ANS Z83.26-2007/CSA 2.37-2007 Gas-Fired Outdoor Infrared Patio Heater ANS Z83.26a-2008/CSA
2.37a-2008 Gas-Fired Outdoor Infrared Patio Heater
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance
and immediately call your gas supplier or fire
department
WARNING
WARNING indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance. An LP-cylinder not connected for use shall
not be stored in the vicinity of this or any other
appliance.
WARNING:
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or
death. Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this
equipment.
Owners
Manual
OUTDOOR
Fire Feature
MODEL #PC14SS
and #PC14AB
For Outdoor Use Only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the pc14ss and is the answer not in the manual?

Questions and answers

Related Manuals for ambiance pc14ss

Summary of Contents for ambiance pc14ss

  • Page 1 Owners Manual OUTDOOR Fire Feature MODEL #PC14SS and #PC14AB DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire...

  • Page 2: Package Contents

    PACKAGE CONTENTS Reflector Emitter Grid Glass Tube Fixer Top Plate Upper Support (Long) Protective Guard Glass Tube Side Panel Black Silicone Ring Control Box Assembly Lower Support (Short) Tank Securing Belt Gas Hose Assb. Wheel Assb. Bottom Plate Front Panel Ceramic Fiber PART DESCRIPTION...

  • Page 3: Safety Information

    HARDWARE CONTENTS (shown actual size) M6 x 12 mm Wing nut Stud Small Flat M5 x 12 mm Screw Bolt Qty. 3 Qty. 3 Washer Qty. 35 Qty. 8 Qty. 6 Chain Knob M4 x 10 mm Qty.1 Fixing Bracket Qty.

  • Page 4: Service Safety

    SAFETY INFORMATION DANGER DANGER • CARBON MONOXIDE HAZARD • This fire feature is a combustion appliance. All • EXPLOSION - FIRE HAZARD combustion appliances produce carbon monoxide • Keep solid combustibles, such as building (CO) during the combustion process. This product is materials, paper or cardboard, a safe distance away designed to produce extremely minute, non-hazardous from the fire feature as recommended by the...

  • Page 5: Burn Hazard

    SAFETY INFORMATION WARNING WARNING • This product is fueled by propane gas. Propane gas California Proposition 65 is invisible and flammable. An odorant is normally Combustion by-products produced when using added to help detect leaks and can be described as a this product contain chemicals known to the “rotten egg”...
  • Page 6 ASSEMBLY INSTRUCTIONS 1.Insert the hoods of bottom plate (O) to the lower holes of the three lower supports (K) Insert the hoods of control box assembly (J) to the upper holes of the three lower support (K). Note: Make sure to align the side of bottom plate (O) with the holes (to accommodate front plate P) with the side of control box assembly (J) with the magnet.
  • Page 7 ASSEMBLY INSTRUCTIONS 3.Use Phillips screwdriver (LL) to fasten the control box assembly (J) and the bottom plate (O) with M5 x 12 mm screws (DD). Hardware Used M6 x 12 mm Screw Phillips Screwdriver 4.Use Phillips screwdriver (LL) to secure the top plate (D) to the upper supports (E) with M5 x 12 mm screws (DD).
  • Page 8 ASSEMBLY INSTRUCTIONS 5.Using wrench (KK) to assemble the wheel assembly (N) to the bottom plate (O) with M6 x 12 mm bolts (EE). Hardware Used M6 x 12 mm Bolt Wrench 6. Use Phillips screwdriver (LL) to secure the block belt (L) to the lower supports (K) with M5 x 12 mm screws (DD).
  • Page 9 ASSEMBLY INSTRUCTIONS 7. Carefully install the glass tube with rubber ring at the bottom (G) between the center of top plate (D) and control box After the glass tube (G) is installed, be sure to wipe off all fingerprints with a clean, dry cloth.
  • Page 10 ASSEMBLY INSTRUCTIONS 9. Use Phillips screwdriver (LL) to install side panels (H) to bottom of assembly with M5 x 12 mm screws (DD). Note: Do not cover the panel where the magnet is. Hardware Used x 12 M5 x 12 mm Screw Phillips Screwdriver 10.Install the knob (GG) to M4x10 screw (HH).
  • Page 11 ASSEMBLY INSTRUCTIONS 11. Assemble the protective guard and mesh by inserting the hooks of protective guard (F) to the holes of upper supports (E). Put the mesh (B) on the top plate (D). Make sure the screw holes align the holes of top plate (D). Use Phillips screwdriver (LL) to secure the mesh (B) and protective guard (F) to the top...
  • Page 12 NOTE, we have provided three tabs at the base of the fire feature where it can be secured to a patio. If installed in a windy area or where it may be bumped or tipped (fasteners are not included) we strongly recommend Ambiance securing to patio.
  • Page 13 The cylinder must have a connection device compatible with the connection for the appliance. The cylinder used must include a collar to protect the cylinder valve. Never connect an unregulated propane cylinder to the fire feature. Ambiance Use only approved replacement parts. These can be ordered through your dealer or directly from AEI Corporation (949) 474-3070 M-F 7 a.m.
  • Page 14 1. Make 6-8 oz. of leak check solution (one part liquid dish washing detergent and three parts water). 2. Make sure tank valve is OFF and valve to Ambiance Fire Feature is in OFF Position 3. Apply several ounces of solution where hose attaches to regulator.
  • Page 15 NOTE Before Lighting: 1. Ambiance Fire Feature should be thoroughly inspected before each use, and by a qualified service person at least annually. Always wait at least 5 minutes before attempting to relight a hot Ambiance Fire Feature.
  • Page 16 OPERATION INSTRUCTIONS 4. Push and release the igniter button until pilot flame is visible through the glass tube. 5. Once the pilot is lit, continue to depress the control knob for 30 seconds. 6. If the pilot does light or does not stay lit, repeat steps 4 to 6. 7.

  • Page 17: For Your Safety

    Operation Checklist For a safe and pleasurable heating experience, perform this check before each use. Before Operating: Ambiance Fire Feature is affected by wind, Do not use is breeze is greater than 10 Miles Per Hour. 1. User is familiar with entire owner’s manual and understands all precautions noted.

  • Page 18: Care And Maintenance

    5. Air flow must be unobstructed. Keep controls, burner, and circulating air passageways clean. 6. Regularly replace AA Battery behind ignitor button (as needed) 7. Remove and thoughouly clean control box assembly using compressed air annually, if Ambiance Fire Feature pilot fails to light or as needed.

  • Page 19: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Cylinder valve is closed or Cylinder is Empty Open valve. Insure fuel in tank Clean with compressed air or replace orifice or pilot tube Blockage in orifice or pilot tube Pilot won’t light Open gas line and bleed it Air in gas line (pressing control knob in) for no more than 1 - 2 minutes or until...
  • Page 20 Then take the glass tube UP AND THEN OUT from the Ambiance Fire Feature wash and clear. After that; reassemble the glass tube and the rest of parts. Note: In a salt-air environment (such as near an ocean), corrosion occurs more quickly than normal.
  • Page 21 Please provide us with the model number and serial number for best possible service and support. Please be sure to fill-out your Ambiance Warranty card so that we can have the record on file. We will not use this information for any marketing activities.

  • Page 22: Replacement Parts List

    Replacement parts available from servicing dealer or AEI CORPORTION www.aeicorporation.com (949) 474-3070 e-mail: info@aeicorporation.com REPLACEMENT PARTS LIST PO Box 16097 Irvine CA USA 92606 or 2641 DuBridge Ave. Irvine CA 92623-6097 Reflector Emitter Grid Glass Tube Fixer Top Plate Upper Support (Long) Protective Guard Glass Tube Side Panel...
  • Page 23 Fire Feature by AEI Corporation. Name___________________________________ Address__________________________________________ City, ST, ZIP ______________________________ Phone____________________________________________ Date Purchased ____________________ Where Purchased (Dlr. Name and City) ___________________________ Ambiance Model#PC14SS ____ (SS Stainless Steel) Serial Number_______________________ (found inside tank enclosure) #PC14AB ___ (Antique Bronze) Fuel LPG__ NAT GAS __ Ambiance...
