Sanyo MCD-Z8F Service Manual

Sanyo MCD-Z8F Service Manual

Cd portable stereo radio cassette recorder
Hide thumbs Also See for MCD-Z8F:

Advertisement

/////
Service Manual
I
Specifications
(CASSETTE
SECTION)
Recording
System
. . . . . . . .
Erasing System
. . . . . . . . . .
Tape speed
. . . . . . . . . . . . .
Fast forward and
rewind time
. . . . . . . . .
Frequency
response
. . . . . . .
(CD SECTION)
Channel
. . . . . . . . . . . . . . . .
S/Nratio
. . . . . . . . . . . . . . .
Wow&Flutter
. . . . . . . . . . .
Sampling
frequency
. . . . . . .
Quantization
. . . . . . . . . . . . .
Pickup light source
. . . . . . . .
Pickup wavelength
. . . . . . .
Laser Output
. . . . . . . . . . . .
sqjlwiio
FILE NO.
.#l
CD Portable
Stereo
Radio
MCD-Z8F
(AU)
Cassette
Recorder
AC bias, 4 track stereo
Magnet erase
4.75 cm I sec.
110 sec. (C-60 tape)
80-12,000
Hz (Normal Tape)
2 channel
70 dB
Undetectable
44.1 kHz
16 bits linear / ch
Semi-conductor
laser
790 nm
Continuous
wave max. 0.6 mW
PRODUCT
CODE
No.
142
993
02
(RADIO
SECTION)
Tuning
range
. . . . . . . . . . . .
Antenna
. . . . . . . . . . . . . . . .
(GENERAL)
Power
output(UK)
. . . . . . . . .
Speaker
. . . . . . . . . . . . . . . .
Terminal
impedance
(UK)
. . .
Power
source
. . . . . . . . . . . .
Dimensions
. . . . . . . . . . . . .
Weight
(approx.)
. . . . . . . . . .
FM:
88-108
MHz
AM :
525-1,710
kHz
FM:
Telescopic
rod
AM:
Built-in ferrite bar
4.0 W / ch (DC max.)
12cm
x2,40hms
PIEZO X 2
PHONES :32 ohms
AC :230-
240V, 50 Hz
DC:12V
(8 "D" size batteries)
556x170x220
mm
(W XHXD)
3.3 kg (without batteries)
Specifications
subject to change
without notice,
REFERENCE
No.
SM580495
