Summary of Contents for Suncti S01
- Page 1 User Manual IP Phone Version 1.0...
-
Page 2: Table Of Contents
User Manual HTTP://www.suncti.co.th CONTENT 1 INTRODUCTION...........ERROR! BOOKMARK NOT DEFINED. 2 INSTALLATION.............ERROR! BOOKMARK NOT DEFINED. 2.1 Installation .................. Error! Bookmark not defined. 2.2 Connection diagrams............... Error! Bookmark not defined. 2.3 Package ..................Error! Bookmark not defined. 2.4 Key introduction................ Error! Bookmark not defined. - Page 3 User Manual HTTP://www.suncti.co.th 6.7.6.2Public Backup Server Configuration ..............30 6.7.6.3Private Server(SIP2) Configuration..............30 6.7.7 Digital Map Configuration....................30 6.7.8 Call Service Configuration ..................31 6.7.9 MMI Filter .........................35 6.7.10 DSP Configuration ......................35 6.8 Dial Peer ............................36 6.9 Config Manage (Save and Clear configuration) ..............38 6.10 Firmware Upgrade ........................39...
- Page 4 User Manual HTTP://www.suncti.co.th 1 Introduction Welcome to select our IP Phone and thanks for your trust and support to our company. We sincerely hope you can enjoy the convenience and capabilities brought forward by our products. IP Phone provides all the features and functionalities of conventional phone and more. Our IP phone...
- Page 5 User Manual HTTP://www.suncti.co.th 2 Installation 2.1 Installation Insert handset cord into the handset jack and the other end to the left jack of IP Phone Insert the power adapter’s plug into the phone Power jack and the 2-prong plug end of which into...
-
Page 6: Package
User Manual HTTP://www.suncti.co.th 2.3 package Unpacking the package of IP Phone and please clearly check the box contents according to below packing list .If you find any contents missing or damaged, contact the place of purchase. Components Packing List Components... - Page 7 User Manual HTTP://www.suncti.co.th Key Button Mode Definitions Three flexible In the IDLE mode or Select the relevant function on the LCD Function Keys In the keypad configure mode HOLD In the keypad Temporarily hold the active call configure mode Transfer...
-
Page 8: Product Overview
User Manual HTTP://www.suncti.co.th 3 Product Overview S01 IP Phone is a next generation IP network telephone based on industry open standard SIP (Session Initiation Protocol).S01 series IP Phone offer customer superb sound quality and rich functionalities at mass-affordable price. 3.1 Software Features Support two modes: Bridge and Router (NAT&NAPT) -
Page 9: Hardware Specifications
User Manual HTTP://www.suncti.co.th 3.2 Hardware Specifications The below table describes the hardware specifications of S01 Phone Item Power Adapter Input: 100-240VAC 50~60Hz Output: +5VDC, 1200mA Infineon PSB21553 150MHz Port 10/100Base T RJ-45 for LAN 10/100Base T RJ-45 for PC Power Consumption Idle:1.4W / Active:1.8W... -
Page 10: Basic Operations
User Manual HTTP://www.suncti.co.th 4 Basic Operations 4. 1 Dialing and Making Calls 4.1.1Dialing General PSTN Phone or Extension. There are three dialing modes: 1. Pick up handset or press SPEAKER button, and then enter the phone numbers, IP phone will send out the numbers with the DTMF tones. -
Page 11: Answering Calls
User Manual HTTP://www.suncti.co.th Example 1 If A dial number 187 , A can talk with B . If B dial number 155 , B can talk with A 4.2 Answering Calls There are three ways to receive incoming calls: Pick up handset to receive incoming calls... -
Page 12: Three-Way Calling
B will talk with C. 4.5 Three-Way Calling S01 IP phone support three-way (or conference) Calling. That is users could talk to more than one person (up to two) at the same time. Process: press HOLD button →Dial third party’s number->put through→ press HOLD button again →Press * button... -
Page 13: Keypad Configuration
User Manual HTTP://www.suncti.co.th 5 keypad configuration Hereinabove the manual has defined the keypad function. It is easy to config IP phone thru the keypads. Get the assigned WAN Port IP, gateway’s IP and the phone number registered on public server: Press the Down Key for three times. -
Page 14: Greeting Message Setting
User Manual HTTP://www.suncti.co.th 5.3.1 Ringer Volume Setting Select Enter. The LCD displays 01 Ringer Volume Adjust the ringer volume by pressing Left Key or Right Key Select Save Finished. 5.3.2 Call Part Volume Select Enter. The LCD displays 01 Call Party Volume... -
Page 15: Network Setting
User Manual HTTP://www.suncti.co.th Press the Down Key once. The LCD displays 02 SIP 1 Number Select Edit. Enter the SIP 1 Number Select Save Finished. SIP Account Setting Return to 01 SIP 1 Press the Down Key twice. The LCD displays 03 SIP 1 Account Select Edit. -
Page 16: Ring Type Setting
User Manual HTTP://www.suncti.co.th Select Enter and go into WAN port network setting. Press the Down Key and go into the Static Setting. The LCD displays 02 Static Setting the LCD displays 01 Static IP Select Enter Select Edit . Enter the Static IP. -
Page 17: Voice Record
User Manual HTTP://www.suncti.co.th 5.9 Check the Callers Record You can check the incoming calls, outgoing calls and missed calls by pressing Callers 5.9.1 Voice Record Voice record while calling Press Rec. Press Stop to stop the record. Notice: You can make voice record for 20 minutes. -
Page 18: Web Configuration
User Manual HTTP://www.suncti.co.th 6.0 Web Configuration 6.1 Physical Connection 6.2 Preparation for Web Configuration The IP Phone Web Configuration Menu can be accessed by the following URI: http://Phone-IP-Address. The IP address can be set to either WAN IP address or LAN IP address, default factory setting of WAN configuration is DHCP Client model, default LAN IP address is “192.168.10.1”. - Page 19 User Manual HTTP://www.suncti.co.th Method 1 Method2 d) Input “cmd” command on the RUN submenu under PC START, key in “ipconfig/all on the command lines dialog box to find the default gateway IP address, which is LAN IP address of IP Phone.
-
Page 20: User Verification
User Manual HTTP://www.suncti.co.th 6.3 User verification Users are requested to make verification when config or browse the IP phone thru web pages, users can direct login the config menu by inputting username and password as below: Default username and password is:... -
Page 21: Network Configuration
User Manual HTTP://www.suncti.co.th 6.5 Network Configuration Network configuration includes WAN Config and LAN Config. 6.5.1 WAN Configuration This web page displays the WAN parameter configuration. Display <valid MAC >, that means the phone had been certificated. Display <invalid MAC>, that means the phone need a Mac Authenticating Code .(get it from Fanvil or your provider ) Display <invalid MAC, that means the phone can not work normally. - Page 22 User Manual HTTP://www.suncti.co.th automatically with immediate effect. If users visit IP Phone thru WAN, it need to input “ipconfig” command to get the new IP address and copy it to web browser bar to visit IP Phone. Connect network to internet thru DHCP mode Select “DHCP”...
-
Page 23: Lan Configuration
User Manual HTTP://www.suncti.co.th 6.5.2 LAN Configuration This web page displays the LAN parameter configuration. Please note once the bridging mode is selected, the LAN configuration will be no longer effective. Configuration Example Config LAN: generally config one private IP address... -
Page 24: Voip Configuration
Proxy Password Set password of SIP register account Domain Realm Enter the sip domain if any, otherwise S01 will use the proxy server address as sip domain. (Usually it is same with registered server and proxy server IP address). Local SIP Port Set local signal port，the default is 5060... - Page 25 Time. Enable this option, S01 will periodically detect whether the public SIP server is available, if the server is unavailable, the S01 will switch to the back-up SIP sever, and continue detecting the public sip server. S01 will switch back to the primary SIP server if the server is available again.
-
Page 26: Advance
6.7 Advance 6.7.1 DHCP Server Configuration When S01 work as a router, this config is for S01 LAN port network device DNS Relay: DNS relay acts as a forwarder between the DNS Clients and the DNS Servers, DNS relay is designed for home/office networks where the users might want to dial into more than one Internet Service Provide (ISP) DHCP server manage page. -
Page 27: Nat Service Configuration
User Manual HTTP://www.suncti.co.th network to access registered networks, such as the Internet, without requiring a registered subnet address. This eliminates the need for host renumbering and allows the same IP address range to be used in multiple intranets. With NAT, the inside network continues to use its existing private or obsolete addresses. -
Page 28: Firewall
Access list support two type limits: input_access limit or output_access limit. Each type support 10 items maximum. S01 firewall filter is base WAN port. So the source address or input destination address should be WAN port IP address. Configuration:... -
Page 29: Qos 802.1P Configuration
Internet. QoS Enable: Enable QoS service. QoS Table: enable include QoS table, S01 will only provide QoS service to the network address included in the QoS table. Disable the option. S01 provides QoS service to the network address outside the QoS table. -
Page 30: Advance Sip Configuration
User Manual HTTP://www.suncti.co.th To show the phone whether has been registered on public server or private server SIP STUN Configuration: STUN can support SIP terminal's penetration to NAT in the inner-net. In this way， as long as there is conventional SIP proxy and a STUN server placed in the public net, it will do;... -
Page 31: 2Public Backup Server Configuration
User Manual HTTP://www.suncti.co.th The specific configuration parameter has the same meaning with public server. It should be noted that the username and password should be the same with the public main server. Private Server(SIP2) Configuration. Specific configuration parameter has the same meaning with public server. -
Page 32: Call Service Configuration
User Manual HTTP://www.suncti.co.th Digit map is a set of rules to determine when the user has finished dialing. Digital Map is based on some rules to judge when user end their dialing and send the number to the server. With digital map, users don’t have to press ‘#’ key or "call"key after dialing. - Page 33 User Manual HTTP://www.suncti.co.th Value added service configuration On this page, user can set value added services such as hot-line，call forwarding， call transfer (CT)，call-waiting service，three way call，blacklist，out-limit list and so 6.7.8.1 Hotline Configure hot-line number of the port. With this number of the port，this hot-line number will be dialed automatically as soon as off-hook and user can's dial any other number.
- Page 34 SPEAKER button and start to record leaving message. Generally, these four option are selected together If it is enabled, the caller will hear S01 automatically play prompt message (welcome message.) User can define only one prompt message (welcome message) that can be played when someone call the phone.
- Page 35 User Manual HTTP://www.suncti.co.th back to the previous call. If you want to use three way conference , this option must be enabled. 6.7.8.2.3 Call Transfer Configuration It is for enabling or disabling phone <TRANSFER> button transferring function. If it is enabled, when user A are talking with user B , A press <TRANSFER>...
-
Page 36: Mmi Filter
MMI filter is used to make access limit toS01. When MMI filter is enable. Only IP address within the start IP and end IP can access S01. 6.7.10 DSP Configuration On this page, user can set speech coding，IO volume control, cue tone standard, caller ID standard and so on. -
Page 37: Dial Peer
User Manual HTTP://www.suncti.co.th Configure hand-down time，that is, if the hooking time is shorter than this time, then the gateway will not consider the user has hand-down. VAD: Enable/disable Voice Activity Detection 6.8 Dial Peer Number IP Table Configuration Function of number IP table is one way to implement the phone's calling online, and the calling of the phone will be more flexible by configuration the number IP table. - Page 38 User Manual HTTP://www.suncti.co.th make the call. When configuring the prefix matching, letter "T" should be added behind the prefix number to be distinguished from the exactitude matching. Configure the calling mode：H323 and SIP. Configure destination address，if it is point-to-point call，then input the opposite terminal's IP address, it can also be set as domain name and resolved the specific IP address by DNS server of the phone.
-
Page 39: Config Manage (Save And Clear Configuration)
User Manual HTTP://www.suncti.co.th It can be used for speed calling User dial 2 The number user dialed will be replaced fully by Sip1 server receive 33334444 the number that is behind all: (not all) Here alias is It can be used to add local area or prefix. before User dial 8309 sending out. -
Page 40: Firmware Upgrade
User Manual HTTP://www.suncti.co.th The interface of “Save Config” as below, please follow the four steps below to config. Enter “Config Manage” Menu →“Save Config” Submenu→ Click “Save” Button→ Return to “Current State” Web page 6.9.2 Clear Config There are four method to clear config (set factory default), web 、 telnet 、 post mode、... -
Page 41: Ftp Or Tftp Update
User Manual HTTP://www.suncti.co.th STEP: Enter Update menu →WEB Update submenu→ click “browse” button→ download upgrade document from hard disk (firmware or config file provided by manufacturer) → click “Update” button →reboot IP phone to go into effect Note: Under system upgrade progress, IP Phone may not be restarted normally due to some system reason (e.g. - Page 42 Example: (export config file) 1 FTP <1> Copy Wftpd32 software and S01 Firmware into a new Folder ( example c:/tmp) <2> Run wftd32.exe. Set a user name and password for S01 ftp updating The process is like the below picture showing from step 1 to step 13.
-
Page 43: System Manage
User Manual HTTP://www.suncti.co.th Update the firmware Download config file to you pc. After it update successfully. You will find After you click apply , you can find the the new version in Current State file that it had download to your pc <c:\temp>... - Page 44 User Manual HTTP://www.suncti.co.th Keypad password Set keypad operation config password, default is 123,users can input new password then click “apply” button ,”submit success” info will show on screen, reset password successfully User Name List existing phone user account name User Level...
-
Page 45: Phone Book Configuration
User Manual HTTP://www.suncti.co.th password, the username and password will be easily to guess on public network, so the user had better modify the administrator and ordinary user. Enter with manager level when making modification，create a administrator account and a browse account (you'd better not set the name as admin, administrator, guest, etc.)，... -
Page 46: Syslog Configuration
User Manual HTTP://www.suncti.co.th Users can star or close syslog function and config syslog server IP address & port. Syslog Configuration Definition of each parameter described as below Enable Syslog Config enable/disable syslog function, choose it and then click “Apply” button to go into effect... -
Page 47: System Reboot
User Manual HTTP://www.suncti.co.th Manual Time set Manual set date and time 6.11.5 System Reboot Once any change of phone configuration is made, users need to reset IP phone to go into effect. Users should save the modified configuration before system reboot, otherwise the phone system configuration will go back to last saved setting. - Page 48 User Manual HTTP://www.suncti.co.th Gain IP address thru DHCP mode, WAN Port static IP is 192.168.1.179, LAN port IP is 192.168.10.1.Default is to start the DHCP service and NAT function. Default communication protocol is to use SIP, SIP port is 5060 Default HTTP port is 80, Telnet port is 23 Default number end is “#”...
-
Page 49: Telnet Setting
8.2.1 Basic Structure User may use telnet command to access and manage gateway. S01 adopts tree structure for telnet. Every node contains its sub-nodes or local command. User can type “help” or “?” whenever to see sub-nodes and all local command under current node. -
Page 50: Global Command
User Manual HTTP://www.suncti.co.th 8.3 Global Command Global command is available under all nodes, S01 support following commands. Command Command function Example Name chinese Set the language of help prompt info #chinese to Chinese clear Clear screen #clear english Set the language of help prompt info... -
Page 51: Net Configuration
User Manual HTTP://www.suncti.co.th 8.4 Net Configuration 8.4.1 LAN interface Settings Path: <config-interface-fastethernet-lan># Function Command [disable]enable bridge mode [no]bridgemode [disable]enable DHCP service [no]dhcp-server [disable]enable NAT [no]nat Show current DHCP rules dhcpshow Show LAN port IP address ipshow Show NAT info natshow Change LAN port IP address ip –addr x.x.x.x –mask x.x.x.x... -
Page 52: Port Settings
User Manual HTTP://www.suncti.co.th <config-netservice>#route –gateway 202.112.10.1 –addr 202.112.210.1 –mask 255.255.255.0 8.6 Port Settings path: <config-port># Function Command set caller ID mode Caller ID xxx disable caller ID no caller ID Disable call forward no callforward [disable]enable call transfer [no]call transfer... -
Page 53: Debug (Level 0~7)
User Manual HTTP://www.suncti.co.th Note: The command : –user xxx –access digit Here if the digit is less 10 , then the user level is guest If the digit is more that 10 ,then the user level is administrator 8.9 Debug (Level 0~7) path: <debug>#... -
Page 54: Logout
# update ftp –user xxx –password xxx –ip x.x.x.x –file xxx # update tftp –ip x.x.x.x –file xxx Example: # update ftp –user abc –password 123 –ip 202.112.20.15 –file S01.z 8.14 Upload Configure File usage: # upload ftp –user xxx –password xxx –ip x.x.x.x –file xxx # upload tftp –ip x.x.x.x –file xxx... -
Page 55: Restore To Factory Default
#setdefault (clear gateway settings expect network part) #setdefault all (clear all settings.) 8.20 POST Mode(safe mode) 8.20.1 Access Post Mode Process 1 PC connect to S01 LAN port 2 power off 3 press # and power on till the LCD display POST MODE 4 telnet 192.168.10.1 5 config page as below 8.20.2 Post Mode Clear... -
Page 56: Post Mode Ftp Update Firmware
8.20.3 Post Mode FTP Update Firmware Input 2 for update firmware S01 provide safe mode. When there is booting problem because of setting problem or firmware problem. User can restore the factory setting or upgrade to a new firmware to solve this problem.
