Model No
MX0404-330

Operating Instructions

Thanks for purchasing our product.
Please be sure to read this instruction manual
carefully before using our product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX0404-330 and is the answer not in the manual?

Questions and answers

Summary of Contents for Grandbeing MX0404-330

  • Page 1: Operating Instructions

    Model No MX0404-330 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product.
  • Page 2 Introduction Grandbeing’s MX0404-330 is a 4-by-4 DVI/HDMI true matrix. It allows any source (Blue-Ray player, HD DVD player, satellite receiver, game system, etc.) to be shown on the any of the four displays simultaneously, no matter the source is HDCP or not. Extra infrared receiver extension, IR emitter are supplied for the control.
  • Page 3: Table Of Contents

    Contents HDMI Matrix..................... 1 Product Overview .................... 1 Features......................1 Package Contents.................... 3 Panel Descriptions ................... 3 Connections and Operations ................4 SPECIFICATIONS ................... 7 Typical Application ................... 8 Maintenance ....................9 Product Service ....................9 ● Provided Service ..................9 ●...
  • Page 4: Hdmi Matrix

    With extra infrared receiver extension. Two switching modes: panel buttons, local IR. HDCP compliant. HDMI 1.4 version. Notice Grandbeing Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Page 1...
  • Page 5 Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
  • Page 6: Package Contents

    ④ 4x IR_RX (IR receiver) extension cable. ⑤ 4x IR_TX (IR emitter) extension cable. ⑥ 4x IR_RX cable extender jack pair. (Refer to page 8). ⑦ Operating Instructions. P/N_INS MX0404-330. ⑧ 2x Mounting Ear. NOTE: PART NUMBER (Abbreviation as P/N).
  • Page 7: Connections And Operations

    Power on the input source you want to show. (Keep the unused input power off, otherwise it may interfere the normal display.) Connect the power supply into MX0404-330 and turn on the display you want to watch. Use remote or push the button to choose input source.
  • Page 8 This function applies to the situation when the source's HDMI version exceeds the sink's HDMI version. (This function can be used to fix the deep color, 1080P, 1080i, 2ch audio, multi channel audio issue.) For example: When the TV is HDMI 1.2 version and PS3 source is HDMI 1.4 version, it will output HDMI 1.2 version.
  • Page 9 DIP switch setting Position ID Mix the low version EDID.(default) (note 1) reserved reserved reserved Copy the EDID of the display which connected the OUTPUT1(note 2) reserved reserved reserved reserved Note1: The matrix will mix the EDID data of the sink devices. The mixed EDID data will use the lowest resolution of the video and the least channel number of the audio.
  • Page 10: Specifications

    SPECIFICATIONS ■ Operating Temperature Range -5 to +35°C (-41 to +95 °F) Operating Humidity Range 5 to 90 % RH (no condensation) Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) Signaling Rate 2.25Gbit/s DTV/HDTV: Video Format Supported 1080p/1080i/720p/576p/480p/576i/480i Audio Format Supported DTS-HD、Dolby trued...
  • Page 11: Typical Application

    Use the male jack and female jack to extend the IR_RX cable like the picture below. MX0404-330 Typical Application ■ Page 8...
  • Page 12: Maintenance

    Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit. Product Service ■ ● Provided Service Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;...
  • Page 13: Warranty

    Warranty If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the length of the period indicated as below, (Parts (1) Year, Labor(90) Days)which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished...
  • Page 14 There are no express warranties except as listed under “limited warranty coverage”. The warrantor is not liable for incidental or consequential damages resulting from the use of this product, or arising out of any breach of this warranty. (As examples, this excludes damages for lost time, cost of having someone remove or re-install an installed unit if applicable, travel to and from the service location, loss of or damage to media or images, data or other recorded content.
  • Page 15 Grandbeing Technology Co., Ltd. Address: 6C, Jialitai Building, No. 6 Yanshan Road, Nanshan District Shenzhen, P.R. China Tel: 86-755-26678449 Fax: 86-755-26678549 Post Code: 518067 www.grandbeing.biz...
