Note: 1. "xxx" indicates nominal power output
2. "B" denotes black diamond module
3. "W" denotes white back sheet and black frame
4. "E" denotes anti-salted property
Version: HW3.819. 242SCV1
Installation Guide
HSL60P6-PC-1-xxx(W/B)
HSL72P6-PC-1-xxx(W/B)
HSL60P6-PC-1-xxxE
HSL72P6-PC-1-xxxE
HSL60P6-PC-3-xxx(W/B)
HSL72P6-PC-3-xxx(W/B)
HSL60P6-PC-3-xxxE
HSL72P6-PC-3-xxxE
Hanwha SolarOne (Qidong) Co., Ltd.
888 Linyang Road, Qidong
Jiangsu 226200, China
www.hanwha-solarone.com
sales@hanwha-solarone.com
Sep 1, 2014
Page 1 / 11
Advertisement
Table of Contents
Related Manuals for Hanwha Solar HSL60P6-PC-1-xxx
Summary of Contents for Hanwha Solar HSL60P6-PC-1-xxx
- Page 1 Sep 1, 2014 Installation Guide HSL60P6-PC-1-xxx(W/B) HSL72P6-PC-1-xxx(W/B) HSL60P6-PC-1-xxxE HSL72P6-PC-1-xxxE HSL60P6-PC-3-xxx(W/B) HSL72P6-PC-3-xxx(W/B) HSL60P6-PC-3-xxxE HSL72P6-PC-3-xxxE Hanwha SolarOne (Qidong) Co., Ltd. 888 Linyang Road, Qidong Jiangsu 226200, China www.hanwha-solarone.com sales@hanwha-solarone.com Note: 1. “xxx” indicates nominal power output 2. “B” denotes black diamond module 3.
-
Page 2: Table Of Contents
Sep 1, 2014 CONTENTS GENERATION INFORMATION....................3 1-1. Purpose Of This Guide ....................3 1-2. Disclaimer Of Liability....................3 1-3. IEC/EN61730 Information .................... 3 1-4. UL1703 Information ..................... 3 1-5. Safety Instruction ......................4 1-6. Unpacking and storing module ..................4 SYSTEM DESIGN, MOUNTING AND INSTALLATION .............. -
Page 3: Generation Information
We are committed to providing technical and installation support for our customers worldwide. This Installation Guide covers installation of the following Hanwha SolarOne modules: IEC 1000V HSL60P6-PC-1-xxx (W/B); HSL72P6-PC-1-xxx (W/B); HSL60P6-PC-1-xxxE; HSL72P6-PC-1-xxxE UL 1000V HSL60P6-PC-3-xxx (W/B); HSL72P6-PC-3-xxx (W/B); HSL60P6-PC-3-xxxE; HSL72P6-PC-3-xxxE 1-1. -
Page 4: Safety Instruction
Sep 1, 2014 1-5. Safety Instruction PV modules generate electricity as soon as they are exposed to sunlight. One module generates a safe, extra low voltage level, but multiple modules connected in series (summing the voltage) or in parallel (summing the current) represent a danger. -
Page 5: System Design, Mounting And Installation
Sep 1, 2014 2. SYSTEM DESIGN, MOUNTING AND INSTALLATION 2-1. System Design Before installing your solar system, contact local authorities to determine the necessary permit, installation and inspection requirements that must be followed. System should be installed by qualified personnel only. The system involves electricity, and can be dangerous if the personnel are not familiar with the appropriate safety procedures. -
Page 6: Module Specification
Sep 1, 2014 Secure the module along the long edges with the correct number of clamps. Use all the mounting points provided and avoid direct contact between glass and metal (e.g. mounting rails). 2-3. Module Specification HSL72 Series HSL60 Series 2-4. - Page 7 Sep 1, 2014 Snow/Wind Pressure Snow/Wind Pressure Installation 5400/4000 Pa 5400/2400 Pa Method HSL60 HSL72 HSL60 & HSL72 Clamping long frame Clamping short frame Option B: Bolting drawing Stainless steel M6 T-head bolt Stainless steel flat washer Stainless steel spring washer Stainless steel M6 nut Version: HW3.819.
-
Page 8: Electrical Installation-Wiring
Sep 1, 2014 Snow/Wind Pressure Snow/Wind Pressure Installation Method 5400/4000 Pa 5400/4000 Pa HSL60 HSL72 Bolting Mounting 3. ELECTRICAL INSTALLATION-WIRING 3-1. Correct wiring scheme To minimize the risk of indirect lighting strike, avoid forming closed loops when designing the system. Check that wiring is correct before starting the generator. -
Page 9: Others
Sep 1, 2014 3-5. Others During installation, be sure to tie the cable from the junction box to the mounting substructure with nylon line, etc. to avoid direct contact of the cable with the back surface of the module. 4. GROUNDING: To avoid the risk of electrical shock or fire, the module frame should be grounded before the electrical connection of the modules is operated. -
Page 10: Limited Environmental Conditions
Sep 1, 2014 Select a grounding lug listed for direct burial and outdoor use (tin-plated, solid copper lay-in lug with a stainless-steel set screw) capable of accepting a 4-14 AWG Serrated washer copper conductor. Module frame Secure the lug to module grounding hole with a stainless steel machine screw, flat Lay-in lug washer, serrated washer and nut. - Page 11 Sep 1, 2014 Visit www.hanwha-solarone.com for more information. Hanwha SolarOne provides detailed technical support, worldwide. Hanwha SolarOne Co., Ltd. Hanwha SolarOne Deutschland GmbH RM605-606, 2277 Long Yang Road Oskar Messter Straße 13 Yongda International Tower 85737 Ismaning Shanghai, China 200135 Deutschland Tel: +86 213 852 1666 Tel: +49 89 2175 667 30...
