- Page 1 USER GUIDE RECHARGEABLE BATTERY PACK for STRAT ®...
- Page 2 Welcome Thank you for making Fishman products a part of your musical experience. We are proud to offer you the finest products available: high-quality professional-grade tools which empower you to sound your very best. Related Products Fishman Fluence Multi-Voice Pickups for Electric Guitar The Fishman Rechargeable Battery Pack for Strat is designed for use with Fishman Fluence pickups.
- Page 3 Charging Charging and operation assume installation and wiring as described in the Installation Guide, available http://www.fishman.com/support/ We recommend fully charging the battery pack before using it for the first time. Connect the charge cable to the battery pack and plug into a wall socket using the wincluded adapter. The small LED on the battery pack will change from red to green when the charge is complete.
- Page 4 You can expect up to 250 hours of operation per charge when used with Fishman Fluence pickups. The battery pack is also suitable for use with active pickups and other active circuits that are designed to be used with 9v batteries.
-
Page 5: Troubleshooting
Users should not attempt replacement of the battery themselves. It is possible to send your bat- tery pack back to Fishman in order to have the battery replaced for a small fee. However, if a battery replacement is attempted: Caution - Replace only with same type of battery, Model BA750. - Page 6 Wire Diagram Battery switch Output (white) Ring Jack (Red) Sleeve Bridge & Pot Ground (Black) Tip - Connect to pickup output...
- Page 7 Compliance EU Declaration of Conformity CE: Hereby, Fishman declares that Fishman rechargable battery pack for strat is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC, 2006/95/ED. FCC Notice (for U.S. Customers): This device complies with FCC Part 15: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 8 FISHMAN TRANSDUCERS www.fishman.com 513-100-224_r2...
