- Page 1 OperatOr and parts Manual Conventional Auger Mover 012012 FK375...
-
Page 3: Table Of Contents
Table of Contents - Conventional Auger Mover Table of Contents Introduction ..........................4 Safety ............................5 • Safety ..........................5 • General Safety ........................5 • Start-up Safety .........................6 • Operation Safety ......................6 • Transport Safety .......................7 • Service and Maintenance Safety ..................7 • Storage Safety ........................7 Assembly ............................8 • Wheel Drive Installation ....................8 • Mover Axle Assembly ......................8... -
Page 4: Introduction
Introduction - Conventional Auger Mover Introduction The Farm King conventional auger mover is an option that attaches to an auger and allows you to transfer the weight from the intake onto a swivel yoke. This makes moving the auger and positioning it at a bin a much lighter task, which can be done by one person. -
Page 5: Safety
Safety - Conventional Auger Mover Safety Safety Instructions Remember, YOU are the key to safety. Good safety practices not only protect you, but also the people around you. Make these practices a working part of your safety program. Be certain that everyone operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions. -
Page 6: General Safety Instructions
• Read and understand the Operator’s Manual and all safety signs before operating, servicing, adjusting, repairing, or unplugging the equipment. • Do not attempt any unauthorized modifications to your Farm King product as this could affect function or safety, and could affect the life of the equipment. -
Page 7: Transport Safety
Safety - Conventional Auger Mover Transport Safety • Review Transport Safety instructions in tractor manual before moving. • Check with local authorities regarding transport on public roads. Obey all applicable laws and regulations. • Do not tow equipment that does not have brakes at speeds over 20 mph (32km/h). • Do not tow equipment that does not have brakes that, when fully loaded, has a mass (weight) over 3300 lb (1.5 t) and more than 1.5 times the mass (weight) of the towing unit. -
Page 8: Assembly Instructions
Assembly - Conventional Auger Mover Assembly Instructions Wheel Drive Installation Jack up one end of the auger axle (#24) and remove the wheel and tire assembly. 2. Take one of the wheel drive gears (#84) and place it into the inside of the rim with the gear facing out. -
Page 9: Mover Frame Assembly
Assembly - Conventional Auger Mover Mover Frame Assembly Slide the left and right adjustment tubes (#6 & #7) into the two outer tubes (#3). The connecting hole you use will vary with the length of the auger. For the small mover use the tubes fully extended on 46’... -
Page 10: Hydraulic Pump, Valve And Hose Assembly
Assembly - Conventional Auger Mover 2. The winch bracket (#70) should be in place on the auger before starting. The rest of the winch drive assembly can be assembled before bolting to the winch bracket. Remove the long bolt from the top corner of the winch and replace it after sliding it through the welded sleeve on the winch adaptor weldment (#23). - Page 11 Assembly - Conventional Auger Mover 3. Join the two guard plates using the 7" adjustment plate (#6). Use 3/8" x 4-1/2" bolts, lock washers and hex nuts fitted through the welded sleeves on the guard plates. The small belt guard (#9) is held on with the same bolts. 4.
-
Page 12: Operation Instructions
Operation - Conventional Auger Mover Operation Instructions Once your fittings are tight you can fill your reservoir with hydraulic oil. Any hydraulic oil will work. 2. Tighten down your winch cable and make sure there are three full wraps around the drum before tension is added. -
Page 13: Bolt Torque
Bolt Torque - Conventional Auger Mover Bolt Torque Checking Bolt Torque The tables shown below give correct torque values for various bolts and hex bolts. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. -
Page 14: Parts Drawings
Parts - Conventional Auger Mover Conventional Auger Mover... -
Page 15: Exploded Views Of Drive Motors
Parts - Conventional Auger Mover Exploded Views of Drive Motors... -
Page 16: Exploded Views Of Winch And Oil Tank
Parts - Conventional Auger Mover Exploded Views of Winch and Oil Tank... -
Page 17: Exploded View Of Hydraulic Pump Mount
Parts - Conventional Auger Mover Exploded View of Hydraulic Pump Mount... -
Page 18: Parts List
Parts - Conventional Auger Mover When Ordering Parts Always give your dealer the Model, Color and Serial Number of your machine to assist him in ordering and obtaining the correct parts. Use the exploded view and tabular listing of the area of interest to exactly identify the required part. - Page 19 Parts - Conventional Auger Mover Item Part Number Description 903416 X Tube Weldt - R 962035 X Tube Weldt - L F8852 Lift Arm Weldt - L F8853 Lift Arm Weldt - R 962043 Lift Arm Ext Weldt 910267 Tank Strap Weldt 910272 Tank MT Weldt 910273...
- Page 20 Parts - Conventional Auger Mover Item Part Number Description 961846 1/2" ID x 3-1/2" Od x 1-1/8" Cble Pulley 903413 8-1/4" x 19-1/2" Wnch Brkt 903414 3/8" x 1-1/4" x 5-1/4" Conn Pl 968430 Oil Seal Se14x 967208 Inner Bearing Cone (967208) (LM48548) 968403 5-Bolt Hub w/ Bearing Cups 967900...
- Page 21 Parts - Conventional Auger Mover Item Part Number Description 81588 3/8" x 4-1/2" Hex Bolt (Pl) 81525 1/4" x 3/4" Hex Bolt (Pl) 81545 1/4" Lock Washer (Pl) 904590 1/4" x 4-1/4" x 5" Hngr Mtg Brkt 961377 1" x 10-1/2" Hngr Swvl Shft 968412 Inner Cup (LM48510) 84111...
-
Page 22: Right Drive Wheel Assembly And Parts List
Parts - Conventional Auger Mover Right Drive Wheel Assembly... - Page 23 Parts - Conventional Auger Mover Item Part Number Description 910245 Hyd Motor 101-1011-009 81636 1/2" Hex Nut (Pl) 81638 1/2" Bs Flat Washer (Pl) 910131 Motor Connector Weldment 910121 Motor Handle 910120 3/8" x 4" x 6-3/4" Hyd Mot Mt (Pl) 910119 Hyd Mot Arm 81624...
-
Page 24: Motor Stop Assembly And Parts List
Parts - Conventional Auger Mover Motor Stop Assembly... - Page 25 Parts - Conventional Auger Mover Item Part Number Description 910179 Stopper Weldt 910180 Mot Stop Frame Weldt 910181 Setscrew Weldt 908010 Mot Mt Weldt 910175 1.017" ID x 1-1/2" Od x 1" Mot Stop Adjable Pipe 81615 7/16" Lock Washer (Pl) 81614 7/16"...
-
Page 26: Hydraulic Pump Assembly And Parts List
Parts - Conventional Auger Mover Hydraulic Pump Assembly... - Page 27 Parts - Conventional Auger Mover Item Part Number Description 910130 Pump Handle Weldment 910126 Hydraulic Pump to Motor Connector 910213 Hyd Pump Arm 910128 Pump Belt Guard Mount Plate 910129 Pump Belt Guard 910127 Pump Belt Guard Spacer 910123 Pump Belt Tensioner Link Plate 910200 26004-Lzd Hyd Pump 910199...
-
Page 28: Hydraulic Fittings And Parts List
Parts - Conventional Auger Mover Hydraulic Fittings... - Page 29 Parts - Conventional Auger Mover Item Part Number Description 910262 9/16" Morb x 9/16" Mjic 90° Elbow w/ Restrictor 887572 9/16" Fjic x 9/16" Mjic x 9/16" Mjic Tee 812304 9/16" Morb x 9/16" Mjic 45° Elbow 811414 3/4" Morb x 3/4" Mjic 90° Elbow 910247 3/8"...
-
Page 30: Hydraulic Hoses - Small Mover And Parts List
Parts - Conventional Auger Mover Hydraulic Hoses - Small Mover... - Page 31 Parts - Conventional Auger Mover Item Part Number Description 910250 3/4" x 60" Hose 1.3" Morb x 3/4" Swmnpt 910251 3/4" x 24" Hose 3/4" Swmnpt x 1/2" Mnpt 910260 1/2" x 198" Hose 1/2 Mnpt x 3/4 Swfjic 910205 1/2"...
-
Page 32: Hydraulic Hoses - Large Mover Parts List
Parts - Conventional Auger Mover Hydraulic Hoses - Large Mover... - Page 33 Parts - Conventional Auger Mover Item Part Number Description 910252 3/4" x 72" Hose 1.3" Morb x 3/4" Swmnpt 910251 3/4" x 24" Hose 3/4" Swmnpt x 1/2" Mnpt 910253 1/2" x 288" Hose 1/2 Mnpt x 3/4 Swfjic 910254 1/2"...
-
Page 34: Conventional Auger Mover Belt Guards And Parts List
Parts - Conventional Auger Mover Conventional Auger Mover Belt Guards... - Page 35 Parts - Conventional Auger Mover Item Part Number Description 910305 Top Belt Guard Weldment 961369 12" Guard Weldment 961357 Guard Plate Weldment 910307 Bottom Belt Guard Weldment 910310 Belt Guard Cover Pin Weldment 910037 Belt Guard Adjustment Plate 0.25 x 3 x 7" 910041 Belt Guard Adjustment Plate 7Ga x 3 x 14"...
-
Page 36: Shipping Kit And Bundle Numbers
Shipping Kit and Bundle Numbers - Conventional Auger Mover Shipping Kit and Bundle Numbers The following is a list of Kit Numbers for this product and the Bundle Numbers, Descriptions, and Quantities for each Kit. Bundle Number Description C501 Conventional Auger Mover 7" x 46' & Under C502 Conventional Auger Mover 8"... -
Page 38: Warranty
Repair Parts Limited Warranty Buhler Industries Inc. warrants Farm King replacement parts purchased after the expiration of the Buhler Industries Inc. Limited Warranty, and used and serviced as provided for in the Operator’s Manual, to be free from defects in materials or workmanship for a period of thirty (30) days from the invoice date for the parts. - Page 39 Warranty Requirements To be covered by warranty, each Farm King new product must be registered with Buhler Industries Inc. within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Buhler Industries Inc.
- Page 40 Warranty - Conventional Auger Mover (Note that some provinces or states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations and exclusion may not apply to you.) This warranty gives you specific legal rights and you may also have other rights, which vary from province to province or state to state.
- Page 42 www.farm-king.com 301 Mountain Street South Morden, Manitoba Canada R6M 1X7 Ph.: 204.822.4467 | Fax: 204.822.6348 Toll Free: 888.524.1004 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2012 Buhler Trading Inc. Printed in USA. TSX:BUI a division of Buhler Industries Inc.
