E120 User Manual

Important safety precautions

This section contains important information on the safe and
efficient operation of your mobile device.
For your safety, please refer to the guideline prior to using the
phone.
Note: Failure to comply with the following precautions may
be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park the vehicle first.
Switch off the phone when refueling
Do not use the phone at a refueling point (service station) or near
fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them in an aircraft is
both illegal and dangerous.
Switch off the phone near all medical equipment
Hospitals or health care facilities may be using equipment that could
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E120 and is the answer not in the manual?

Questions and answers

Related Manuals for FLY E120

Summary of Contents for FLY E120

  • Page 1: Important Safety Precautions

    E120 User Manual Important safety precautions This section contains important information on the safe and efficient operation of your mobile device. For your safety, please refer to the guideline prior to using the phone. Note: Failure to comply with the following precautions may be dangerous or illegal.
  • Page 2  If left unused, a fully charged battery will discharge itself over time.  Use only FLY-approved batteries, and recharge your battery only Be aware of special regulations with FLY–approved chargers. Disconnect the charger from the Meet any special regulations in force in any area and always switch off power source when it is not in use.
  • Page 3  Do not use harsh chemicals, cleaning solvents, or strong detergents to FLY-Authorized and/or Qualified Service Center. Do not attempt to to clean the phone. Wipe it with a soft cloth slightly dampened in a dry it with an external heat source, such as a microwave oven.
  • Page 4  When the phone or battery gets wet, phone repairs are no longer phones, may interfere with inadequately protected medical devices. guaranteed by the manufacturer's warranty, even if the warranty for Consult a doctor or the manufacturer of the medical device if you your phone has not expired.
  • Page 5 While there may be differences in SAR levels among mobile electronic systems in motor vehicles. Check with the manufacturer or phones, all FLY mobile phone models are designed to meet radio its representative regarding your vehicle. You should also consult the frequency exposure guidelines.
  • Page 6  Check regularly that all wireless phone equipment in your vehicle is atmosphere, and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. mounted and operating properly. ...

  • Page 7: Special Features Of Your Phone

    • PC Sync Manager CD using free, wireless Bluetooth technology. • Multimedia Message Service (MMS) You can obtain various accessories from your local FLY dealer. Send and receive MMS messages with a combination of text, images, video, and audio. Note: • The items supplied with your phone and the accessories •...

  • Page 8: Get Started

    Get started Your phone First steps to operating your phone Keys, features, and locations SIM card information When you subscribe to a cellular network, you receive a plug-in SIM Main display Main display Main display USB connector USB connector (Subscriber Identity Module) card loaded with your subscription details, such as your PIN, and available optional services.

  • Page 9: Low Battery Indicator

    When the phone is completely charged (the battery icon becomes Insert the SIM card. still), unplug the charger from the power outlet. Remove the charger from the phone. Switch the Phone On/Off Make sure that the gold- colored contacts on the card Enter Your Pin (Access Codes).

  • Page 10: Customize Your Phone

    [Menu]  [10.Settings]  [10.1 Phone Setup]  [10.2.1. Display  PUK Settings] The 8-digit PUK (Personal Unblocking Key) is required to change a disabled PIN. The PUK may be supplied with the SIM card. If not, or  Phone lock in case you have lost it, please contact your service provider.
  • Page 11 To activate the “Silent Mode” option, press and hold [#] key in End Key : End a call. the idle mode. In Menu mode, cancel input and return the phone to 4. To lock/unlock the phone the Idle mode. Long press left soft key/Menu key to lock the phone. Power on/off Key : Press and hold to switch the To unlock the phone, long press on left soft key/Menu key .

  • Page 12: Access Menu Functions

    Vibrate then Ring: Appears when the Vibrate then Ring mode is active. Signal Strength: Shows the strength of the receiving signal. Greater the number of bars, stronger the signal strength. Vibrator ON : Appears when the Vibration mode is active. GPRS: Shows the strength of the receiving GPRS signal.

  • Page 13: Shortcut Functions

    appears on the screen. Text Input Options: While you are in text editing mode, you will be in several modes. When you see [Option], press the soft key (left) for option: you can Shortcut functions save the entry or change the Text Input Method. To erase a character, Shortcut bar can be visible or hidden.

  • Page 14: Overview Of Menu Functions

    Overview of menu functions To access Menu mode, press [Menu] in Idle mode. 1. Phonebook 8.3 WAP ▷ ▶ ▷ 4.7 Flight Mode 8.4 Data Account ▷ 1.1 Quick Search ▷ ▷ 8.5 SIM Tool Kit 1.2 Search Entry ▷ 5.

  • Page 15: Phonebook (Menu 1)

    1. Phonebook (Menu 1) phonebook, you can search them by Name. 1. Enter a name you want to search in the text input box. Input full You can store phone numbers on your SIM card and in your phone’s name or even a start letter and press the [Option] soft key (left). memory.
  • Page 16 1.4 C 3. Press [Option] soft key, and select ‘Edit’ and select the entry from the You can copy all phonebook data from SIM card to Phone or from phonebook list by pressing the [Add] soft key. Phone to SIM. It is a useful function if you want to back up your Managing speed dial entries phonebook data from a SIM card to your phone and vice versa.

  • Page 17: Messaging (Menu 2)

    There are fields that you can set on or off in your phonebook entry. • Depending on the file type or DRM (Digital Rights (Home Number, Company Name, E-mail Address, Office Number, Fax Management) system, some files may not be able to be Number, Birthday, Associate Picture, Associate Sound and Caller forwarded.
  • Page 18 3. After you complete the message, press the [Done] soft key (right). messages. You can create the templates with the sentences you use Choose one of following options. frequently so that you can retrieve and insert them when composing 1) Send Only: Sends the message. It will not save the message. a message.
  • Page 19 • Priority – the priority of the mail. You can use inline selection to Note: Voice mail is a network feature. Please contact your service change the priority. There are “Low”, “Normal” and “High.” options. provider for more information. • Encoding Type – the encoding type of email body, including ASCII, BIG5, GB, UTF8 2.4 Broadcast Message •...

  • Page 20: Call History (Menu 3)

    • Received Calls: Allows you to delete all received call data Note: For more information about the available subjects, please • Delete All: Allows you to delete all call logs. contact your network service provider. 3.5 Call Time This menu displays the time log for calls made and received. The actual 3.

  • Page 21: Camera (Menu 5)

    3. Outdoor 5.1 Camera You can use the camera module embedded in your phone to take 4. Indoor photos. Before taking a picture, you can set your camera settings on 5. Headset screen by using navigation keys , and [Option] soft key (left). 6.

  • Page 22: Function Keys

    • Camera [OK] [OK] • EV (-4/-3/-2/-1/0/+1/+2/+3/+4): You can set the EV (Exposure Value) Shutter ( Key): you can take a picture by pressing the and the preview will look darker in lower EV and brighter in higher EV. key. •...
  • Page 23 5.2 Image Viewer sub-menu You can see your photos in your phone by choosing [Image Viewer] • White Balance (Auto / Daylight / Tungsten / Fluorescent / Cloud / menu in [Multimedia] menu. It will display the photos with thumbnail, Incandescence) image name, and image size.

  • Page 24: Music (Menu 6)

    Bluetooth. you can expand canvas size to full screen. 3) Rename: allows you to rename the video file 4) Delete: allows you to delete the video file 5.6 Slide Show 5) Delete All Files: allows you to delete entire recorded video files. Enables you to view all your pictures in slide show mode.
  • Page 25 - List Auto Generation (On/Off): you can select whether to generate the music list automatically or manually. When this option is On, 6.3 Sound Recorder music files in the main directory will be selected in the play list; With this menu, you can record sound in AMR, WAV and AWB format when the option is Off, you can add a file or a directory to the and use it as voice memo, ring tone, MMS attachment.
  • Page 26 Option: as your Ring Tone, MMS attachment. 1) Channel List: By selecting this menu, you can check the saved How to compose a melody: Channels. When you first use the Melody Compose, (1) Play : allows you to listen the channel chosen 1.
  • Page 27 1. Select the weight or length options. 6.7 Download Music 2. Select the type of conversion to be performed. Allows you to download musics from Fly website 3. Input the value to be converted, and then press [Ok] to get the result.

  • Page 28: Services (Menu 8)

    direction. latest WAP page. When you press a direction icon, the direction stopwatch will start Enter Address timing, and other direction stopwatch will pause the timing. When you If you know the URL of the site, you can go to the site directly by press the paused direction’s direction icon, the stopwatch will resume inputting the URL.

  • Page 29: Settings (Menu 10)

    Fun & Games menu provides you with Java interface and Games. You 9.6/7/8/9 Download Games/Sounds/Video/Pictures can use your phone as your entertainment center. Allows you to download multimedia content directly from Fly website 9.1 E-book reader The viewer application provides an easy way for you to read 10.
  • Page 30 • Set Format pressing the [On] or [Off] soft key (left). This menu allows you to set Time Format and Date Format. LCD Backlight Enables you to set up backlight duration. Schedule Power On/Off : You can set a schedule for powering on and off your mobile phone. 10.2 Display Characteristics When you schedule the power on or off, the phone will power on or off This menu allows you to customize desired phone display items as...
  • Page 31 3) Query Status: displays the status of the call waiting service. This option allows you to set redial automatically when the call receiver is busy. If you set [Auto Redial] on, it will redial 10 times to make a call. Call Divert Black list This network service reroutes incoming calls to the number that you...

  • Page 32: Connectivity (Menu 11)

    SIM card does not have PIN2, this feature is not supported. Remote Control Select to control your PC by Bluetooth (media player, Barred Dial mouse control, slide show) When the Barred Dial mode is enabled, the person using the phone cannot call numbers in the barred dial list.

  • Page 33: File Manager (Menu 12)

    Webcam Acts as a webcam for your PC. 3) Opening a Folder Fly PC Tool Acts as a modem for your phone and • Open: allows you to open the folder and view a list of files in the PC connection. You can use the folder.
  • Page 34 • Rename: allows you to edit the folder name. • Delete: allows you to delete the folder. • Sort: allows you to sort the files in the folder by name, by type, by time and by size. 4) Opening a File You can view, play, and setup files in the storage or the folder.
