The setup menu system---DVB PART
2. The Main Menu Pressing <SETUP> will enter the Main Menu, which is shown in Figure (5). From here,
pressing <SETUP> again or <RETURN> will exit the menu. The the main menu is divided into four main
selection items: Channel Guide, System Config, Installation, and Game, which are displayed on
the left side. Selecting an item will open a submenu, with the menu s items displayed on the right side of
the screen. The menus are shown in Figures (5) to (8), and are detailed later in this document.
Channel guide -> TV Channel
Channel guide -> TV Channel
Channel guide
TV Channels
System Config
Radio Channels
Installation
Channels Class
Game
Channels Edit
Book List
Figure (5) Main Menu + Channel Guide
Channel guide -> TV Channel
Channel guide -> TV Channel
Channel guide
Auto Scan
System Config
Manual Scan
Installation
Default Setup
Game
Figure (7) Installation Menu
Upon entering the main menu, the first item, Channel Guide, will already be highlighted. Use the <UP> or
<DOWN> buttons to highlight a different item. Press <ENTER> to enter a new menu corresponding to the
highlighted item. The submenus are their items include:
Channel Guide:
This includes TV Channels, Radio Channels, Channels Class, and Channels Edit. See Figure (5).
System
Config:
This includes TV Setting, Video Setting, Audio Setting, Language, Parent Control, Time Setting, and
System Info. See Figure (6).
Installation:
This includes Auto Scan, Manual Scan, and Default Setup. See Figure (7).
Game:
This includes Boxman and Burning Tetris and Hit Rat. See Figure (8).
Advanced Features
Channel guide -> TV Channel
Channel guide -> TV Channel
Channel guide
TV Setting
System Config
Video Setting
Installation
Audio Setting
Game
Language
Parent Control
Time Setting
System Info
Figure (6) System Config Menu
Channel guide -> TV Channel
Channel guide -> TV Channel
Channel guide
Box Man
System Config
Burning Tetris
Installation
Hit Rat
Game
Figure (8) Game Menu
-33-
The setup menu system---DVB PART
3. Channel Guide
3.1 TV Channels
The TV Channels Menu is shown in Figure (9). The channels are listed on the left side of the menu, and a
preview window is on the right side. From here, the channel can be changed using the <UP> or <DOWN>
keys, <ENTER> to start viewing, <LEFT> or <RIGHT> to change channel groups. Channel groups include
news, sports, favorites, etc. Press <DISPLAY> to sort the channels, which can be set to alphabetical (A-Z),
reverse alphabetical, free on top, scrambled on top, and transponder (Figure (10)).
Channel Guide -> TV Channels
Channel Guide -> TV Channels
No
All TV
0001
Xxx
0002
Xxx
Xxx
0003
Xxx
0004
< >to switch calssify
DISPLAY key to sort channel
Figure (9) TV Channels Menu
3.2 Radio Channels
The Radio Channels Menu, shown in Figure (11), is similar to the TV Channels Menu.
The channels are listed on the left side. The channel can be changed using <UP> and <DOWN>, and group
can be changed using <LEFT> or <RIGHT>. Press <DISPLAY> to sort the channels.
Channel Guide -> Radio Channels
Channel Guide -> Radio Channels
No
0001
Xxx
0002
Xxx
0003
Xxx
0004
Xxx
< >to switch calssify
DISPLAY key to sort channel
Figure (11) Radio Channels Menu
3.3 Channels Class
From the Channels Class Menu, shown in Figure (12), each channel can be classified into
a group. Pressing <ENTER> will add the row s c hannel to the column s category. Use <TV/RADIO> to
switch between TV and radio channels. Note: If there are no channels, the user cannot enter this menu.
Channel Guide->Channel class
Channel Guide->Channel class
NO TV
0001
Xx
0002
Xxx
0003
Xxxx
0004
Xxx
Enter key to check/uncheck
Enter key to check/uncheck
TV/RADIO key to switch TV/RADIO
TV/RADIO key to switch TV/RADIO
Figure (12) Channel Class Menu
Advanced Features
Channel Guide -> TV Channels
Channel Guide -> TV Channels
No
All TV
0001
Xxx
Cancel
Cancel
0002
Xxx
A~Z
A~Z
Xxx
Z~A
Z~A
0003
Free~Scramble
Free~Scramble
Xxx
0004
Scramble~Free
Scramble~Free
Transponder
Transponder
Figure (10) Sort Channels
All TV
Favor
Movie
News
Show
-34-
