- Page 1 USER GUIDE RECHARGEABLE BATTERY PACKS fishman.com...
-
Page 2: Installation Warning
NEGLIGENCE OR ANY OTHER FAULT of Fishman, including but not limited to equipment malfunction from whatever cause, or any other fault of Fishman. Additionally, you agree to indemnify, defend and hold Fishman harmless from any third party claims arising from such activities. This product should be professionally installed. If you are not a profes- sional installation service provider for musical instruments, please refer to the Battery Pack Installation Guide included CAUTION! Excessive pressure may puncture the battery. - Page 3 Charging and operation assume installation and wiring as described in the Installation Guide, available at http://www.fishman.com/support/ We recommend fully charging the battery pack before using it for the first time. Connect the USB charge cable to the battery pack and plug into a wall socket using a 5 volt USB-compliant charger. The LED on the battery pack will change from red to green when the charge is complete.
-
Page 4: Operation
You can expect up to 250 hours of operation per charge when used with Fishman Fluence pickups (depending on model and pickup configuration). The battery pack is also suitable for use with active pickups and other active circuits that are designed to be used with 9-volt batteries. -
Page 5: Troubleshooting
Users should not attempt replacement of the battery themselves. It is possible to send your battery pack back to Fishman in order to have the battery replaced for a small fee. However, if a battery replacement is attempted: Caution - Replace only with same type of battery:... -
Page 6: Installation
Installation This guide provides installation instructions for the Fishman Fluence Universal Battery Pack intended for use with the Fishman Fluence series of pickups. Warning! Installation of this product is meant to be performed only by a professional instrument repair technician. -
Page 7: Wiring Diagram
Wiring Diagram Rechargeable Battery Strat® is a registered trademark of FMIC Pack for Strat ® Les Paul® is a registered trademark of Gibson Guitar Corporation Rechargeable Battery Pack for Les Paul ® Universal Battery Pack Bridge GND Battery switch Ring (white) Output (Red) - Page 8 Rechargeable Battery Pack for Universal Battery Pack with Output Module Wiring Battery (Red) Modern Ceramic MHBC COIL TAPS Rev 0.0 Common / GND Output module Ground...
- Page 9 Universal Battery Pack Install & Wiring Components: Drill 1/2 inch hole in control cavity cover 1. Existing control cover (not included) 2. Li-Ion battery pack 3. Rechargeable Universal Module 4. Power leads How to Install Battery Pack: 1. Remove adhesive backing on Li-Ion battery (2) and Rechargeable Universal Module (3).
- Page 10 Wiring Diagram Battery switch (white) Ring Output Jack +9V (Red) Bridge & Pot Sleeve Ground (Black) Tip - Connect to pickup output...
- Page 11 Compliance EU Declaration of Conformity CE: Hereby, Fishman declares that Fishman rechargeable battery pack products are in compliance with the essential requirements and other relevant provisions of Directive 2014/30/EU, 2014/35/EU. The Declaration of Conformity can be found at www.fishman.com/support FCC Notice (for U.S. Customers):...
- Page 12 Fishman and Fishman Transducers are trademarks or tradenames of Fishman Transducers Inc. 513-300-227_r2 7/16...
