Echo PPF-2100 Service Data

17-21C-00

SERVICE DATA

POWER PRUNER
PPF-2100 PPT-2100
PPT-2400 PPFD-2400
INTRODUCTION
We are constantly working on technical
improvement of our products. For this reason,
technical data, equipment and design are subject to
change without notice. All specifications,
illustrations and directions in this SERVICE DATA
are based on the latest products information
available at the time of publication.
For further information to service these models,
please refer to ECHO SERVICE MANUAL Ord.No.
402-18.
INDEX
PPF-2100 PPT-2100 PPT-2400 PPFD-2400
with new gear case
CONTENTS
1 SERVICE INFORMATION .............................. 2
1-1 Specifications ............................................ 2,3
1-2 Technical data ............................................ 4
1-3 Torque limits ............................................... 5
1-4 Special repairing materials ......................... 5
1-5 Service limits .............................................. 6
1-6 Special tools ............................................... 7
2 SERVICE PROCEDURE ................................ 8
2-1 Gear case construction .............................. 8
2-2 Checking oil line ......................................... 9
2-3 Checking oil filter and check valve .............. 9
2-4 Replacing oil line and grommet .................. 9
2-5 Removing worm gear ................................. 10
2-6 Inserting worm gear ................................... 10
2-7 Replacing bar stud ..................................... 10
2-8 Replacing drive gear and bearing .............. 11
2-9 Replacing sprocket shaft gear ..................... 11
2-10Assembling gear case ................................. 12
Reference No.
I S S U E D :
1
1
page
17-21C-00
2 0 0 0 0 7
