- Page 1 CC Pilot XS, rev. 1.3 080812 CC Pilot™ XS User Manual and Reference Handbook CC Pilot™ XS Basic CC Pilot™ XS Extended CC Pilot™ XS All-Integrated...
-
Page 2: Table Of Contents
User Manual and Reference Handbook for the CC Pilot™ XS Table of Contents Introduction....................................4 Identification ..................................4 Care......................................4 Environment and Environmental Tolerance........................5 Cleaning....................................5 Overview ..................................... 6 CC Pilot™ XS Front Face ..............................7 CC Pilot™ XS Rear Side..............................7 Set-up and configuration................................ - Page 3 User Manual and Reference Handbook for the CC Pilot™ XS Program installation................................40 Connect to the GPS receiver............................40 Creating a dial-up connection with the GSM/GPRS modem..................40 Using the FTP server.................................42 Using Telnet server................................42 Specifications ...................................43 Computer Core...................................43 Interfaces.....................................43 Power Supply..................................44 Display....................................44 GPS ......................................44 GSM/GPRS ..................................45 Bluetooth....................................45...
-
Page 4: Introduction
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Introduction In this user manual and reference handbook you, as a user, a reseller or system integrator, will find important information about the CC Pilot™ XS. The handbook will guide you and broaden your knowledge about this onboard computer’s technical possibilities and advantages. -
Page 5: Environment And Environmental Tolerance
User Manual and Reference Handbook for the CC Pilot™ XS Consider traffic safety when the CC Pilot™ XS is installed and whenever it is used. CC Systems AB does not recommend that CC Pilot™ XS or its accessories be used actively by the driver when a risk of injury to people, or damage to property, is present. -
Page 6: Overview
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Overview The CC Pilot™ XS is a compact, robust and versatile onboard computer for Windows CE 5.0. It is equipped with, among other things, a pressure-sensitive touch screen as well as a large number of connection alternatives such as CAN, COM, Ethernet and USB. -
Page 7: Cc Pilot™ Xs Front Face
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Front Face On the front face of the CC Pilot™ XS there are the touch screen, a button for switching the unit on/off as well as buttons for adjusting the screens brightness level. Furthermore, there is a status indicator and a light sensor to aid in adapting the screen’s brightness level. -
Page 8: Set-Up And Configuration
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Set-up and configuration The CC Pilot™ XS uses Windows® CE 5.0 as operating system, which enables the use of a multitude of applications in various fields of interest. Even though CC Pilot™ XS has been designed to handle greater stress and a harsher surrounding environment than ordinary computers, it is built to be as simple as possible to handle. -
Page 9: Basic Operations
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Basic operations This section covers basic operation of the CC Pilot™ XS unit such as start-up shut down. For more information on usage please also see the Software chapter. Function of the Display’s Push-buttons On/Off button Increase Display’s... -
Page 10: Status Indicating Function
User Manual and Reference Handbook for the CC Pilot™ XS Connecting the Power Supply. Status Indicating Function On the front side of the CC Pilot™ XS there is a status indicator, a red LED, which is used to indicate different states for your CC Pilot™ XS during start up. A 1Hz flashing red light indicates that the unit is starting up normally. -
Page 11: Reset Of The Unit
User Manual and Reference Handbook for the CC Pilot™ XS Don’t use sharp or pointed objects on the touch screen since these can damage or scratch it, which can seriously degrade its functionality. Reset of the unit Using the On/Off button in combination with the brightness buttons it is possible perform three modes of advanced start ups, forcing registry clean and formatting of Compact Flash. -
Page 12: Module Description
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Module description This section deals with the various parts which make up the CC Pilot™ XS and how they are used. Depending on your CC Pilot™ XS version Basic, Extended or All- Integrated the configuration this section can handle functions and interfaces which are not applicable to your unit. -
Page 13: Usb
User Manual and Reference Handbook for the CC Pilot™ XS Via the USB port, you can connect a multitude of devices to the CC Pilot™ XS. For some devices, however, drivers compatible with the operating system are required to be installed in order for the device to function. In the Microsoft Windows CE operating system, which comes standard with the CC Pilot™... -
Page 14: Gprs/Gsm
User Manual and Reference Handbook for the CC Pilot™ XS GPRS/GSM The CC Pilot™ XS All-Integrated has an integrated GPRS/GSM modem for data connection and access, for example, the internet or company network. The modem has support for dual band (900/1800 MHz) and GPRS class 8 which gives a maximum transfer speed of 85,6 Kbit/s. -
Page 15: Connectors
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Connectors Connectors Accessible on the rear and top of CC Pilot™ XS, there are a number of ports to connect various peripheral equipment. In order to give the CC Pilot™ XS its high environmental classification, the unit is equipped with DIN M12 connectors. - Page 16 User Manual and Reference Handbook for the CC Pilot™ XS Power Supply Connector Marking: X1 POWER Connector Type: DIN M12 4-pole, A-coded, male Description Battery(+28 VDC) ON/OFF (+28 VDC) The CC Pilot™ XS power supply can range from 10 – 36 volts. If the power supply voltage goes beyond this range, the unit shuts down.
- Page 17 User Manual and Reference Handbook for the CC Pilot™ XS Ethernet (Ethernet 1, Ethernet 2) Marking: X1 Ethernet1 and X3 Ethernet2 Connector Type: DIN M12 4-pole, D-coded, female Pin Signal The ports support 10/100 Mbps, i.e. communication speed up to 100 Mbps. CAN (CAN1, CAN2) Marking: X6 CAN1 and X7 CAN2 Connector Type: DIN M12, 5-pole A-coded, female...
- Page 18 User Manual and Reference Handbook for the CC Pilot™ XS Misc Port (COM1) Alternatively: Audio, Communication and or Digital Input (MISC) Marking: X5 MISC Connector Type: DIN M12, 8-pole, A-coded, male. NOTE! This connector has two alternative functions depending on the configuration ordered.
- Page 19 User Manual and Reference Handbook for the CC Pilot™ XS Marking: X8 USB1 and X9 USB2 Connector Type: DIN M12, 5-pole, A-coded, male Pin Signal Description Vbus Power supply to external USB unit. 5 V, 500mA max, Internal short-circuit and overload protection Data Data...
- Page 20 User Manual and Reference Handbook for the CC Pilot™ XS GPS-antenna Marking: GPS Connector Type: SMA, female This connector is used to attach the antenna to the GPS receiver. The cable which is used to connect the GPS antenna to the computer shall be a 50-O coaxial cable which has low attenuation at high frequency (˜...
-
Page 21: Installation
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Installation Your CC Pilot™ XS must be installed in such a way that the unit is not exposed to any unnecessary stress or present any traffic danger. In this section, some recommendations are made regarding methods for how the unit should be installed. - Page 22 User Manual and Reference Handbook for the CC Pilot™ XS Panel Mount There are two installation alternatives for panel mounting: front-mounted or rear- mounted With a front-mounted installation, use the rubber mask as a seal against the panel plate. The unit is locked down by applying clamps which are either fixed to the panel (recommended) or fixed to the unit through holes for VESA75 installation.
- Page 23 User Manual and Reference Handbook for the CC Pilot™ XS Display Panel Dimensions for 10,4”...
- Page 24 User Manual and Reference Handbook for the CC Pilot™ XS Display Panel Dimensions for 6,5”...
- Page 25 User Manual and Reference Handbook for the CC Pilot™ XS Installing the SIM card The SIM card is installed in a SIM card holder under the SIM card cover. Install the SIM-card by unscrewing the six screws holding the SIM card cover and lift the cover away.
- Page 26 User Manual and Reference Handbook for the CC Pilot™ XS Connecting the Power Supply This instruction addressed vehicle installations but the principle is the same also for other types of installations. See also the description of the pinouts for the Power Supply Connector under the section Connectors.
-
Page 27: Software
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Software This section gives a short description to some of the software supplied with the CC Pilot™ XS. Operating System The CC Pilot™ XS is supplied with the Windows CE operating system and this manual provides the basics how to get started with basic operations and configurations. - Page 28 User Manual and Reference Handbook for the CC Pilot™ XS The Desktop Name Description My Computer To access the computer’s hard disc (Compact flash) Internet Explorer To access the internet browser Start button To start programs and access the Control Panel Network status Information about the network connection and access to network settings...
- Page 29 User Manual and Reference Handbook for the CC Pilot™ XS Navigating the Desktop Using the touch screen with a stylus or finger, one can navigate in Windows CE and the applications being in use. Besides the touch screen, keyboard and mouse connected via the USB port can also be used.
- Page 30 User Manual and Reference Handbook for the CC Pilot™ XS NOTE! To prevent the loss of information, which is stored on the hard disc, the unit must be shut down correctly. If the unit shuts down incorrectly or the power is switched off to the unit this can lead to corrupt files and damage to the hard disc.
- Page 31 User Manual and Reference Handbook for the CC Pilot™ XS Set Time and Date Open the settings for time and date through Date/Time in the Control Panel. Input the date, time and time zone. Activate these settings by pressing the button Apply. Configure Power Properties Choose Power Properties on the Control Panel to chose which energy profile to be used by your CC Pilot™...
-
Page 32: Xs Settings
User Manual and Reference Handbook for the CC Pilot™ XS Changing the input language The toolbar shows the input language that is currently used. To temporarily change the input language click on the icon and select the desired input language. To permanently change the input langue, select Regional setting from the Control Panel. - Page 33 User Manual and Reference Handbook for the CC Pilot™ XS From the CAN tab, settings are made for CAN message frame mode and baud rate. By pressing the default button the CAN settings will be reset to predefined default settings. From the GPS tab, status can be read for the GPS and the baud rate of the GPS can be altered.
- Page 34 User Manual and Reference Handbook for the CC Pilot™ XS From the GSM tab status information are displayed for the GSM modem. From here it is also possible to turn on or off the PIN code of the SIM-card. To turn on or off the PIN-code please: 1.
- Page 35 User Manual and Reference Handbook for the CC Pilot™ XS On: black tick in the checkbox. The power output will switch on when the system enters the particular system mode. Off: empty checkbox. The power output will switch off when the system enters the particular system mode.
-
Page 36: Cc Video
User Manual and Reference Handbook for the CC Pilot™ XS surrounding light; therefore the setting may vary depending on whether it is changed in bright of dark environments. CC Video CC Video is the application used to view the video input signals from the video, X4, connector on the CC Pilot™... - Page 37 User Manual and Reference Handbook for the CC Pilot™ XS Selecting video channel To select which camera channel to display, press the desired channel button or select the desired channel from the view menu. Changing video display size The size of the video window is changed by selecting from the predefined sizes using the pop up menu or the view menu.
-
Page 38: Microsoft Activesync
User Manual and Reference Handbook for the CC Pilot™ XS CC Video can also be controlled from external application using a function interface. For more information about interaction with CC Video please contact your dealer. Microsoft ActiveSync Microsoft ActiveSync is a desktop computer tool for Windows used to synchronise information between the desktop computer and CC Pilot™... - Page 39 User Manual and Reference Handbook for the CC Pilot™ XS When the dialogue Get Connected is shown, the following steps must be carried out so that a connection can be established with the CC Pilot™ XS: Ensure that the CC Pilot™ XS is connected via a null modem cable to a Start the CC Pilot™...
-
Page 40: Program Installation
User Manual and Reference Handbook for the CC Pilot™ XS Program installation Different Windows CE programs have different requirements on how they shall be installed. The most common is either that they are installed directly on the CC Pilot™ XS or via Microsoft ActiveSync. Consult the instructions for the program you are installing to learn exactly how the program is installed. - Page 41 User Manual and Reference Handbook for the CC Pilot™ XS Chose the internal GSM/GPRS modem on COM3. Depending on the connection, an extra AT-command may be needed.. This is done under Configure. Chose the tab Call Options in the dialogue which opens and type in the AT-command under Extra Settings.
-
Page 42: Using The Ftp Server
User Manual and Reference Handbook for the CC Pilot™ XS Depending on the cellular network provider and what type of connection is to be made, individual settings may be necessary. Contact your provider or network administrator for the correct settings. Using the FTP server CC Pilot™... -
Page 43: Specifications
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Specifications Computer Core Core Component Description Comments Processor Intel XScale, 533 MHz Kernel Flash 32 MB Strata flash For operating system Compact Flash 1 GB For application and user data 256 MB SDRAM EEPROM... -
Page 44: Power Supply
User Manual and Reference Handbook for the CC Pilot™ XS Power Supply Power Supply Description Comments Supply Voltage 10 to 36 V Power Consumption Max 1A at 24 V With10.4” displays. Varies depending on background lighting. Display Display Description Comments 6,5”... -
Page 45: Gsm/Gprs
User Manual and Reference Handbook for the CC Pilot™ XS GSM/GPRS GSM/GPRS Description Comments Frequency Band Dual-band EGSM 900, GSM1800 Broadcast strength Class 4 (2W) with EGSM900 Class 1 (1W) with GSM1800 GPRS GPRS multi-slot class 8 GPRS mobile station class B DATA GPRS max download speed: 85.6 kbps... -
Page 46: Environmental Tolerance
User Manual and Reference Handbook for the CC Pilot™ XS Environmental Tolerance Environmental Test Standard Comments Vibration IEC 60068-2-64 0,01 g /Hz 5-200 Hz 1,39g (RMS) 1h Shock IEC 60068-2-27 5 g/30 ms ±3x3 Dry Heat EN 60068-2-2 Bd Operating: +65°C, 24h Storage: +70°C, 24h Damp Heat EN 60068-2-30 Db... -
Page 47: Weight And Dimensions
User Manual and Reference Handbook for the CC Pilot™ XS Weight and Dimensions 10.4” Description Comments Enclosure size 285,5 x 217 x 58,4 mm (W x H x D) Display size 210,6 x 159 x 53,8 mm (W x H x D) Weight ca 1.7kg Depending on... - Page 48 User Manual and Reference Handbook for the CC Pilot™ XS...
- Page 49 User Manual and Reference Handbook for the CC Pilot™ XS 6.5” Description Comments Enclosure size 210.8 x 172.9 x 58.4 mm (W x H x D) Display size 198 x 163 x 53.8 mm (W x H x D) Weight ca 1.3 kg Depending on configuration...
- Page 50 User Manual and Reference Handbook for the CC Pilot™ XS...
-
Page 51: Technical Support
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Technical Support Contact your reseller or supplier for help with possible problems with your CC Pilot™ XS. In order to get the best help, you should have your CC Pilot™ XS in front of you and be prepared with the following information before you contact support. -
Page 52: Glossary
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Glossary Bluetooth, is an open standard for wireless communication in the 2.4 GHz range. It is built for low power consumption and is used to connect together units such as cell phone, printer, keyboard, pointing instrument and computer. - Page 53 User Manual and Reference Handbook for the CC Pilot™ XS NC, Not Connected. The socket, or a pin in the socket, is without an internal connection and can not be used. NMEA-0183, Protocol for GPS communication from the National Marine Electronics Association, which was originally developed for marine use but is now an accepted de facto standard for GPS communication in many different regions.
-
Page 54: References
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS References http://www.cc-systems.com http://www.ELFA.se/ http://www.nmea.org/pub/0183/ http://www.hardwarebook.net/ Trade Mark, etc. © 2008 CC Systems AB All trademarks sighted in this document are the property of their respective owners. CC Pilot is a trademark which is the property of CC Systems AB. Intel XScale is a registered trademark which is the property of Intel Corporation in the USA and/or other countries. -
Page 55: Index
User Manual and Reference Handbook for the CC Pilot™ XS CC Pilot™ XS Index Enclosure............46 Enclosure size 6.5..........49 Enclosure size, 10.4 ........47 Accuracy............44 Environmental Test.......... 46 ActiveSync............38 Environmental Tolerance......5, 46 Adapter cables..........15 Ethernet............12, 43 ARM processors.......... - Page 56 User Manual and Reference Handbook for the CC Pilot™ XS LAN..............52 Shock..............46 Light Emitting Diode......... 10 Shutting Down the CC Pilot™ XS ....10 Linux..............27 SIM ..............53 SMS ..............45 Software............. 27 Software installation..........8 Maintenance............5 Specifications............ 43 Mbps..............
- Page 57 User Manual and Reference Handbook for the CC Pilot™ XS Manufacturer contact information Sales contact productsales@cc-systems.com Phone +46 (0)271 193 80 Address CC Systems AB +46 (0)271 193 89 Box 83 www.cc-systems.com SE-822 22 Alfta General contact info@cc-systems.com Sweden...
