Chapter 5. Part List

NO DESCRIPTION
1 GHT-S200/BODY/SATELLITE-FL
2 GHT-S20/BODY/SATELLITE-FR
3 GHT-S20/BODY/SATELLITE-RL
4 GHT-S20/BODY/SATELLITE-RR
5 GHT-S20/BODY/SATELLITE-CEN
6 SPEAKER UNIT A-204 8 OHM/2"
7 RUBBER, Ø21.5/SATE
8 GHT-S200/BODY/WOOFER/230V-EU
9 SPEAKER UNIT 8" 4 OHM 80W
10 PCBA GHT-S200
11 IC TDA7294
12 IC TDA7265
13 IC PT2323
14 IC JRC4558
15 IC PT2258
16 IC EM78P447
17 TRANSFORMER, 230V: 16.5VACx2&3A;
26VAC*2&2A
18 AUDIO CABLE, 6RCA to 6RCA, GHT-S200
19 AUDIO CABLE, 1ST to 2RCA, GHT-S200
20 CARTON, GHT-S200
21 CUSHION, GHT-S200
22 Round Red type Label (NO CARTON)
23 S/N LABEL (NO CARTON&WOOFEWR)
24 MANUAL GHT-S200
25 PE BAG, GHT-S200
26 PE BAG, GHT-S200
27 PE BAG, POWER CORD, GHT-S200
28 PE BAG, AUDIO CABLE
29 CARDBOARD, ENGLISH, GHT-S200
1
1
1
1
1
20
16
1
1
1
1
3
1
4
1
1
1
1
1
2
1
1
2
1
1
1
1
1
1
Version 1.0 Page 15 of 21
Qty UNIT Part No
PC S200-01
PC S200-02
PC S200-03
PC S200-04
PC S200-05
PC S200-06
PC S200-07
PC S200-08
PC S200-09
PC S200-10
PC S200-11
PC S200-12
PC S200-13
PC S200-14
PC S200-15
PC S200-16
PC S200-17
PC S200-18
PC S200-19
PC S200-20
SET S200-21
PC S200-22
PC S200-23
PC S200-24
PC S200-25
PC S200-26
PC S200-27
PC S200-28
PC S200-29
GHT-S200
