Summary of Contents for Chimei 23 58cm
-
Page 1: User Manual
Wide LCD Monitor User Manual... -
Page 2: Table Of Contents
PRECAUTIONS Information for users applicable in European Union countries Information for users applicable in United States of America Power connection Maintenance Transporting the monitor GETTING STARTED Package contents Monitor installation Identifying parts and controls Working with OSD Group Customizing your Monitor Introduction to Hotkeys The operation of Function menu OSD icon list... -
Page 3: Information For Users Applicable In European Union Countries
PRECAUTIONS 5.Disconnect the power cable from the power supply if: Information for users applicable in European Union countries 5.1 You will not use the monitor for an extended period. The symbol on the product or its packaging signifies that this product has to be 5.2 The cable is damaged or frayed. -
Page 4: Getting Started
GETTING STARTED Package contents Monitor installation 1.Setting up the monitor Before beginning, ensure that the carton contains the following items: 1.1 Take out the monitor, stand and monitor base from the package. 1.2 Grasp the monitor with both hands and then slide the 1. -
Page 5: Identifying Parts And Controls
Identifying parts and controls Customizing your Monitor The On Screen Display (OSD) system provides a full range of customizable tools to 1.The LED light indicates the state of working. During operation, the LED Light is bright bule. When dormant, the LED Light is orange. optimize your display. -
Page 6: Introduction To Hotkeys
5. Return to the higher level menu. Press to return to the higher level. Hotkeys Introduction 6. Exit: Press to exit OSD menu; Or if you do not press any button, it will 1.Auto Adjustment automatically disappear after 30 seconds. When the OSD functions are displayed, press the first button on the left , and then you can automatically optimize the image performance. -
Page 7: Osd Icon List
OSD Icon List AUTO HORIZONTAL * Optimize the picture performance automatically. ADJUSTMENT * Shift the screen left or right POSITION * Activate the built-in color engine to enhance the graphic THEME MODE effects according to the different situations of the display. VERTICAL contents Shift the screen up or down... -
Page 8: Troubleshooting
Troubleshooting Symptom Check Items 1.No picture 1. Check if the monitor is turned on (press the button again). 2.LED indicator is not lit. 2. Check if the power cord is properly connected to the monitor and power outlet. 3 .Check if there is electricity coming from the power outlet (use another device to check for power). 1.No picture 1 Check if your computer is turned on. -
Page 9: Technical Features And Specifications
Technical Features and Specifications Item Description Interface Frequency 1. The following frequency range is the working period. If the entered mode between below Display Size 509 (H) x 286 (V)mm period but not match the frequency of supported timing, display optimization would not be Panel assured. -
Page 10: Fcc Compliance
FCC compliance 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
