  • Page 1 MG3000-R8 Gateway WEB User Manual GoHigh Data Networks Technology CO., LTD © Copyright, 2007 GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 2: Table Of Contents

    DSP Detail Parameter Configuration ................34 Voice Parameter Configuration................34 8.1.1 Configure Code Mode .................34 8.1.2 Configure Voice Gain ..................35 GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...
  • Page 3 How to check the device’s serial number and Mac address.......57 12.9 Why the web page can’t visited after change protocol........57 13 Application example ......................59 GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...
  • Page 4 13.1 Call back ......................59 13.2 Remote extension ....................60 13.3 Intelligent Route application................61 GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 5: General Introduction

    General Introduction MG3000-R8 series products are developed as a type of advanced VoIP access equipment according to the features of broadband construction and to the development demand of voice business. Besides the functions of the traditional 4-port/8-port gateway, MG3000-R8 series products improve their reliability by the intelligent routing technology.

  • Page 6: Connect Cable & Supply Power

    The quantity of FXO/FXS ports may differ in different models, and users shall follow the actual labels on the equipment. FXO port may be connected to PBX or an analog trunk cable; FXS port may be connected to FXO port or a telephone. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 7: Initial Configuration

    Initial Configuration Users may perform WEB management by WAN port. Its IP address in initial configuration is 192.168.9.237。 System default user: admin (password: admin) GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 8: Log In The Web Management Interface

    Input the user name and password in the login interface and click the “Enter” button. If successful, the user will enter into the Quick Setup Interface of WEB management, as Figure4-2 shows. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...
  • Page 9 Figure 4-2 MG3000-R8 H323 Version Quick Setup Interface GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 10: Quick Setup

    Setup Protocol Parameter Before configuring the VoIP protocol parameter, the user needs to confirm the type of software version of MG3000-R8. For users with H.323 version, please refer to Chapter 5.2.1; for users with SIP version, please refer to Chapter 5.2.2.

  • Page 11: Configuration Of Sip Protocol

    ID”, the user needs to set up H.323 ID (allocated by the softswitch) in [Device H.323 ID] in [Quick Setup] at the same time. Configuration of SIP Protocol Shown as Figure 5-1. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...
  • Page 12 Figure 5-1 MG3000-R8 SIP Protocol Quick Setup Interface Peer to Peer Method If it is peer to peer routing method, please choose [No] in [Enable Registration] in the [Quick Setup] interface, and then directly refer to Chapter 5.3. Registration Mode IP Registration Choose [Yes] in [Enable Registration] in the [Quick Setup] interface.

  • Page 13: Setup Dsp Parameter

    FXO port may detect the type of tone signals correctly. First Coder: preferred coding/decoding method of voice channels. Users may choose one from G.711 U-law PCM audio, G.723.1 audio, G.726_32 audio, GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...

  • Page 14: Setup The Endpoint Number List

    Setup the Endpoint Number List Before configuring the Endpoint Number List, please confirm the software version of MG3000-R8 first. For users with H.323 version, please directly refer to Chapter 5.4.1; for users with SIP version, please directly refer to Chapter 5.4.2..

  • Page 15: Setup The Sip Protocol Port Number List

    To enter into the telephone number setup interface, just click the button of [Telephone Number List] in [Quick Setup], as shown in Figure 5-3： Figure 5-3 MG3000-R8 SIP Protocol Telephone Number Setup Interface GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 16: Peer To Peer Call Routing Table

    To enter into the setup interface of peer to peer call routing table, click the button of [Peer to Peer Call Routing Table] in [Quick Setup], as shown in Figure 5-4. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 17: Ip/Pstn Routing And Number Transfer Table

    Figure 5-4 MG3000-R8 Peer to Peer Call Routing Cable Setup Interface Set up the IP address of the other peer in [IP Address]. Fill in the call signal port number of the other peer in [Signal Port]. Fill in the start number with the device port of the other peer in [Start Number].
  • Page 18 The configuring operation explanation: To operating, just modify the content of list directory is invalid, it is especially to performed by the【delete】,【add】and 【modify】button. For example, request all the domestic call pass the IP and all the city call are passed the PSTN. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 19: Configuration Save And Restart

    Click the 【save & restart】 button on the 【quick configuration】page, the equipment would be save the configuration automatically and restart the PC. After the restarting, the telephone connects the FXS and could able to using. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...
  • Page 20 GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 21: Basic Configuration

    The operating details please read 5.1section. Setting the port number Please ensure the MG3000-R8 software version before the configuring the port number. H.323 version please read the 6.2.1 section; SIP version please read the 6.2.2 section. The basic port configuration of H.323 version In the section it is introduced the basic information in the 【basic configuration】->【port...

  • Page 22: The Basic Port Configuration Of Sip Version

    Figure 6.2 Port setting on the MG3000-R8 in H.323 version The operation details please read 5.4.1 section The basic port configuration of SIP version In the section it is introduced the basic information in the 【basic configuration】->【port configuration】 , and the advanced configuration would be introduced successively on the extend chapter according to the function.

  • Page 23: Configuring The Peer To Peer Route

    Figure 6.3 Port setting on the MG3000-R8 in SIP version The operation details please read 5.4.2 section. Configuring the peer to peer route The point to point could be configured except in 【quick configuration】->【peer to peer routing table】 page, it is also configured on 【advanced configuration】 -> 【peer to peer call routing table】 , it is showed as the figure 6-4: GoHigh Data Networks Technology Co., Ltd./DTT Group...

  • Page 24: Ip/Pstn Routing And Number Transfer

    IP/PSTN routing choice and number switching could be configured except in 【quick configuration】->【IP/PSTN routing and number transfer table】page, it is also configured on 【advanced configuration】 -> 【IP/PSTN routing and number transfer table】 , it is showed as the figure 6-5: GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...

  • Page 25: Speed Dialing

    Figure 6-5 the interface of IP/PSTN routing and number transfer table in MG3000-R8 The operation details please read 5.6 Section. Speed Dialing The user could recorder the common telephone number by speed dialing table, as long as dial the speed key and then the system could mapping it as the original number to call out. For example, fill in the 123 in the 【speed number】...
  • Page 26 Figure 6-6 the interface of speed dialing in MG3000-R8 When the speed number will be deleted, just fill in the ID in the first rows, and click the delete button. When the speed number will be added, just fill in the ID and the original number in the second rows, and click the add button.
  • Page 27 GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 28: The Protocol Parameter Definition

    The protocol parameter definition Before configuring the protocol parameter please confirm the MG3000-R8 software version. H.323version user please read the 7.1 sections; SIP version user please read the 7.2 sections. H.323protocol parameter definition The basic protocol parameter of H.323 is already introduced in 5.2.1section. In this section, the content is included other protocol parameter and call connection parameters, the encryption configuration would be introduced later.

  • Page 29: Calling Related Parameter Configuration

    Link overtime value: configure the overtime value when the calling terminal waiting for the callee terminal answering information Answering overtime value: configure the calling terminal send the “set up” information and wait for the ALERTING，CALL PROCEEDING，CONNECT， GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...

  • Page 30: Sip Protocol Parameter Definition

    The encrypt config will be introduced in the following chapter. As the chart 7-2 below: Figure 7-2 MG3000-R8 SIP parameters configuration interface Register Parameter Configuration Local port: set up the UDP port numbers of the local computer SIP register information.

  • Page 31: Calling Related Parameter Configuration

    Replacing Agreement Type In the “Advanced Config->System Config” page, choose the signal protocol type, as chart7-3: GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...
  • Page 32 When switching between the SIP agreement and H.223 agreement, the set up has to be saved and restart the equipment, then it can take effect. Current controlled edition needs to eliminate the IE buffer memory. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...
  • Page 33 GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 34: Dsp Detail Parameter Configuration

    “DSP detail parameter set up” is in the “Basic Config-> Channel Setting” page, in order to set up the parameter used for building media channel, as chart 8-1: Figure 8-1 MG3000-R8 channel setting interface Input the channel number in “Channel Number”. If it is “0”, it means all the channel will be configured the same parameter.

  • Page 35: Configure Voice Gain

    Transmission mode: The Transmission mode of FAX, can be T.38 FAX Relay or penetrate (use the currently code mode of voice to code. Only can use penetrate under the voice code manner of G.711 ) GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 36: Dtmf Parameter Configuration

    RFC2833 redundancy gain load type (96-127): RFC2833 redundancy gain load type of DTMF message(the value of RFC2833 gain load type must be different from RFC2833 redundancy gain load type ) RFC2833 transmission mode: Setting RFC2833 transmission mode. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...

  • Page 37: Www.datangnetwork.com

    GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 38: Fxo Analog Junction Function Configuration

    (The configuration of FXO number regenerate see as Figure 9.4) or dial the number of FXO. You make second dial after you hear the dial tone, it can dial the GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 39: Configuration ""Double Mode" Of Fxo

    The item of “play voice recording” is valid only under normal mode. If you choose “yes”, the call comes from PSTN will send second dial indicate tone, such as “welcome to Datang Gohigh, please dial extension number, if you want to get number infromating you can dial 0”; If you choose “No”, the call comes from PSTN will send second dial tone.

  • Page 40: Configuration "Double Mode" Of Fxo

    In the interface of 【advanced configuration 】-> 【system configuration 】, can configure the “FXO pattern of call restriction” as the figure 9-1 is illustrated. If you choose “unrestricted”; all the PSTN caller number will permit to incoming. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 41: Pstn Incoming Call List

    PSTN to input in the 【advanced configuration 】 , 【 user management of the white list】as the figure 9-3 is illustrated: Figure 9-3 MG3000-R8 the interface of user management in white list PSTN incoming call list FXO receive the call from PSTN, and through the second dial (common mode) to dial the extension, or call it automatically to the attendant number（attendant mode）...

  • Page 42: The Signal Advice Of Charge For Charging By Pstn

    FXO is picked up and begin to billing, you should choose “sending in normal”; if the callee from PSTN is picked up and begins to billing, you choose “after receiving the reverse signal ” GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 43: Management

    And the page will be refurbished automatically in each 5senconds, and the figure 10-1 is followed. Figure 10-1 MG3000-R8 interface of port estate Check the edition information In the page layout of 【information check】 -> 【system information 】 , you can check the edition...

  • Page 44: Edition Upgrade

    Figure 10-2 MG3000-R8 interface of system information Edition upgrade In the page layout of 【equipment management】-> 【upgrade management】 and can make the edition upgrade. ， down load of configuration document or operation of picking up configuration document, the figure 10-3, first choose the transmission protocol, and can choose the HTTP（recommendation）or TFTP protocol.

  • Page 45: Www.datangnetwork.com

    Figure 10-3 the interface of MG3000-R8 upgrade management If you choose the protocol of HTTP protocol, click “yes”button and enter into the interface of upgrade edition, figure 10-4 as follows; GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...

  • Page 46: Www.datangnetwork.com

    Figure10-4The interface of MG3000-R8 HTTP upgrade management If need the upgrade program, In the “document type” choose “program document”, click the button of “browse” to choose the program document which will download, and click the button of “upgrade”, after finishing the upgrade, the system will prompt the “program document download successes, it need reboot the...

  • Page 47: Www.datangnetwork.com

    If choose the TFTP protocol，click “yes” button and into the interface of upgrade edition. The figure 10-5 is showed as the following: Figure 10-5 MG3000-R8 TFTP interface of upgrading management When use the TFTP protocol to upgrade, it needs to provide the TFTP sever and the IP address which is download and upgrade the document.

  • Page 48: Amending The User Password In Web

    WEB console password, the figure 10-6 is as follows. Attention: it amending the user password, and the user name cannot revise. Figure 10-6 MG3000-R8 interface of passport management Resume the beginning configuration In the page layout of 【equipment management】-> 【resume the configuration 】, it can make it to be acquiescence, the figure 10-7 is showed as follows: GoHigh Data Networks Technology Co., Ltd./DTT Group...

  • Page 49: Save Configration

    Figure 10-7 MG3000-R8 the interface of resume the configuration Click the “yes” button, and after resume the acquiescence setting, it should be save reboot and it will become effective. Save Configration The “save config” page will save configuration as the figure 10-8.

  • Page 50: Restart Device

    Figure 10-8 MG3000-R8 Save config page Restart Device The 【Restart Device】page will have the MG3000-R restart, as the figure 10-9 shown. Figure 10-9 MG3000-R8 Restart GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...

  • Page 51: Other Configration

    Encrption In the 【Basic Config】->【Protocol】page, select Encryption Type and key under your service provider’s advise. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...

  • Page 52: Www.datangnetwork.com

    Figure 11-1 MG3000-R8 Protocol parameters page In the item 【Encryption Type】, there are options including no encryption, encryption algorithm 1, encryption algorithm 2, encryption algorithm 3. In the item【key】 ,input your key. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 53: Www.datangnetwork.com

    GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 54: Faq

    2、 In normal mode or attendant mode, calls from PSTN arrived the CO line that FXO port connected, the number transfer will take place on the second stage dial number( the normal mode) or the attendant number ( the attendant mode). GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 55: The Item "Iptopstn Prefix Strip Len" And "Iptopstn Prefix Number" Of 【Ip/Pstn Routing And Number Transfer Table

    The VOIP side user call to 01062303100, This call will route to a MG3000-R. The gateway will cut the prefixed 3 number 010 of “01062303100”, add a prefix 0. The result of number is GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 56: Number Regeneration Usage

    If the second dial failed in normal mode or connect attendant failed under attendant mode in the call from PSTN, please check the IP/PSTN Routing and Number Transfer Table. If the GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 57: How To Check The Device's Serial Number And Mac Address

    2、 In the internet explorer, select “Tools”=>”Internet Options”, click “Delete files”, on the pop up dialogue box , don’t select “Delete all offline content”, click ‘ok’. 3、 Login into the web page again. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 58: Www.datangnetwork.com

    GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn Add: No.40 Xueyuan Road, Haidian District, Beijing China 100083...

  • Page 59: Application Example

    The caller will hear the ringback tone only before timeout. no Register mode: When MG3000-R used in Call back for terminateon, it can be used in no Register mode. The call will route to this gateway directly. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com...

  • Page 60: Remote Extension

    Have the FXO gateway ‘s voip number set to 91728; Set to attandent mode. The attendant number is the MG3000-A’s extention number. Addtionally, those two device should set the same DTMF method. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...

  • Page 61: Tel: 8610-62302956 Fax: 8610-62301900

    FXO gateway mode: double mode. IP/PSTN route table：set the call out route rule； FXO port ringback time: if there is Caller ID display from PSTN, this parameter must >1. GoHigh Data Networks Technology Co., Ltd./DTT Group Web: www.datangnetwork.com Tel: 8610-62302956 Fax: 8610-62301900 E-mail: voip@gohigh.com.cn...
