Avsl 154.016UK User Manual

Any damage caused by misuse of the product will void the warranty.

Item description

Item reference
Power
LED type
Power consumption
Fuse type
Illuminance
Beam angle
Dimension
Weight

Manual control

Press 'MENU' button to navigate through setting options, press 'UP' and 'DOWN'
buttons to choose setting values and finally press 'ENTER' to confirm setting.
A000 to A512 – DMX initial address setting
R000 to R255 – Red dimmer for colour mixing
G000 to G255 – Green dimmer for colour mixing
B000 to B255 – Blue dimmer for colour mixing
H000 to H255 – White dimmer for colour mixing
1E00 to 1E20 – Single colour jump strobe, speed decreases with value increase
2E00 to 2E20 – Full LED strobe, speed decreases with value increase
1F00 to 1F20 – Red LED only, brightness increases with value
2F00 to 2F20 – Green LED only, brightness increases with value
3F00 to 3F20 – Blue LED only, brightness increases with value
4F00 to 4F20 – White LED only, brightness increases with value
5F00 to 5F20 – Red and white LED only, brightness increases with value
6F00 to 6F20 – Green, blue and white LED only, brightness increases with value
7F00 to 7F20 – RGBW full LED, brightness increases with value
COMPACT PLASTIC LED PAR CANS
Item refs: 154.016UK & 154.017UK
Please do not open cover as it contains high voltage.
This product is not serviceable or repairable by the end user.
Please refer to qualified personnel for service or repair.
Please read this manual thoroughly before use.
Compact LED PAR56 Can
154.016UK
100-240Vac, 50/60Hz
186 x 10mmØ
(42 x red, 42 x green, 42 x blue, 60 x white)
30W
F1A
1700lux @ 2m
25°
200 x 200 x 64mm
1kg
User Manual
Compact LED PAR48 Can with remote
154.017UK
100-240Vac, 50/60Hz
154 x 10mmØ (36 x red,
48 x green, 46 x blue, 24 x white)
20W
F1A
1500lux @ 2m
25°
173 x 173 x 105mm
1kg
