- Page 1 Installation Guide HSL Poly Series...
-
Page 2: Table Of Contents
ADDITIOnAL InFORMATIOn DISCLAIMER OF LIABILITY The installation techniques, handling and use of the product are beyond company control. Therefore, Hanwha Solar assumes no responsibility for loss, damage or expense resulting from improper installation, handling or misuse. Ensure that the module is used only in applications for which it is suitable (see “Mounting Instructions”). All work on a PV system (installation, setup, maintenance) must be carried out only by appropriately qualified and authorized engineers. -
Page 3: Introduction
INTRODUCTION PURPOSE OF THIS GUIDE Hanwha Solar is a leading manufacturer of silicon ingots, This guide contains important information wafers, PV cells and modules, delivering reliable products regarding the installation, safe handling at competitive pricing on a global scale. We provide... -
Page 4: System Design
SYSTEM DESIGN Before installing your solar system, contact local authorities to determine the necessary permit, installation and inspection requirements that must be followed. System should be installed by qualified personnel only. The system involves electricity, and can be dangerous if the personnel are not familiar with the appropriate safety procedures. -
Page 5: Mounting Instructions
Keep in mind, different modules, mounting systems, and building materials do have different thermal expansion coefficients. Hanwha Solar recommends a minimum distance of 20 mm between modules •... - Page 6 MOUNTING INSTRUCTIONS Maximum Load/Pressure Extended Maximum 4000 7000 Static Load IEC Products HSL60P6-PB-1-xxx (W/B) 140mm 140mm Moun,ng h oles Moun,ng h oles 250mm 250mm UL Products Moun,ng h oles Moun,ng h oles HSL60P6-PB-0-xxxT (W/B) HSL60P6-PB-2-xxxQ (W/B) HSL60P6-PB-3-xxxQ (W/B)
- Page 7 Maximum Load/Pressure Extended Maximum 4000 7000 Static Load IEC Products HSL72P6-PB-1-xxx (W/B) 200mm 200mm Moun*ng h oles Moun*ng h oles 300mm 300mm UL Products Moun*ng h oles Moun*ng h oles HSL72P6-PB-0-xxxT (W/B) HSL72P6-PB-2-xxxQ (W/B) HSL72P6-PB-3-xxxQ (W/B)
-
Page 8: Electrical Installation
The use of a diode to bypass the shaded area can minimize both heating and array current reduction. All Hanwha Solar modules are equipped with factory installed bypass diodes. The factory installed diodes provide proper circuit protection for the system. - Page 9 4 Stainless steel spring washer M4 5 Stainless steel lock-toothed washer M4 6 Stainless steel slotted washer M4 IEC/En61730 InformatIon Hanwha Solar module is designed to fulfill the criteria of Application Class A requirements according to IEC/EN61730- part1. The modules are qualified for application class A: Hazardous voltage (IEC61730: higher than 50V DC; EN61730:...
-
Page 10: Additional Information
ADDITIONAL INFORMATION warnIng! PV modules generate electricity as soon as they are exposed to sunlight. One module generates a safe, extra- low voltage level, but multiple modules connected in series (summing the voltage) or in parallel (summing the current), represent a danger. The following points must be noted when handling the solar modules to avoid the risk of fire, sparking, and fatal electric shock. - Page 11 CondItIons for hanwha soLar modULEs operating conditions • The operating temperature of PV module should be within -40°C to 85°C (-40°F to 185°F). • Ensure adequate ventilation behind the module, especially in hot environments. • Module should be installed at least 500m from the sea to avoid corrosion due to exposure to salt.
- Page 12 International Product Safety Certifications No. 888, Linyang Road, Qidong Jiangsu Province, 226200, China Phone: 86-513-8360-6222 TÜV, CE, UL, and Safety Class II certifications ensure that Hanwha Solar’s Fax: 86-513-8360-6278 products operate safely and comply with electrical and fire safety codes hanwha solarone gmbh around the world.
