This manual covers the following models:
• T755H
Thermostat Applications Guide
D
e
s
c
i r
t p
o i
n
Gas or Oil Heat
Electric Furnace
Heat Pump (No Aux. or Emergency Heat)
Heat Pump (with Aux. or Emergency Heat)
Multi-stage Systems
Heat Only Systems
Cool Only Systems
Millivolt
Any HVAC System up to 3H/2C with
standard low voltage controlled humidifier.
Any HVAC System up to 3H/2C with
standard low voltage controlled de-humidifier.

Table of Contents

Una versión española de este
manual puede ser descargada
en www.pro1iaq.com
® U.S. Registered Trademark. Patents pending.
Copyright © 2010 Pro1 IAQ, Inc. All rights reserved.
INSTALLATION MANUAL
Power Type
Battery Power
Hardwire (Common Wire)
Yes
Yes
Hardwire (Common Wire) with Battery Backup
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Page
A trained, experienced technician
must install this product.
2
3
Carefully read these instructions. You
4
could damage this product or cause a
5
hazardous condition if you fail to follow
6-9
these instructions.
10
11
12-13
14
Need Help?
For assistance with this product please
visit http://www.pro1iaq.com or call Pro1
Customer Care toll-free at 888-Pro1iaq
(776-1427) during normal business hours
(Mon-Fri 9 AM - 6 PM Eastern)
1
Rev. 1021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T755H and is the answer not in the manual?

Questions and answers

Related Manuals for Pro1 IAQ T755H

Summary of Contents for Pro1 IAQ T755H

  • Page 1: Table Of Contents

    (776-1427) during normal business hours Una versión española de este (Mon-Fri 9 AM - 6 PM Eastern) manual puede ser descargada en www.pro1iaq.com ® U.S. Registered Trademark. Patents pending. Copyright © 2010 Pro1 IAQ, Inc. All rights reserved. Rev. 1021...

  • Page 2: Installation Tips

    INSTALLATION TIPS Wall locations The thermostat should be installed approximately 4 to 5 feet above the floor. Select an area with average temperature and good air circulation. Do not install thermostat in locations: • Close to hot or cold air ducts •...

  • Page 3: Thermostat Quick Reference

    Getting to know your thermostat Displays the days of the Displays the user week and time, or the selectable setpoint current ambient temperature. humidity level. HOLD is displayed when thermostat program is permanently overridden. Menu Options: Shows different options Low Battery Indicator: Replace batteries when this indicator is shown.

  • Page 4: Subbase Installation

    SUBBASE INSTALLATION Caution: Mercury Notice: Electrical Hazard All of Pro1’s products are mercury free. However, if the Failure to disconnect the product you are replacing power before beginning to contains mercury, dispose of it install this product can cause properly. Your local waste electrical shock or equipment management authority can give damage.

  • Page 5: Wiring

    WIRING Wiring Warning: If you are replacing a thermostat, make note of the terminal connections on the thermostat that is being replaced. In some cases the wiring All components of the control connections will not be color coded. For system and the thermostat example, the green wire may not be connected to the G terminal.

  • Page 6: Technician Setup Menu

    TECHNICIAN SETUP MENU Technician Setup Menu Configure the installer options as This thermostat has a technician setup menu desired using the table below. for easy installer configuration. To set up the thermostat for your particular application: Use the keys to Press MENU button change settings and the NEXT STEP or PREV STEP key to move from one...
  • Page 7 TECHNICIAN SETUP MENU Tech Setup Steps (Continued from the previous page) Program Morning ºF or ºC 12 or 24 Options Recovery Hour Clock Operation This feature turns your Select F for Fahrenheit You can select either a Select GAS for You can configure this system on before the temperature read out...
  • Page 8 TECHNICIAN SETUP MENU Tech Setup Steps (Continued from the previous page) Heat Pump System Gas Auxiliary Stages Cooling Fan Switch for Heat Pump of Heat Delay When turned on the You can configure the This option will turn You can configure the The cooling fan delay system switch for the the heat pump off 45...

  • Page 9: Hum Terminal

    TECHNICIAN SETUP MENU Tech Setup Steps (Continued from the previous page) Humidify Dehumidify Humidity Dehumidify Over Cool Calibration with AC Limit Terminal Terminal This feature adds This feature This feature forces The amount of over Options for how the Option for how the This feature allows humidity when removes humidity...

  • Page 10: Setting The Humidity

    SETTING THE HUMIDITY Setting Target Humidity Setpoint HUMIDITY KEY Follow the steps below to change your target humidity setpoint. Press the HUMIDITY key Use the key to select the target humidity setpoint. Press DONE when completed Note: The target humidity setpoint is not programmable. Unlike temperature, humidity does not change quickly and should TARGET HUMIDITY not be programmed.

  • Page 11: Mounting And Battery Installation

    MOUNT THERMOSTAT & BATTERY INSTALLATION Mount Thermostat Align the 4 tabs on the subbase with corresponding slots on the back of the thermostat, then push gently until the thermostat snaps in place. To insure a solid fit between Note: the thermostat and the subbase: mount subbase to flat wall use screws &...

  • Page 12: Programming The Thermostat

    PROGRAMMING THE THERMOSTAT Set Time Follow the steps below to set the day of the week and current time: Press MENU Press SET TIME Day of the week will be flashing. Use the key to select the current day of the week. Press NEXT STEP The current hour is flashing.
  • Page 13 PROGRAMMING THE THERMOSTAT You can use the table below to plan your customized program schedule if using 5+1+1. Programming Table Setpoint Setpoint Day of the Events Time Temperature (Cool) Temperature (Heat) Week Weekday Wake Leave Return Sleep Saturday Wake Leave Return Sleep Sunday...

  • Page 14: Specifications

    32ºF to +105ºF (0º to +41ºC) Operating humidity 90% non-condensing maximum Dimensions of thermostat 4.7”W x 4.4”H x 1.1”D Pro1 IAQ Inc. 1111 S. Glenstone Suite 2-100 Spring eld, MO 65804 Toll-free: 1-888-Pro1iaq (776-1427) Toll Number (Outside the USA): 330-821-3600 Web: http://www.pro1iaq.com...
