- Page 1 Platinum CCTV Surveillance Solutions CD-8361 Indoor/Outdoor Day/Night Long-Range IR Varifocal Camera with Sony 700 TVL CCD Installation Manual Outdoor Varifocal Hi-Res Day/Night Infrared CCD Armor Dome Camera with Sony EFFIO® DSP Http:// Platinum-CCTV.com...
-
Page 2: Camera Installation
Platinum CCTV Surveillance Solutions Camera Installation Camera Mounting: Items Needed: Screwdriver, Drill, Mounting Hardware (not included), Pencil Rotate the collar of the camera counter-clockwise to loosen and remove. Place the bracket on the wall or ceiling and mark to drill holes. Mount bracket to wall or ceiling. - Page 3 Platinum CCTV Surveillance Solutions Camera Installation Reinstall camera ball onto the bracket and adjust camera to the proper angle then re-tighten camera collar to hold the camera solid. Adjust Zoom/Focus with 2 adjustment screws Note: BOTH adjustments need to be adjusted.
- Page 4 Platinum CCTV Surveillance Solutions CD-8361 Long Range IR CCD Camera Image Sensor 1/3” Sony® ExView HAD II CCD Number of Pixels NTSC: 768 (H) x 494 (V) Scanning System 15.7343Khz (H), 60 Hz (V) Sony® EFFIO® Resolution 700 TVL Lens 2.8-12mm Varifocal Lens...
