream interface is shown as in Figure 5-74. Here you can set corresponding HDD group to save sub stream. Figure 5-74 5.8.4.4.3 Snapshot The snapshot interface is shown as in Figure 5-75.
Page 702 5.8.4.5 Quota It is to set channel storage capacity. See Figure 5-76. Select a channel from the dropdown list and then select corresponding HDD quota. Figure 5-76 5.8.5 Setting 5.8.5.1 General The general interface includes general, date/time and holiday setup. 5.8.5.1.1 General The general interface is shown as in Figure 5-77.
Page 703 Standard Here is for you to select working mode when hard disk is full. There HDD full are two options: stop recording or rewrite. If current working HDD is overwritten or the current HDD is full while the next HDD is no empty, then system stops recording, If the current HDD is full and then next HDD is not empty, then system overwrites the previous files.
Page 704 Holiday setup interface is shown as in Figure 5-79. Here you can click Add box to add a new holiday and then click Save button to save. Figure 5-79 5.8.5.2 Display Display interface includes GUI, TV adjust, Tour and zero-channel encoding. 5.8.5.2.1 GUI Here you can set background color and transparency level.
Page 705 Figure 5-81 5.8.5.2.3 Tour The tour interface is shown as in Figure 5-82. Here you can set tour interval, split mode, motion detect tour and alarm tour mode. Figure 5-82 Please refer to the following sheet for detailed information. Parameter Function Check the box here to enable tour function.
Page 706 Figure 5-83 Please refer to the following sheet for detailed information. Parameter Function This function is disabled by default. Check the box here to enable Enable this function so that you can control the zero-channel encoding function at the WEB. Compression System default setup is H.264.
Page 707 Figure 5-84 5.8.5.3.2 HDMI This function is for some series only. The HDMI interface is shown as in Figure 5-85. It is to set the HD video matrix output tour function of the HDMI port 2. You can set tour channel, resolution, and interval. System support 1/4-window tour.
Page 708 The RS232 interface is shown as in Figure 5-86. Figure 5-86 Please refer to the following sheet for detailed information. Parameter Function Select the corresponding dome protocol. Protocol Default setup is console. Select the baud rate. Baud Rate Default setup is 115200. Data Bit The value ranges from 5 to 8.
Page 709 Figure 5-87 Please refer to the following sheet for detailed information. Parameter Function Select speed dome connected channel. Channel There are two modes:Local/remote. PTZ type Please select corresponding protocol from the dropdown list. Protocol Set corresponding dome address. Default value is 1. Please note Address your setup here shall comply with your dome address;...
Page 710  Overlay mode: There are two options: preview and encode. Preview means overlay the card number in the local monitor video. Encode means overlay the card number in the record file.  Overlay Position: Here you can select the proper overlay position from the dropdown list.
Page 711 For the ATM/POS without the protocol, the interface is shown as in Figure 5-90. Source IP refers to host IP address that sends out information (usually it is the device host.) Destination IP refers to other systems that receive information. Usually you do not need to set source port and target port.
Page 712 Figure 5-92 5.8.5.7.2 Schedule It is to set schedule broadcast function. You can play the different audio files in the specified periods. See Figure 5-93. Figure 5-93 5.8.5.8 Account Note:  For the character in the following user name or the user group name, system max supports 6-digits.
Page 713  User management adopts group/user modes. The user name and the group name shall be unique. One user shall be included in only one group. 5.8.5.8.1 User name In this interface you can add/remove user and modify user name. See Figure 5-94. Figure 5-94 Add user: It is to add a name to group and set the user rights.
Page 714 Figure 5-95 Modify user It is to modify the user property, belonging group, password and rights. See Figure 5-96. Modify password It is to modify the user password. You need to input the old password and then input the new password twice to confirm the new setup. Please click the OK button to save. Please note, the password ranges from 1-digit to 6-digit.
Page 715 Figure 5-96 5.8.5.8.2 Group The group management interface can add/remove group, modify group password and etc. The interface is shown as in Figure 5-97. Figure 5-97 Add group: It is to add group and set its corresponding rights. See Figure 5-98. Please input the group name and then check the box to select the corresponding rights.
Page 716 includes: shutdown/reboot device, live view, record control, PTZ control and etc. Figure 5-98 Modify group Click the modify group button, you can see an interface is shown as in Figure 5-99. Here you can modify group information such as remarks and rights. Figure 5-99...
Page 717 5.8.5.9 Auto maintain The auto maintain interface is shown as in Figure 5-100. Here you can select auto reboot and auto delete old files interval from the dropdown list. If you want to use the auto delete old files function, you need to set the file period. Click Manual reboot button, you can restart device manually.
Page 718: Information
5.8.5.12 Upgrade The upgrade interface is shown as in Figure 5-103. Please select the upgrade file and then click the update button to begin update. Please note the file name shall be as *.bin. During the upgrade process, do not unplug the power cable, network cable, or shutdown the device.
Page 719: Connection Log
Figure 5-105 Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type operation, event operation, record operation, user management, log clear. Set the start time of the requested log. Start time Set the end time of the requested log.
Page 720: Online User
Figure 5-106 5.9.4 Online User The online user interface is shown as in Figure 5-107. Figure 5-107 5.10 Playback Click Playback button, you can see an interface is shown as in Figure 5-108. Please set record type, record date, window display mode and channel name. You can click the date on the right pane to select the date.
Page 721 Figure 5-108 Then please click File list button, you can see the corresponding files in the list. See Figure 5-109. Figure 5-109 Select a file you want to play and then click Play button, system can begin playback. You can select to playback in full-screen. Please note for one channel, system can not...
Page 722 playback and download at the same time. You can use the playback control bar to implement various operations such as play, pause, stop, slow play, fast play and etc. See Figure 5-110. Figure 5-110 Select the file(s) you want to download and then click download button, you can see an interface shown as in Figure 5-111.
Page 723 Figure 5-111 HD Transcoding When the bandwidth is limited, you can use this function to transfer the HD bit stream to the specified lower resolution and then playback. It is to reduce network load. In Figure 5-108, select the playback period and then select playback mode and channel(s). Check the box to enable HD transcoding function and then click the Set button;...
Page 724: Alarm
Figure 5-114 Watermark Watermark interface is shown as In Figure 5-113. Please select a file and then click Verify button to see the file has been tampered with or not Figure 5-115 5.11 Alarm Click alarm function, you can see an interface is shown as Figure 5-116. Here you can set device alarm type and alarm sound setup (Please make sure you have enabled audio function of corresponding alarm events.).
Page 725: Log Out
Figure 5-116 Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Tampering System alarms when camera is viciously masking. Disk full System alarms when disk is full.
Page 726: Un-Install Web Control
Figure 5-117 5.13 Un-install Web Control You can use web un-install tool “uninstall web.bat” to un-install web control. Please note, before you un-installation, please close all web pages, otherwise the un-installation might result in error.
Page 727: Professional Surveillance System
6 Professional Surveillance System Besides Web, you can use our Professional Surveillance Software (PSS) to login the device. For detailed information, please refer to PSS user’s manual.
Page 728: Faq
7 FAQ 1. DVR can not boot up properly. There are following possibilities:  Input power is not correct.  Power connection is not correct.  Power switch button is damaged.  Program upgrade is wrong.  HDD malfunction or something wrong with HDD ribbon. ...
Page 729  DVR and monitor resistance is not compatible.  Video transmission is too long or degrading is too huge.  DVR color or brightness setup is not correct. 6. Can not search local records. There are following possibilities:  HDD ribbon is damaged. ...
Page 730  PTZ decoder setup, connection or installation is not correct.  Cable connection is not correct.  PTZ setup is not correct.  PTZ decoder and DVR protocol is not compatible.  PTZ decoder and DVR address is not compatible. ...
Page 731  MAC address conflict.  PC or DVR network card is not good. 16. Burn error /USB back error. There are following possibilities:  Burner and DVR are in the same data cable.  System uses too much CPU resources. Please stop record first and then begin backup.
Page 732  Camera quality is too low. Lens is dirty. Camera is installed against the light. Camera aperture setup is not correct.  HDD capacity is not enough.  HDD is damaged. 22. Can not playback the downloaded file. There are following possibilities: ...
Page 733 29. After I connected to the IP channel, there multiple-window output is OK, but there is no one-window output. There are following possibilities:  Check there is video from the IP channel or not. Please go to the main menu->info->System->BPS to view bit stream real-time information. ...
Page 734: Appendix A Hdd Capacity Calculation
Appendix A HDD Capacity Calculation Calculate total capacity needed by each DVR according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte. ...
Page 735 448K 196M 512K 225M 640K 281M 768K 337M 896K 393M 1024K 450M 1280K 562M 1536K 675M 1792K 787M 2048K 900M...
Page 736: Appendix B Compatible Backup Devices
Appendix B Compatible backup devices Appendix B-1 Compatible USB list Manu factor Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Freedom Sandisk Cruzer Freedom DataTraveler Ⅱ Kingston DataTraveler Ⅱ...
Page 737: Appendix B-2 Compatible Sd Card List
Kingston Data Traveler 32GB Aigo L8315 16GB Sandisk 16GB Kingston Data Traveler Locker+ 32GB Netac U228 Appendix B-2 Compatible SD Card list Brand Standard Capacity Card type Transcend SDHC6 16GB Kingston SDHC4 Kingston Kingston Sandisk SDHC2 Small Sandisk Small Appendix B-3 Compatible Portable HDD list Brand Model Capacity...
Page 738 Samsung TS-H653 Ver.F Samsung SH-224BB/CHXH SONY DRU-V200S SONY DRU-845S SONY AW-G170S Pioneer DVR-217CH Appendix B-6 Compatible SATA HDD List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. Here we recommend HDD of 500G to 4T capacity. Port Manufacturer Series...
Page 739 Seagate Seagate Pipeline HD2 ST31000322CS SATA Seagate Seagate Pipeline HD2 ST1000VM002 SATA Seagate Seagate Pipeline HD2 ST1500VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM002 SATA Seagate Seagate Pipeline HD2 ST2000VM003 SATA Seagate Seagate Constellation ST3500514NS 500G SATA Seagate Seagate Constellation ST31000524NS SATA Seagate Seagate Constellation...
Page 740 Westem Digital Cariar SE WD2500JS 250G SATA Westem Digital Cariar SE16 WD7500KS 750G SATA Westem Digital Cariar SE16 WD5000KS 500G SATA Westem Digital Cariar SE16 WD4000KD 400G SATA Westem Digital Cariar SE16 WD3200KS 320G SATA Westem Digital Cariar SE16 WD2500KS 250G SATA Westem Digital...
Page 741 Hitachi HitachiCinemaStar™ HCP725050GLA380 500G SATA 5K500 Hitachi HitachiCinemaStar™ HCT721050SLA360 500G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721075SLA360 750G SATA 7K1000.B Hitachi HitachiCinemaStar™ HCT721010SLA360 SATA 7K1000.B Maxtor DiamondMax 20 STM3320820AS 320G SATA Maxtor DiamondMax 20 STM3250820AS 250G SATA...
Page 742 Appendix C Compatible CD/DVD Burner List NOTE: Please upgrade the DVR firmware to latest version to ensure the accuracy of the table below. And you can use the USB cable with the model recommended to set USB burner. Manufacturer Model Port Type Type Sony...
Page 743: Appendix D Compatible Displayer List
Appendix D Compatible Displayer List Please refer to the following sheet form compatible displayer list. Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch HFNOVO（LCD） LXB-L17C 17-inch 22 寸(wide screen) SANGSUNG（LCD）...
Page 744: Appendix E Compatible Switcher
Appendix E Compatible Switcher Brand Model network working mode D-LinK DES-1016D 10/100M self-adaptive D-LinK DES-1008D 10/100M self-adaptive Five network modes 1. AUTO 2. HALF-10M Ruijie RG-S1926S 3. FULL-10M 4 .HALF-100M 5. FULL-100M H3C-S1024 10/100M self-adaptive TP-LINK TL-SF1016 10/100M self-adaptive TP-LINK TL-SF1008+ 10/100M self-adaptive...
Page 745: Appendix Fcompatible Wireless Mouse List
Appendix F Compatible Wireless Mouse List Please refer to the following sheet for compatible SD card brand. Brand Model Rapoo 3500 Logitech M215 Shuangfeiyan Tianyao G7-630...
Page 746: Appendix G Earthing
Appendix G Earthing 1. What is the surge? Surge is a short current or voltage change during a very short time. In the circuit, it lasts for microsecond. In a 220V circuit, the 5KV or 10KV voltage change during a very short time (about microseconds) can be called a surge.
Page 747  Signal lightning arrester: This device is mainly used in the PC network, communication system. The connection type is serial connection. Once you connected the signal lightning arrestor with the signal port, it can cut the channel of the thunderstorm to the device, and on the other hand, it can discharge the current to the ground to guarantee the device proper work.
Page 748 conductance of the ground conductor. In the high-frequency circuit, you need to use the multiple-point ground mode and each cable needs to connect to the ground. The length shall be less than the 1/20 of the signal wavelength. Mixed ground: The mix ground consists of the feature of the one-point ground and multiple-point ground.
Page 749  The thunder proof ground shall adopt the special ground cable from the monitor control room to the ground object. The ground cable adopts copper insulation cable or wire and its ground section shall be more than 20mm2.  The ground cable of the monitor system can not short circuit or mixed connected with the strong alternative current cable.
Page 750 For L (live cable) Turn the digital multimeter to 750V AC, use your one hand to hold the metal end, and then the other hand insert the pen to the L port of the socket. See the following figure. If the multimeter shows 120, then you can see current live cable connection is standard.
Page 752: Appendix H Toxic Or Hazardous Materials Or Elements
Appendix H Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...

This manual is also suitable for:

Dvr-fe032960-dh

Techpro Federal Series User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Techpro Federal Series

Summary of Contents for Techpro Federal Series
