LEDs on iMcV-PIM (-10)
The LED functions are as follows:
PWR
LNK (RJ-45)
ACT (RJ-45)
LNK
ACT
FA Pulse
Glows green when unit has power.
Glows green if link is established on the
twisted pair port (located on RJ-45).
Glows amber when data is being passed on
the twisted pair (located on RJ-45).
Glows green when link is established on the
fiber port.
Glows green if data is being passed on the
fiber port.
Glows green when Pulsing FiberAlert is
enabled
