Lava QUATTRO-PCI 3.3V Datasheet

I O /
Board
by:
LAVA
Features:
!
Four 9- pin high speed 16550 UART serial port s – adds four CO M port s t o any 3.3 volt
PCI- equipped PC. Maximum dat a t hroughput rat e: 115.2 kbps on each port .
!
Requires only one syst em IRQ – saves valuable resources for ot her expansion cards.
!
Bot h port s share one PCI bus IRQ – even when accessed simult aneously.
!
Aut omat ically select s next available IRQ and CO M addresses – just plug it in and go!
!
Includes Lava Com Port Redirect Ut ilit y for renaming CO M Port s –allows for
backward compat ibilit y wit h soft ware t hat support s CO M 1- 4 only.
!
Compat ible wit h RS - 232 serial peripherals – including modems, PDAs, digit al
cameras, bar- code scanners, and UPS es.
!
Compliant wit h PCI S pecificat ion 3.0
!
Lava Lifet ime Warrant y
LAVA COMPUTER MFG INC.
2 VULCAN STREET, TORONTO, ON CANADA M9W 1L2
QUATTRO-PCI 3.3V
PCI Bus
4-Port
Serial Board
with
16550 UARTs
for 3.3 Volt PCI
Lava: "The Source For Ports"
LAVA
PORT C
QUAD SERIAL PCI 3.3v
TEL:(416) 674-5942
FAX:(416) 674-8262
PORT D
LAVA COMPUTERS
MADE
IN
CANADA
P.N. MOKO L99.0
L I F E T I M E
W A R R A N T Y
www.lavalink.com
Rev. B00
