Instructions for use

Hartenberger

Underwater Hand Lamp

compact

professional

Table of Contents

Need help?

Do you have a question about the compact and is the answer not in the manual?

Questions and answers

Summary of Contents for Hartenberger compact

Page 1 Instructions for use Hartenberger Underwater Hand Lamp compact professional...
Page 2: Table Of Contents
Hartenberger Underwater Hand Lamp compact / professional Instructions for use ONTENTS AFETY ARNING UARANTEE PPLICATIONS RTICLE ESCRIPTION ECHNICAL PECIFICATIONS RONT OUSING OWER REPARATION FOR USE SING THE NDERWATER FTER USE RANSPORT TORAGE HARGING ARE AND AINTENANCE ERVICE AULT IAGNOSIS CCESSORIES...
Page 3: Article Description
Hartenberger Underwater Hand Lamp compact / professional Instructions for use RTICLE ESCRIPTION OUSING 1. Front Ring 2. Front O-Ring seal 3. Housing 4. Rear O-Ring seal 5. Rear Ring 6. Magnetic Switch 7. Transport Safety Pin Diagram 1 RONT The front sealing ring must be removed to access the rechargeable cell pack for charging and/or to replace the halogen bulb.
Page 4 Hartenberger Underwater Hand Lamp compact / professional Instructions for use OWER 1. Reflector 2. Halogen Bulb 3. Spare O-Ring 4. Spare Halogen Bulb Holder 5. Plug-In Electronic Control Panel 6. Charging socket Diagram 2 EFLECTOR The reflector is pressed on to the power pack and can be removed by simply pulling the reflector away from the power pack.
Page 5: Technical Specifications
(11 in x 4 in) (8 lbs 9 oz) (3 lbs 4 oz) ESISTANCE TO WATER PRESSURE We guarantee that all Hartenberger lamps are pressure proof to a depth well in excess of 200 meters (650 feet). RONT LASS LATE The professional lamps have a special borosilicate glass plate as standard.
Page 6: Power Pack
Hartenberger Underwater Hand Lamp compact / professional Instructions for use be used for the removal of the O-Ring, i.e. a wooden tooth pick. Should the sealing surfaces and/or components be contaminated, then the O-Ring and its groove should be thoroughly cleaned and lubricated with a light coating of silicone grease.
Page 7: Using The Underwater Lamp
Hartenberger Underwater Hand Lamp compact / professional Instructions for use If the bulb has been removed for transport, it should be refitted into the socket. • The transport safety pin should be removed from the magnetic switch immediately before the lamp is used.
Page 8: After Use
Hartenberger Underwater Hand Lamp compact / professional Instructions for use ISCHARGE PROTECTION After the lamp warns of the immanent loss of power, (the lamp will blink continuously off and on), the lamp should be turned off as soon as possible. The dive should be terminated as soon as possible to avoid total loss of illumination.
Page 9: Storage
Hartenberger Underwater Hand Lamp compact / professional Instructions for use TORAGE The lamp should be stored in a fully charged condition with the housing closed securely. An ideal storage temperature is between 15 and 25°C, (60 and 75°F). Under no circumstances should the lamp be subjected to temperatures above 45°C, (110°F).
Page 10 Hartenberger Underwater Hand Lamp compact / professional Instructions for use discharge the cells before charging. We regard this as being more harmful for underwater lamps with between 5 and 20 cells. The constant discharge down to the cut-off voltage limit can overload individual cells and disrupt the balance within the matched cell pack.
Page 11 45 - 65 Hz. (There is no need to manually select the input voltage). All Hartenberger power packs with between 5 and 12 cells will be automatically recognised by the charger, and charged as fast as possible. The charging current can reach 2.0 amps.
Page 12: Care And Maintenance
Hartenberger Underwater Hand Lamp compact / professional Instructions for use • Chargers other than that supplied with this lamp must be checked by a qualified electrician for compatibility before attempting to use them. The guarantee will be lost due to improper use.
Page 13: Service
Hartenberger Underwater Hand Lamp compact / professional Instructions for use ERVICE Action to be taken Interval By Owner Workshop Impregnate Housing After repeated use surface Clean and lubricate After the housing is opened Front O-Ring Replace Front O-Ring 1-2 years or after 200 dives...
Page 14 Hartenberger Underwater Hand Lamp compact / professional Instructions for use LED II illuminates red Charger protection switch Unplug the mains cable and active. allow 3 minutes to cool down. Reconnect the mains cable.
Page 15: Accessories
Hartenberger Underwater Hand Lamp compact / professional Instructions for use ONDUCT ESET If the lamp is not operated correctly or when the power pack is removed from the housing, the entire electronic circuitry will turn over to a self protection mode. The lamp cannot be inadvertently activated or operated in this condition.
Page 16 Hartenberger Underwater Hand Lamp compact / professional Instructions for use...
Page 17: Parts
Hartenberger Underwater Hand Lamp compact / professional Instructions for use PEAR ARTS Seal Dimensions Elasticity Material Glass Outer 88 mm x 3.0 mm 70° Shore Viton, Blue Glass Inner 90 mm x 2.0 mm 70° Shore Viton, Blue Front Housing 78 mm x 2.5 mm...
Page 18 Hartenberger Underwater Hand Lamp compact / professional Instructions for use info@hartenberger.de www.hartenberger.de...
