- Page 1 HTTP://WWW.SUNCTI.CO.TH User Manua User Manual S03 Series IP Phone Version 1.1 Contents Catalogue...
-
Page 2: Table Of Contents
HTTP://WWW.SUNCTI.CO.TH User Manua 1 INTRODUCTION....................3 2 INSTALLATION.....................3 2.1 Appearance..........................3 2.2 Package List ........................4 2.3 Installation..........................4 2.4 Check installation by ICON of LCD..................4 3 PRODUCT OVERVIEW ..................5 3.1 Software Features.........................5 3.2 Hardware Specifications ......................6 4 BASIC OPERATIONS....................6 4.1 Get familiar with Keypad.....................6 4.2 Dialing or Making Calls.......................6... -
Page 3: Introduction
Notice This publication describes the instruction for S03 series IP phone functions only. We reserve the rights to do any changes or make enhancements of this publication without further notice. The most updated electronic revision of user manual can be downloaded from WISH’s website: www.wishproduct.com timely, thanks for your understanding and continuous support. -
Page 4: Package List
3) One universal power adapter 4) One User Manual Warning: Although the adapter of S03 series IP Phone is compliant with UL standard, please do not attempt to use other difference power adapter or cut off power supply during configuration or updating phone. Using other power adapter may damage S03 series phone and will void the manufacturer warranty. -
Page 5: Product Overview
Product Overview S03 IP Phone is a next generation IP network telephone based on industry open standard SIP (Session Initiation Protocol) and H.323.Built on innovative technology, S03 series IP Phone offer customer superb sound quality and rich functionalities at mass-affordable price. -
Page 6: Basic Operations
HTTP://WWW.SUNCTI.CO.TH User Manua Certification CE / FCC Part 15 Class B BASIC OPERATIONS 4.1 Get Familiar with Keypad S03 phone has a 25-button keypad. Definitions of each state as below Key Button Mode Definitions Key Button Mode Definitions Decimal digit number 0-9, star and pound keys... -
Page 7: Answering Calls
HTTP://WWW.SUNCTI.CO.TH User Manua send out the numbers with the DTMF tones. 2. In the off hook mode or Hands-free mode, Press the REDIAL button directly to redial the number last called. Once pressed, the last dialed number will be displayed on the LCD with DTMF tones and an outgoing call is sent. -
Page 8: Call Transfer
HTTP://WWW.SUNCTI.CO.TH User Manua 4.5 Call transfer Press the XFER button enables users could transfer an incoming call to transfer the incoming call to the third party’s number. When both sides are on conversation, users could inform the called person to announce the call will be transferred and then press the XFER button, dial another telephone number when you hear the dial tone, then the incoming call will be transferred to another line and users conclude the previous telephone conversation. -
Page 9: Config Ip Phone Through Web Browser
HTTP://WWW.SUNCTI.CO.TH User Manua 2. Router Configuration 1． Gateway Address 3. DNS Server 4. Call Manager 3. Password 1. Enter Password 4. Reboot 1. Reboot Now 2. Reboot Later Press the button select list item Press”*” Sound clew Number Function User Input... -
Page 10: User Verification
HTTP://WWW.SUNCTI.CO.TH User Manua 5.2.2 User verification Users are requested to make verification when config or browse the IP phone thru web pages, users can direct login the config menu by inputting username and password as below , Guest account: both default username and password are “guest”, enable users to browse IP Phone parameter with low-level user interface Administrator account: both default username and password are “admin”, enable users to... -
Page 11: Voip Configuration
HTTP://WWW.SUNCTI.CO.TH User Manua Default network config is static model; Users need to set below parameters LAN Configuration This web page displays the LAN parameter configuration. Please note once the bridging mode is selected, the LAN configuration will be no longer effective. - Page 12 HTTP://WWW.SUNCTI.CO.TH User Manua Definition of each parameter described as below SIP[Unregistered] SIP register state ； if register successfully, show “Registered” Configuration in the square bracket ， otherwise show Unregistered Register Server address Set SIP register server IP address Set proxy server IP address（usually SIP will provide the same...
- Page 13 HTTP://WWW.SUNCTI.CO.TH User Manua to RFC3261； DTMF Mode Set DTMF sending mode User Agent Set the user agent if have, default is common Enable Register Configure enable/disable register Auto Detct Server Set the phone enables to detect server automatically Enable Pub Outbound...
-
Page 14: System Reboot
HTTP://WWW.SUNCTI.CO.TH User Manua 5.2.5. System Reboot Once any change of phone configuration is made, users need to reset IP phone to go into effect. Users should save the modified configuration before system reboot, otherwise the phone system configuration will go back to last saved setting. The system reboot interface as below CODECS Setup 5.2.6... -
Page 15: System Manage
HTTP://WWW.SUNCTI.CO.TH User Manua 5.2.7 System Manage 1. Account Manage Users can edit users (add or delete) account and modify existing users’ authority on this web page. 2. Time Set Setting time zone and SNTP (Simple Network Time Protocol) server according to users location, users could manual adjust date and time on this web page. -
Page 16: Web Update
HTTP://WWW.SUNCTI.CO.TH User Manua Add one new account Click “Add” button →input User name (No-Modify) →Choosing User level from dropdown menu →set new user password →confirm password account info, return to account configuration interface by clicking “Change Password” button Owing to the phone's default account：accounts of the administrator level-admin account and the ordinary level－guest account are all weak account and weak password, the username and... -
Page 17: Firmware Upgrade
HTTP://WWW.SUNCTI.CO.TH User Manua On this page, user can select the upgrade document (firmware or config file) from hard disk of the computer directly to run the system upgrade. After upgrade completed ， reset the phone and it will be usable immediately. -
Page 18: Default Factory Setting
HTTP://WWW.SUNCTI.CO.TH User Manua 7. Default Factory Setting Gain IP address thru DHCP mode, the static IP address of WAN Port is 192.168.1.176, the IP address of LAN port is 192.168.10.1.Default is to start the DHCP service and NAT function. Default communication protocol is to use SIP, SIP port is 5060 Default HTTP port is 80, Telnet port is 23 Default number end is “#”... - Page 19 HTTP://WWW.SUNCTI.CO.TH User Manua...
