Service Manual

This Service manual is issued as a service guide for the models of the NA9FL family listed above. Included in this
manual are a set of schematic, block diagrams, functional descriptions, alignment procedures, disassembly
procedures and a complete parts list.
"WARNING! This service manual is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this Service Manual by anyone else could result in serious injury or death."
The service technician is required to read and follow the "Safety Precautions" and "Important Safety Notice" in this main manual.
Models
CT-32SX12F
CT-32SX12UF
CT-32SX12CF
CT-36SX12F
CT-36SX12UF
CT-36SX12CF
Copyright 2002 by Matsushita Electric Corporation of
America. All rights reserved. Unauthorized copying
and distribution is a violation of law.
®
ORDER NO. MTNC020721C1
B5
Color Television
Main Manual
(NA9FL)
Panasonic
Chassis
AP381
AP381
AP381
AP382
AP382
AP382
