Norman D12 Instruction Manual

D12 and D24 Digital Power Supply
D12R and D24R Digital Power Supply
Instruction
Manual
For
Models:
INTRODUCTION
Thank you for purchasing a Norman Power Supply. Welcome to the Norman family of
interchangeable high-quality flash equipment. The utilization of larger high-duty-cycle flash
capacitors and related components enables this Power Supply to be utilized for demanding
commercial and portrait silver halide and digital applications.
FEATURES
o D12: 1200 watt-second capacity and D24: 2400 watt-second capacity. The D12 and
D24 is an honest 1200/2400 watt-seconds respectively.
o 1/20-stop repeatability at full power. Holds this tolerance with line voltages from 105
to 125 volts.
o 2 Independently controlled channels, symmetric or asymmetric operation.
4-lamp head connectors (2 per channel) with individual on/off switches.
o
Misfire alarm for each lamphead.
o
Fan Cooled
o
Digital controls with LED display. Adjustable in 1/10-stop increments.
o
Audio and visual ready indication (switchable).
o
Built in photo-eye (switchable).
o
Modeling light full/ratio/trim modes.
o
o Error condition diagnostic readouts via internal software, as displayed in the LED
arrays.
o Automatic thermal protection.
Slow recharge selection.
o
o Interchangeable with the entire Series 900 line. Over 80 lamphead and accessory
items support the D12 and D24 digital power supply.
Full two year limited warranty, including parts and labor.
o
Optional built in Pocket Wizard. D12R and D24R.
o
2
