Empire MANTIS BF28 Series Installation Instructions And Owner's Manual

Power-vent high-efficiency fireplace with bay window models bf28(b,c,g)m(n,p)-3 bi28(b,c,g)m(n,p)-3 bp28(b,c,g)m(n,p)-3/flat front models ff28bm(n,p)-1 fi28bm(n,p)-1 fw28bm(n,p)-1
Hide thumbs Also See for MANTIS BF28 Series:
Table of Contents

Advertisement

EMPIRE
EMPIRE
Comfort Systems
WARNING
WARNING: If not installed, operated and maintained in
accordance with the manufacturer's instructions, this
product could expose you to substances in fuel or from fuel
combustion which can cause death or serious illness.
Attention: Check local codes for venting requirements.
Attention: This appliance may be installed in the U.S. and
Canada.
Installer:
Leave this manual with the appliance.
Consumer:
Retain this manual for future reference.
WARNING: If the information in these instructions
are not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appli-
ance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any
phone in your building.
Immediately call your gas supplier from a neigh-
bor's phone. Follow the gas supplier's instruc-
tions.
If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLATION INSTRUCTIONS
HOT GLASS
WILL
CAUSE BURNS.
DO NOT TOUCH
GLASS
UNTIL COOLED.
NEVER
ALLOW CHILDREN
TO TOUCH GLASS.
AND
OWNER'S MANUAL
POWER-VENT
HIGH-EFFICIENCY
FIREPLACE WITH
BAY WINDOW MODELS
BF28(B,C,G)M(N,P)-3
BI28(B,C,G)M(N,P)-3
BP28(B,C,G)M(N,P)-3
FLAT FRONT MODELS
FF28BM(N,P)-1
FI28BM(N,P)-1
FW28BM(N,P)-1
Young children should be carefully supervised when they
are in the same room as the appliance. Toddlers, young
children and others may be susceptible to accidental con-
tact burns. A physical barrier is recommended if there are
at risk individuals in the house. To restrict access to a fire-
place or stove, install an adjustable safety gate to keep tod-
dlers, young children and other at risk individuals out of
the room and away from hot surfaces.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only) or
mobile home, where not prohibited by state or local codes.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
Page 1
