Atom 730 Operator Owner's Manual

MULTI INTERNATIONAL GOLD MEDALS &
AWARD WINNING LAWN EDGERS & TILLERS
TILLER/MULCHER
Gasoline Model 730, 740, 750
Safety Precautions
Operating and Tilling/Mulching Instructions
Important Manual - Do Not Throw Away
Manual always to be available for reference or
instructing new operators.
Introduction: Gasoline Tiller
This Atom Gasoline Tiller is designed to the highest standards
to ensure you many hours of uninterrupted service. Pay
special attention to the safety precautions. Only persons
who understand this Manual are to operate the Tiller.
To receive maximum performance and satisfaction from
your Tiller, it is important that you read and understand the
maintenance and safety precautions before using the unit.
Contact your Atom dealer or the Atom distributor in your
area if you do not understand or cannot carry out any of the
operating instructions in this Manual.
Atom's philosophy is to continually improve all of its products.
As a result, engineering changes and improvements are made
from time to time. Appearances may differ between models.
This manual covers information required to operate, maintain
and service this gasoline Tiller.
AS WITH ANY POWER TOOL IMPROPER USE CAN CAUSE
SERIOUS INJURY. Make sure this manual is read and carefully
understood before starting or operating this equipment.
! SAFETY WARNING
this Manual is to attract your attention to possible dangers and
deserve your careful attention and understanding. The Safety
Warnings in this Manual and on the Tiller do not, by themselves,
eliminate any danger. The instructions or warnings they give are
not substitutes for proper accident prevention measures.
Failure to obey a safety warning can
! WARNING
result in injury to yourself and others.
Advises you of information or instructions vital
! NOTE
to the operation or maintenance of the equipment.
SAFETY WARNING LABELS
FIG 2
Wear eye
protection
Read operators
Do not expose
manual
motor to moisture
ATOM Tillers have Australian and foreign Patents, Patent Pending, and Design Registrations.
Assembling
The purpose of Safety
Warnings and Notes in
15m (50 feet)
Keep bystanders Blade cover label
away
ACN 000 583 924
Service
Contents
Safety Precautions ............................................. 2
Assembling the Tiller ...........................................2
Parts and Controls ............................................. 3
Fuel Mix and Fuelling ........................................ 3
Furrow Plow ..................................................... 3
Starting and Stopping Instructions ....................... 4
Using Your Tiller ................................................ 4
Troubleshooting ................................................ 5
Lubrication of Gears .......................................... 6
Air and Fuel Filter Maintenance .......................... 6
Repair Throttle Trigger ....................................... 6
Carburettor Adjustments ..................................... 6
Tines Maintenance, Removal & Tightening ............ 7
Tiller Parts List ....................................................7
Warranty ......................................................... 7
Tiller Parts Illustration ......................................... 8
The information contained in this manual is also
available at www.atomindustries.com
Operator /
Owner Manual
63901MA-11
1711
FIG 1
MADE IN AUSTRALIA
PAGE
