Summary of Contents for Russell Hobbs RHM1714RC
- Page 1 Microwave USER’S GUIDE Model No: RHM1714RC, RHM1714 CC, RHM1714 BC For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com IMPORTANT: RETAIN FOR FUTURE...
-
Page 2: Table Of Contents
Contents Page Safety instructions …………………………….……….. Product overview ………………………………..….. About this microwave oven ……………………………….…….. Unpacking the microwave ……………………………………… Microwave oven installation ……………………………………… Turntable installation ……………………………………… Control panel ……………………………………… Using the microwave oven ……………………………………… Cleaning and care ……………………………………… Important utensil information ……………………………………… Connection to the mains supply ………………………………………... -
Page 3: Safety Instructions
Safety instructions IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 Safety instructions WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person. WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
- Page 5 Safety instructions If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
- Page 6 Safety instructions A minimum clearance of 7.5cm is required between the oven and any adjacent walls. One side must be open. Leave a minimum clearance of 30cm above the oven. The microwave oven should be used freestanding only and must not be built-in or used in a cabinet. If smoke is emitted , switch off or unplug the appliance and keep the door closed in order to stifle any flames.
- Page 7 Safety instructions Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended. The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
- Page 8 Safety instructions Do Not obstruct the ventilation from the microwave Only use thermometers that are approved for microwave ovens.
- Page 9 Safety instructions • Food containing a mixture of fat and water (for example, stock) should stand for 30 to 60 seconds in the oven after it has been turned off. This is to allow the mixture to settle and to prevent it from bubbling when a spoon is placed in it, or a stock cube is added.
- Page 10 Safety instructions • The microwave is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, wheat bags, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire. • Heat from the contents of a container may be transmitted to the container itself, so please be careful when removing it from the oven.
- Page 11 Safety instructions • Do not use metal pans or dishes with metal handles. • Do not use anything with a metal trim. • Do not use paper covered wire twist-ties on plastic bags. • Do not use melamine dishes as they contain a material which will absorb microwave energy.
-
Page 12: Product Overview
Product overview 1. Door safety lock system 2. Oven window 3. Turntable support 4. Control panel 5. Wave guide cover 6. Glass tray WARNING: Do not use the oven when empty or for warming plates. Always keep the oven cavity, door assembly and waveguide cover clean For Customer Services &... -
Page 13: About This Microwave Oven
About this microwave oven Microwaves are high-frequency electromagnetic waves similar to radio waves. While radio waves may vary in length from one metre to many kilometres, microwaves are very short (less than 12.5 centimetres). Microwaves do not make any heat themselves but only cause water molecules in food to vibrate. -
Page 14: Unpacking The Microwave
Unpacking the microwave Before you use your microwave oven 1. Remove all the packaging. Do not remove the small piece of card from the right hand side of the cavity wall. This is called a wave-guide cover and allows the microwaves to pass through to cook the food. Please ensure you keep this cover clean at all times. -
Page 15: Microwave Oven Installation
Microwave oven installation • Select a level surface that provides enough space for the outlet vents. • A minimum clearance of 7.5cm is required between the oven and any adjacent walls. One side must be open. Leave a minimum clearance of 30cm above the oven. -
Page 16: Turntable Installation
Turntable installation • Before first use, check that any securing tape has been removed from the glass tray and turntable ring assembly. These parts must never be restricted from rotating. • Never place the glass tray upside down. • Both the glass tray and turntable ring assembly must always be used during cooking. -
Page 17: Control Panel
Control panel Display Cooking time, power, action indicators, and clock time are displayed. Power Press this button a number of times to set a cooking power level. Multi Stage Cooking Press this button to set a multi-stage cooking program. Pre-Set Press this button to set a pre-set cooking program. -
Page 18: Using The Microwave Oven
Using the microwave oven Connect the main plug into a suitable 13amp mains socket, make sure the voltage is the same as on the rating label (do not use extension cables or mains socket adaptors). The microwave oven will beep once and the display will show the clock symboll. Note: during any of the following cooking programs, to pause cooking, press the 'Stop/Cancel' button. - Page 19 Using the microwave oven Microwave cooking(Cooking times between 10 seconds and 60 minutes) Press the 'Power' button a number of times to choose a cooking power level, then turn the 'Time/Menu.' knob clockwise to choose the time. Press the 'Time/Menu.' knob to start cooking. You can microwave food using 6 settings: Press the power button Cooking power...
- Page 20 Using the microwave oven Please note: 'End' will be displayed and 4 beeps will be heard every 2 minutes until the oven door is opened or the 'Stop/Cancel' button is pressed. Quick start cooking This program allows you to cook food at 100% power between 30 seconds and 12 minutes by pressing the 'Time/Menu' knob directly.
- Page 21 Using the microwave oven 5. When the food has finished defrosting the oven will beep 4 times to let you know and the word 'End' will be displayed. Please note: 'End' will be displayed and 4 beeps will be heard every 2 minutes until the oven door is opened or the 'Stop/Cancel' button is pressed.
- Page 22 Using the microwave oven Hints Do not cook, reheat or defrost foods directly on the turntable. always put the food into a suitable microwave container. Do not cook foods such as meat from frozen, always defrost the foods first. Where appropriate cover dishes with microwave safe cling film and pierce, this will retain the moisture and prevent splashing and spillages.
- Page 23 Using the microwave oven Auto Food Weights Recommendations menu Place the cup onto the center of the Milk/Coffee 1-200ml turntable. When the liquid has been 2-400ml removed from the oven, leave to stand 3-600ml before adding sugar. Rice 150g Place the rice into a suitable container, 300g cover with water.
- Page 24 Using the microwave oven Multi-stage cooking oven has the ability to set multistage cooking. You can combine any 2 cooking programs at once. you are using 1 function the display will show '1s' (1 stage cooking) you are using 2 functions, the display will show '2s'...
- Page 25 Using the microwave oven Pre-set You can pre-set the oven to start cooking at a later time. For example, current time is 14:30pm, you can set the oven to start at 16:30pm and cook for 20 minutes. 1. Place the food a container suitable for use...
- Page 26 Using the microwave oven Kitchen timer The kitchen timer is used to set a countdown time for the convenience of the user, it can be used as a reminder. 1. Press the 'Kitchen timer' button. 2. Turn the 'Time/Menu' knob to the length of time required. 3.
-
Page 27: Cleaning And Care
Cleaning and care • Before you clean the oven, turn it off and unplug it. • Keep the inside of the oven clean. When food or liquids stick to the oven walls, wipe with a damp cloth. We recommend that you do not use harsh detergent or abrasives. -
Page 28: Important Utensil Information
Important utensil information • Do not use metal pans or dishes with metal handles. • Do not use anything with a metal trim. • Do not use paper covered wire twist-ties on plastic bags. • Do not use melamine dishes as they contain a material which will absorb microwave energy. -
Page 29: Connection To The Mains Supply
Connection to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC230V ~ 50HZ. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. If this plug is unsuitable or needs to be replaced, please note the following: Important: The wires in the mains lead are coloured in accordance with the following code:... - Page 30 Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which...
-
Page 31: Problem Solving & Plug
Problem solving & plug Problem solving The microwave oven may cause interference to your radio, TV or similar equipment. If it does, you can get rid of the interference by moving the radio, TV or equipment as far away from your microwave oven as possible. -
Page 32: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the store. The following conditions apply: •... -
Page 33: Technical Specification
Rated Voltage 700W Rated Output Power(Microwave) Oven Capacity 262mm x 452mm x 360mm External Dimensions(HxWxD) Net Weight; Approx 10.5 kg Product name: RHM1714RC RHM1714CC RHM1714BC Site code: 15A.10.13.205 15A.10.13.208 15A.10.13.210 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am –... -
Page 34: Spare Parts
Spare parts The following spare parts are available from www.productcareuk.com Glass turntable Turntable support Wave Guide cover For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com... - Page 35 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
- Page 36 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com Revision 4 This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
