FOR ALLURE DP320 STUDIO FLASHES
1.
INTRODUCTION
This DC Power Pack for Studio Flashes is primarily designed for use with the Allure
DP320 studio flash in DC mode, a Norman product from Photo Control Corporation,
4800 Quebec Ave. N., Minneapolis, MN 55428.
If it is intended to use this power pack on DC or AC/DC dual power source studio
flashes produced by other manufacturers, consult your dealer or the manufacturer for
suitability first.
2.
BASIC FEATURES OF THE PACK
2.1. The pack has a built-in rechargeable battery. It can be recharged with an AC/DC
adaptor (included) which provides a DC output of 18V, 600mA.
2.2. The output from the pack is approximately DC 305V, 500mA. An optional DC
power cord (part no. R6000) plugs into the pack on one end and the flashhead on
the other end.
2.3. A brand new and fully-recharged power pack will be able to support
approximately 90 - 115 full power flashes of the Allure BP320 studio flash,
which will have an energy capacity of about 270WS when used with this battery
pack, without the modeling lamp.
Note: The modeling lamp, if there is one, will be disabled automatically when
the studio flash is switched into the DC mode.
ALLURE BP320
DC POWER PACK
OPERATION INSTRUCTIONS
by Norman
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Norman BP320
Summary of Contents for Norman BP320
-
Page 1: Operation Instructions
2.3. A brand new and fully-recharged power pack will be able to support approximately 90 - 115 full power flashes of the Allure BP320 studio flash, which will have an energy capacity of about 270WS when used with this battery pack, without the modeling lamp. - Page 2 2.4. There are the following indicators, switches and sockets on the front panel of the pack – 1. Flash Socket 5. Main ON/OFF Switch 2. Battery Level Indicator Lamps (4X) 6. Charger Socket 3. Input Circuit Pilot Lamp 7. Charger/Flash Selection Switch 4.
- Page 3 (e) When the pack has been fully recharged, the green Input Status Indicator Lamp will blink, instead of remaining steady, to indicate completion of the process. Flip the Main ON/OFF Switch off. Disconnect the unit from the charger. Note: The front panel of the pack may become warm during the charging process.
- Page 4 When the studio flash has been fully re-charged, the Output Status Indicator Lamp will change from a steady light to blinking. Note: The blinking of the indicator lamp actually is the result of the DC Power Pack constantly re-charging the studio flash to keep the energy level at the predetermined level to ensure a correct flash output at all times.
- Page 5 5.2. Condition of Indicator Lamps during Studio Flash Recharge Cycle When the recharge of a studio flash is in progress, the Battery Level Indicator Lamps may flicker or even go off. This is a normal phenomenon and should not cause any alarm. When the re-charge is complete, the light of the indicator lamps will return to a steady condition and the indicator lamps will restore themselves as a correct reference for the approximate level of battery power remaining.
- Page 6 Recharge the unit at least two to three times a month (see (3.3.) above). Recharge as early as possible when battery level is low (see (5.1.) above). SPECIFICATIONS Charge Input Requirement DC18V, 600mA Charger Input Socket Round coaxial type with centre -ve and perimeter Output Voltage/Current Approx.
