Summary of Contents for Nortek Control LV-D4-XMDI
- Page 1 NETWORK CAMERA GUIDE Install Browse Network Camera setup and installation guide. Browser setup with settings explained. Product Made in China under ISO9001 & ISO1400 standards 01.BSM.11.0086601 Manual Printed in China v1.0...
-
Page 2: Instruction Manual
IR Vandal Dome IP Camera CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER. NO USER SERVICABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated "dangerous voltage"... -
Page 3: Important Safeguards
Service Important Safeguards In addition to the careful attention devoted to quality standards in the manufacturing process of 13. Servicing - Do not attempt to service this video 19. Cleaning - Unplug the video product from the wall equipment yourself as opening or removing covers outlet before cleaning. -
Page 4: General Precautions
Features General Precautions 1. All warnings and instructions in this manual should be followed. 2. Remove the plug from the outlet before cleaning. Do not use liquid aerosol detergents. Use a water dampened cloth for cleaning. 3. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not be blocked. -
Page 5: Table Of Contents
8.7.2 Device Port ............31 8.7.3 Camera . -
Page 6: Getting Started
1.2 Camera Interior Overview Front of Camera 1. GETTING STARTED Zoom Focus IR LED’s The system comes with the following components: Camera Lens • 1 x Camera • 6 x Camera locking screws (3x inside CdS Sensor Mounting Screw Kit: camera;... -
Page 7: Onvif Compatibility And Included Software Overview
Connection 1.3 ONVIF Compatibility and Included Software Overview This camera is ONVIF v2.1 compliant. It is designed for interoperability with popular VMS’s and NVR’s*, with backwards compatibility to ONVIF v.1.02. For 2. CONNECTION more information on ONVIF, visit www.onvif.org NOTE: Provided software is PC compatible only; Mac OS® access to the The camera has the following termination cables: cameras is available via Safari®... -
Page 8: Camera Installation
Method 2 - Camera Base Install 3. CAMERA INSTALLATION 2b. Use the included mounting template (Installation Option 1) to mark and pre-drill the required holes. Make sure to follow the correct polarity if connecting 2c. Remove the camera 2c/2f the camera to DC power. Polarity is marked on the base by unscrewing the 3 power connector. - Page 9 6a. Adjust camera viewing angle and secure into Reattaching the Camera Module place by tightening thumb screw using a flat head 3a. Reinsert camera module into screwdriver. camera base by aligning the arrow notches on the edge of the camera Avoid pointing the camera lens in module and the camera base angles where the IR LEDs are...
-
Page 10: Junction Box Plate
Junction 7.Re-attach the dome cover. 4. JUNCTION BOX PLATE Align the arrows as shown in the diagram to Junction box plate is used to install camera into standard 4S and Octagon ensure a junction boxes. Junction box plate screw kit contains the following waterproof seal. -
Page 11: Junction Box Installation Types
Finding the Address Junction Box Installation Types 6. FINDING THE CAMERA’S IP ADDRESS 5. JUNCTION BOX INSTALLATION TYPES Use the steps below to find the camera’s IP address and connect to the camera over the local area network (LAN) using NVMS, UPnP on 5.1 Two Gang Fitting Windows®... -
Page 12: Finding The Camera's Ip Address Using Upnp In Windows® 7
Finding the Address Finding the Address 4. Click on a camera IP address in Device List to login. 1. Click Start>Computer>Network. The camera’s IP address appears under Network Infrastructure. 5. Under User Name, enter the user name for the camera (default: admin). Under Password, enter the password for the camera (default: admin). -
Page 13: Finding The Camera Ip Using The Bnc Test Cable
Finding the Address Configuring Connection 2. Click Bonjour. The camera’s IP address appears in the Bonjour Devices list. 7. CONFIGURING REMOTE CONNECTION 3. Double-click the camera to open it in Safari®. Follow the steps below to configure your camera for connections over the Bookmarks Internet using a web browser, NVMS, or other VMS software. - Page 14 Configuring Connection Configuring Connection Step 3 of 6: Locate your camera’s MAC address: Step 5 of 6: Enable DDNS on the camera: 1. Open a web browser and enter the camera’s IP address in the address 1. Ent er the camera’s IP address in your web browser. Log in and then click bar in the following format: Network Service>DDNS.
-
Page 15: Connecting To A Ddns Address Using Nvms
Configuring Connection Configuring Connection 7.1 Connecting to a DDNS address using NVMS 8. Close Device Maintenance and Device Manager, and return to the Live Video screen. The newly added camera will appear in Device List. NOTE: Complete all the steps above before performing the following method. -
Page 16: Web Configuration
Configuration 4. The main screen for the camera web interface opens. From here you can view and configure the camera. 8. WEB CONFIGURATION NOTE: If you do not see video from the camera, make sure your computer has the latest version of Adobe Flash Player installed (visit http:// The camera includes a built-in web interface that can be accessed using a www.adobe.com/... - Page 17 Configuration 4. If your computer has Flash Player installed, the main screen for the 3. Under Download unsigned ActiveX controls, click Prompt camera web interface opens. From here you can view and configure the (recommended) or Enable. camera. NOTE: The ActiveX plug-in may provide smoother video performance than Select Enable or Prompt under Flash Player.
-
Page 18: Web Interface/Live Video Overview
Configuration 8.4 Web Interface/Live Video Overview The Live Video Menu contains the following options: Click and drag to zoom in. Right-click and • Full Screen: Open the video in full screen. Press ESC to exit full screen. Camera select ZoomOut to zoom out. configuration •... -
Page 19: Device Info
Configuration 8.5 Device Info 8.6 Stream Configuration The Stream Configuration page allows you to configure the camera’s video The Device Info page shows information about your IP camera, such as the streams. The camera supports three different video streams. This allows Device Name (which appears in the Device List in NVMS), firmware you to have a high quality recording stream (stream1), a lower quality stream version, MAC address, and camera inputs and outputs. -
Page 20: Device Configuration
Configuration 8.7.1 Local Network • Frame Rate: Select the frame rate for the stream up to maximum of 30FPS for stream1 or stream2 or 12FPS for stream3. NOTE: Frame rate may be automatically adjusted to account for bandwidth limitations. • I Frame interval: Select the interval for I frames: 1, 2, or 3. The default value of 2 should be used unless there are special requirements. -
Page 21: Device Port
Configuration 8.7.3 Camera 4. Click OK to save changes. The camera will restart with the new IP address. 8.7.2 Device Port The Camera page (Device Configuration>Camera) allows you to configure the Channel Name, which appears on the camera OSD and the video system frequency. -
Page 22: Osd
Configuration 3. Un-check Enable NTP and click Apply at the bottom of the screen. You can set the camera’s date and time the following ways: 4. If your region observes daylight savings time, check Adjust clock for • Using an NTP server (recommended) daylight saving changes. -
Page 23: Microphone
Configuration Configure microphone settings for listen-in audio. Self-powered • Custom: Create a custom OSD message. Enter the custom OSD text under Custom OSD. microphone required (not included). Device Name To configure microphone settings: Channel ID 1. Click Device Configuration>Microphone. Channel Name 2. -
Page 24: Alarm Configuration
Configuration 3. Under Max Disk Space, enter the disk full percentage that will trigger an To change the language for the OSD and email alarms: alarm (e.g. a Disk Full Alarm will be triggered when the recording disk is 1. Click Device Configuration>Language. 80% full). -
Page 25: Local Record
Configuration 8.9 Local Record 3. Click Schedule to configure a motion detection schedule. The Schedule Time Setting menu opens. Local Record contains the following sub-menus: • Record Policy NOTE: If the Schedule Time Setting does not open, disable any popup blockers. - Page 26 Configuration 4. Click Modify. The Record Disk Path menu opens. 2. Under Disk Name, select ftp. Select SD1 Select ftp Click Modify Click Modify 5. Check Enable. 3. Click Modify. The Record Disk Path opens. 4. Check Enable. Check Enable 5.
- Page 27 Configuration 4. Configure the following: 6. Click OK. 7. Set up recording using the Record Policy sub-menu (see “8.9.1 Record Directory” on page 40). To access your recordings, use NVMS or manually access your FTP server. NOTE: On the Record Directory page, Status will be OK when FTP is selected if FTP is accessible and all settings have been entered correctly.
-
Page 28: Record Policy
Configuration 6. Set up recording using the Record Policy sub-menu (see “8.9.1 Record The Record Policy menu allows you to set the microSD/SD memory card, Directory” on page 40). To access your recordings, use NVMS or NAS, and FTP recording parameters. Once configured, the device can record manually access your NAS device. -
Page 29: Privacy Masking
Configuration 4. Click OK. An error message appears if the masks configured exceed 8% number of days and enter the Number of Days desired. Note that you of the total image area. must have sufficient storage space to save the number of days entered. 8. -
Page 30: Service Center
Configuration To enable email alerts: • Password: Enter the Password you have set on the account. 1. Click Service Center>SMTP. 4. Click OK to save settings. 2. Check Enable SMTP. 8.12 Service Center 3. Configure the following: • SMTP Server Address: Enter the address for your SMTP server. Service Center contains the following sub-menus: •... -
Page 31: Group
Configuration 8.13.1 Group 1. Under Group, select the group you would like to modify. 2. Click Modify to change the group name if needed, enter a new group name and click OK. 3. Change permissions as needed and click OK. To delete a user group: 1. -
Page 32: Unlocking User Accounts
Configuration To add a user account: 2. Click Privilege Manager>User. 1. Click Add. The Add User window appears. NOTE: If the Add User menu does not appear, disable any popup blockers. Select the user Click Unlock 3. Under User, select the locked user account. 4. -
Page 33: Default Settings
Configuration 8.16 Default Settings • Click Save to save setting changes. • Click Reset to revert to the last saved changes. • Click Factory Setting to revert all camera sensor settings to factory defaults. • Click Cancel to exit. Click Default Settings. Click Restore then click OK to restore the camera to TIP: Hold the mouse over the tabs to see the full name of the tab. -
Page 34: Gain Mode
Configuration • MaxShutter: Sets the upper limit of the shutter speed when AutoShutter • Night Color: Select Black_White to have the camera switch to black and is selected. white during night mode or select Multicolor to have the camera remain in color during night mode. -
Page 35: Ae Meter Mode
Configuration 8.17.7 AE Meter Mode • WB Mode: Select Auto for automatic white balance or Manual to manually set the white balance. • Manual Mode: Select a mode for the lighting conditions or select Customized and manually adjust the RedGain and BlueGain. 8.17.9 WDR (solution may not feature this setting) Set the Auto-Exposure Meter Mode from one of the following: •... -
Page 36: Mirror
Configuration 8.17.10 Mirror 9. RESETTING TO FACTORY DEFAULTS Follow the steps below to revert all settings to factory defaults. The camera must be connected to power to perform a factory reset. 1.Loosen the three tamper screws using the provided allen key. Lift the dome cover. -
Page 37: Dimensions
5.Re-attach the dome cover. Align the arrows 10. DIMENSIONS as shown in the diagram to ensure a waterproof seal. Use the allen key to tighten the Arrow on camera base tamper screws. Arrow on camera module (inside camera) NOTE: Make sure dome cover cord does not catch in Camera... -
Page 38: Troubleshooting
Troubleshooting Troubleshooting Can’t connect to camera on a web browser using a DDNS address: • Port forwarding not set up. Make sure the HTTP port (default: 80) and 11. TROUBLESHOOTING Control port (default: 30001) are forwarded on your router to the camera’s local IP address.
