BRS BioLock Quick Start Manual

Fingerprint Door Security Kit Quick Start Guide
Head Office
Unit 11, Building F, 16 Mars Road,
Lane Cove, NSW 2066 Australia
Tel: +61 2 9882 8600
Fax: +61 2 9427 2503
Freecall: 1800 421 616
sales@brsgrp.com
Multiple Patents Pending
Designed, developed &
manufactured in Australia
www.brsgrp.com
BioAccess ® ,BioTime ® ,BioLock ® ,BioScan ® and BioNet ® are all
trademarks of Bio Recognition Systems Pty Ltd. All information
shown on this brochure is deemed to be accurate at time of printing.
Bio Recognition System Pty Ltd reserves the right to change any
specification and pricing without notice including discontinuing
manufacture.
© Copyright 2005 by Bio Recognition Systems Pty Ltd. All rights
®
reserved. Printed in Australia. Reference BRS-BioLock Rev1.0.
AVAILABLE COLOURS
SATIN BLACK
GLOSS STAINLESS STEEL
Fingerprint Door Security Kit Quick Start Guide
®
Your BioLock kit includes the following components:
• BioLock device
• Metal mounting backplate
• Secure I/O electronics board (SIOB)
• Secure I/O enclosure
• Power plugpack
• 2 cable assemblies (BRS-819-32-3/5)
• Electric door strike
• Door strike power cable (red/black)
• Screw pack including security screw, screw allen
key, wall plugs, wall mounting screws, sealing
grommet and diode
• Documentation including this Quick Start Guide,
wiring diagram, and door strike template
If any item is missing please contact the outlet
where you purchased the kit.
Tools that you will need to install this kit:
• Drill
• Chisel
• Screwdrivers (Phillips and standard)
Overview:
BioLock is a fingerprint access controller designed
to operate in outdoor and indoor environments. The
fingerprint sensor uses a radio-frequency technology
penetrating below the epidermis to read even damaged
or dirty fingers. BioLock can be used stand-alone, with
internet/web access, running a Windows™ interface, or any
combination of these.
BioLock can be used to control any electrical device,
including lighting, security systems and of course doors.
