  • Page 1 ’ ’ ’...

  • Page 2: Copyright

    In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.

  • Page 3: Foreword

    This is why NH-310C is designed to be a cost effective home networking solution. With the data transmission up to 200Mbps and distance can withstand 60dB of the attenuation; it meets the growing demand for high speed multimedia services. With plug & play, this simply eliminates the pain in modification and high infrastructure cost.

  • Page 4: Safety Warnings

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions before using the device. DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks.

  • Page 5: Table Of Contents

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Table of Contents Copyright ................................1 Foreword ................................2 Safety Warnings..............................3 Table of Contents ..............................4 Chapter 1. Unpacking Information......................... 5 1.1C ....................................5 HECK Chapter 2. Hardware Description.......................... 6 2.1 F...

  • Page 6: Chapter 1. Unpacking Information

    3. Do not use sub-standard power supply. Before connecting the power supply to the device, be sure to check compliance with the specifications. The NH-310C supports 5V to 12 VDC power input. 4. The power supply included in the package is commercial-grade. Do not use in industrial-grade applications.

  • Page 7: Chapter 2. Hardware Description

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Chapter 2. Hardware Description This section describes the important parts of the modem. It features the front indicators and rear connectors. NH-310C Outward 2.1 Front Panel The front panel provides a simple interface monitoring of the end point.

  • Page 8: Led Indicators

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 2.2 LED indicators At a quick glance of the front panel, it will be easy to tell if the modem has power, signal from its 2 Ethernet RJ-45 port, its HCNA coaxial connector and high / low line speed quality.

  • Page 9: Rear Panel

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Table 2-2 Line Speed performance with reference to Line speed LED Dataspeed (Mbps) Attenuator (dB) SNR (dB) Line speed LED on 80 or above 40 and below Green...
  • Page 10 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 And the table shows the description. (Table 2-3) Table 2-3: Connectors shown on the rear side of the Modem Connectors Type Description F-type female HCNA For connecting the 2 HCNA modems with RG59 75ohm coaxial cable.

  • Page 11: Chapter 3

    (ex. a table or shelf). However, please take note of the following minimum site requirements before you begin. NH-310C needs paste four rubber feet on the bottom to avoid scratching, please refer to Appendix E: Attaching Rubber Feet.

  • Page 12: General Rules

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 3.3 General Rules Before making any connections to the modem, take note the following rules: • Ethernet Port (RJ-45) All network connections to the end point Ethernet ports must be made using Category 5 UTP or above for 100 Mbps, Category 3, 4 UTP for 10Mbps.

  • Page 13: Hcna Connections

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 3.4 HCNA Connections The modem has been designed to operate on the coaxial cable installed in homes throughout the world. They utilized the same cable and connectors commonly used for television.
  • Page 14 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Figure 3.1: NH-310C connections diagram...
  • Page 15 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Figure 3.2: NH-310C connections diagram-2...

  • Page 16: Appendix A: Cable Requirements

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Appendix A: Cable Requirements A CAT 3, 4 or 5 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the modem. A 10Base-T cable often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10Base-T cable is referred to as an RJ-45 connector and it consists of eight pins.
  • Page 17 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...

  • Page 18: Appendix B: Product Specification

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Appendix B: Product Specification Key Features & Benefits • Compliant with HomePNA3.1/HomePNA3.0 over coaxial cable(HCNA) specifications (ITU-T G.9954) • Compliant with IEEE802.3 10Base-T and IEEE802.3u 100Base-Tx standards • Compliant with IEEE802.3x flow control standard •...

  • Page 19: Product Specification

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Product Specification Standards: IEEE802.3 / IEEE802.3u / ITU-T G.9954 standard 2 x RJ-45, 10/100Mbps Ethernet port with Auto-MDI/MDIX 1 x F-type female coaxial connector for HCNA Interfaces: 1 x F-type female coaxial connector for STB/TV 1 x Power jack for 5-12VDC / 1A power adapter.

  • Page 20: Appendix C: Troubleshooting

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Appendix C: Troubleshooting Diagnosing the Modem’s Indicators The endpoint can be easily monitored through its comprehensive panel indicators. These indicators assist the network manager in identifying problems the hub may encounter. This section describes common problems you may encounter and possible solutions.
  • Page 21 Notes: 2. Please note that NH-310C TV signals input power is unlimited, user does not need add the attenuator before NH-310C to weaken the TV signal source. 3. If TV signal is too strong, leading to the advent of television ripple, please add an attenuator...
  • Page 22 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Figure C-1 TV signal connection solution...
  • Page 23 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 5. Question: Why do the NH-310C units have MAC addresses and what are the MAC Addresses used for? Because NH-310C can support 10 endpoints maximum and It uses the MAC address value to Answer: identify the identity of each endpoint.
  • Page 24 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply as explained in the previous section.
  • Page 25 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Physical Configuration If problems occur after altering the network configuration, restore the original connections, and try to track the problem down by implementing the new changes, one step at a time. Ensure that cable distances and other physical aspects of the installation that do not exceed recommendations.
  • Page 26 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 AVOID THESE BAD CONDITIONS: B. Low dielectric – a gap between the dielectric and ridge will cause packet loss; dielectric should be flush with the ridge. C. Debris inside connector – for example, loose shielding strands wrapped around the stinger will cause 30dB attenuation.

  • Page 27: Appendix D: Fcc And Ce Mark Warning

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Appendix D: FCC and CE Mark Warning FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC class A rules.
  • Page 28 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs.
  • Page 29 NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 FCC Warning This equipment has been tested to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 30: Appendix E: Attaching Rubber Feet

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Appendix E: Attaching Rubber Feet 1. Make sure mounting surface on the bottom of the Modem is grease and dust free. 2. Remove adhesive backing from your Rubber Feet.

  • Page 31: Warranty

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Warranty The original owner that the product delivered in this package will be free from defects in material and workmanship for one year parts after purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.

  • Page 32: Chinese Sj/T 11364-2014

    NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7 Chinese SJ/T 11364-2014 有 毒 有 害 物 质 或 元 素 部件名称 铅(Pb) 汞(Hg) 镉(Cd) 六价铬[Cr(VI)] 多溴联苯(PBB) 多溴二苯醚(PBDE) 结构壳体 ○ ○ ○ ○ ○ ○ 电路组 ○...
