  • Page 1 ’ ’ ’...

  • Page 2: Copyright

    In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.

  • Page 3: Safety Warnings

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions before using the device. DO NOT open the device or unit. Opening or removing the cover may expose you to dangerous high voltage points or other risks.

  • Page 4: Foreword

    Be sure to read this manual carefully before using this product. Especially Legal Disclaimer, Statement of Conditions and Safety Warnings. Caution: The NP-100SE+/PD is for indoor applications only. This product does not have waterproof protection, please do not use in outdoor applications.

  • Page 5: Table Of Contents

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Table of Contents Copyright ................................1 Safety Warnings..............................2 Foreword ................................3 Table of Contents ..............................4 Chapter 1. Unpacking Information......................... 6 1.1 Check List ....................................6 Chapter 2. Hardware Description.......................... 7 2.1 LED Indicators ....................................8 2.2 Connectors ....................................8...
  • Page 6 PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Appendix D: Compliance and Safety Information ....................19 Appendix E: DC Power Cable Information ......................22 Warranty ................................23 Chinese SJ/T 11364-2006........................... 24...

  • Page 7: Chapter 1. Unpacking Information

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Chapter 1. Unpacking Information 1.1 Check List Carefully unpack the package and check its contents against the checklist. Package Contents 1. 1 x PSE and 1x PD 2. 1 x DC Adaptor 3. 1 x DC to DC Plug Cable Note1: Please inform your dealer immediately for any missing or damaged parts.

  • Page 8: Chapter 2. Hardware Description

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Chapter 2. Hardware Description This section describes the important parts of the converter. It features the front panel and rear panel. Figure 2.1 Front Panel of PSE Figure 2.2 Rear Panel of PSE Figure 2.3 Front Panel of PD...

  • Page 9: Led Indicators

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 2.1 LED Indicators PSE or PD has a LED indicator. The following Table shows the description. (Table 2-1) LED Indicators Description and Operation Table 2-1 Model Color Status Descriptions The PSE is connected with PD and functioning properly.
  • Page 10 PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Figure 2.5 PSE Connectors Figure 2.6 PD Connectors...

  • Page 11: Chapter 3. Installation

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Chapter 3. Installation 3.1 Hardware Installation This chapter describes how to install the PoE and establishes network connections. You may install the PoE on any level surface (ex. table). However, please take note of the following minimum site requirements before you begin.

  • Page 12: Basic Connections

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 3.3 Basic connections Please refer to PoE application as follows. (Figure 3.1) PSE: 1. Connect a standard network cable from Hub/Switch to “Data” port of PSE. 2. Connect the long cable that will be used to connect to remote device to the port “PoE OUT”.
  • Page 13 PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Figure 3.1 PoE Application diagram...

  • Page 14: Appendix A: Cable Requirements

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Appendix A: Cable Requirements A CAT 3, 4 or 5 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the modem. A 10Base-T cable often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10Base-T cable is referred to as an RJ-45 connector and it consists of eight pins.
  • Page 15 PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...

  • Page 16: Appendix B: Product Specification

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Appendix B: Product Specification Key Features and Benefits 1. Compliant with IEEE 802.3af, IEEE 802.3at (NP-100SE+), Power over Ethernet, IEEE802.3/802.3u 10/100Base-TX 2. Provides 48V DC power over RJ-45 Ethernet cable to device with Ethernet port 3.
  • Page 17 PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Product Specification Specification Model NP-100SE+ (PSE) Input Specification Data Interface RJ-45 Jack (See Pin Assignment) Input Voltage 36 ~ 57 Vdc (48V) Input Current 400mA MAX. Input @Vin=48Vdc Output Specification PD Detection & Classification IEEE802.3af, IEEE802.3at compliant...
  • Page 18 PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Choice of powered device for 5V DC, 9V DC or 12V DC Specification Model NP-100PD (PD) Input Specification Input Signal IEEE 802.3af compliant signal from PSE Data Interface RJ-45 Jack (See Pin Assignment)

  • Page 19: Appendix C: Troubleshooting

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Appendix C: Troubleshooting The PoE can be easily monitored through its comprehensive panel indicators. These indicators assist the network manager in identifying problems the hub may encounter. This section describes common problems you may encounter and possible solutions.

  • Page 20: Appendix D: Compliance And Safety Information

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Appendix D: Compliance and Safety Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC class B rules.
  • Page 21 PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs.
  • Page 22 PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 FCC Warning This equipment has been tested to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 23: Appendix E: Dc Power Cable Information

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Appendix E: DC Power Cable Information...

  • Page 24: Warranty

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Warranty The original owner that the product delivered in this package will be free from defects in material and workmanship for one year parts after purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.

  • Page 25: Chinese Sj/T 11364-2006

    PoE SERIES NP-100SE+/PD USER’S MANUAL Ver. A6 Chinese SJ/T 11364-2006 有 毒 有 害 物 质 或 元 素 部件名称 铅(Pb) 汞(Hg) 镉(Cd) 六价铬[Cr(VI)] 多溴联苯(PBB) 多溴二苯醚(PBDE) 结构壳体 ○ ○ ○ ○ ○ ○ 电路组 ○ ○ ○ ○ ○ ○...
