Summary of Contents for S2Konnect N-3010AVB
-
Page 2: User Manual
S2Konnect N-3010AVB 10/100/1000Base-T Adapter PCI Express User Manual S2Konnect N-3010AVB... - Page 3 Copyright © S2Konnect GmbH, 2010. All rights reserved. This manual refers to the S2Konnect N-3010AVB 10/100/1000Base-T Adapter with AVB , PCI Express x1, 1 x RJ-45. Contents are subject to change without notice. Product and brand names are (registered) trademarks of their appropriate owners.
-
Page 4: Conventions
Used to indicate a potentially hazardous situation which, if not avoided, could result in death or serious injury. Example: dangerous voltage. Used to indicate a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. Example: electrostatic discharge. Used for additional information and advice. S2Konnect N-3010AVB... -
Page 5: Table Of Contents
Virtual LAN (VLAN) Support 7 Troubleshooting 8 Important Information Technical Support Returning an Adapter for Repair Additional Documentation and Updates Technical Specifications Appendix A. License and Warranty Information The Americas, Asia, Australia, New Zealand, Pacific Europe Deutschland, Schweiz, Österreich, Lichtenstein S2Konnect N-3010AVB... - Page 6 Table of Figures Figure 1: Insertion of the adapter into the computer Figure 2: Connection of the RJ-45 cable/plug Figure 3: Location of the LEDs Figure 4: Typical display after a successful test (external repeater) S2Konnect N-3010AVB...
-
Page 7: Safety Precautions
Avoiding damage Electrostatic discharge! Electrostatic discharge may damage or destroy the Network adapter. To avoid damaging the S2Konnect N-3010AVB Network adapter observe the following: • Switch off the computer. • Disconnect the power cord from the power outlet. -
Page 8: Introduction
Thank you for purchasing a S2Konnect product. This document describes the installation of the network adapter card. The N-3010AVB is a PCI Express adapter which must be installed in a PCI Express slot of the com- puter. The adapter contains a Network chipset “Marvell 88E8059“... - Page 9 Figure 1. Insertion of the adapter into the computer S2Konnect N-3010AVB...
-
Page 10: Connection Of The Network Adapter
Connection of the Network Adapter This chapter describes the physical connection of the S2Konnect N-3010AVB Network Adapter to a network. Transmission Distances The maximum transmission distance for the S2Konnect N-3010AVB 10/100/1000Base-T adapter, is 100m, you have to use a Category 5 unshielded twisted pair cable or better. -
Page 11: Hardware Features
SK-9E21D Adapter family. It is compliant to the PCI Express 1.0a standard and supports a PCI Express single lane (x1). For information about other S2Konnect network products, refer to the product overview on our web site: http://www.s2konnect.com. -
Page 12: Led Displays
ACT/LINK LINK 10=OFF 100=GRN 1000=YLW 10=OFF 100=GRN 1000=YLW Figure 3. Location of the LEDs The LEDs of the S2Konnect N-3010AVB 10/100/1000Base-T Adapter, PCI Express have the following meaning: Marking on Color Status Description bracket green Blinking Link up and Receiving/Transmitting... -
Page 13: Software Features
6 Software Features Operating System Support The drivers for the S2Konnect N-3010AVB 10/100/1000Base-T Adapters, PCI Express sup port the following operating systems: • Windows NT 4.0, Windows 98 Second Edition, Windows Millennium Edition, Windows 7 Windows 2000, Windows XP, Windows Server 2003, Server 2008 and Windows Vista on 32- bit sys tems •... -
Page 14: Promiscuous Mode / Multicast Support
Boot Agent ROM The Boot Agent ROM for S2Konnect N-3010AVB 10/100/1000Base-T adapter, comprises the boot protocols PXE and RPL, allowing the user to choose between both proto cols during every boot. ln addition, it includes a setup program where the user can define sev eral default boot options. -
Page 15: Advanced Power Management / Wake On Lan
Management Reference Specification V2.0. The power management features are implemented according to the Advanced Configuration and Power Interface (ACPI) Specification V2.0. The S2Konnect N-3010AVB Adapters utilize an auxiliary power supply to keep some parts run- ning. This setting enables the network device to “Wake on LAN“. -
Page 16: Redundant Switch Failover
Configuration and Power Interface Specification Revision V2.0. Hot-Plug enables the re- placement of failed devices in a running system. The following conditions have to be met in order for Hot-Plug to work on S2Konnect Gigabit Ether- net Adapters: •... -
Page 17: Parity
7. The “Marvell Network Control“ is part of the “Marvell Network Driver Installation Pac- kage“ available for Windows 2000 XP/Server 2003/2008. With the “Marvell Network Control“, all S2Konnect adapters can be controlled and configured. This tool displays the current configuration and status of the S2Konnect N-3010AVB Adapters. -
Page 18: Virtual Lan (Vlan) Support
By means of Frame Tagging, the S2Konnect N-3010AVB 10/100/1000Base-T Adapters, can sup- port up to 64 IP address assignments in a single network connection. Thus, multiple VLANs can be configured for one port. -
Page 19: Troubleshooting
Is the maximum transmission distance exceeded (see page 10)? If you have any other S2Konnect adapter installed, compare your setup with this adapter. If the problem persists, you can analyze the status of the network adapter with the aid of the LEDs and the diagnostics programs. -
Page 20: Important Information
Additional Documentation and Updates S2Konnect maintains a site on the World Wide Web where you can find the latest information on our product range and our customer support services. The latest drivers are provided on the Marvell web site. -
Page 21: Technical Specifications
N-3010AVB - 10/100/1000Base-T Adapter with AVB, PCI Express x1, 1 x RJ-45 Product Highlights Audio Video Bridging support (AVB) Supports up to 64 VLANs WoL support and Smart Power Down TCP Segmentation (IPv4 and IPv6) Features AVB support according to IEEE 802.1QAV Supports both AVB and non AVB queues Suports priority between non AVB high and low traffi... - Page 22 N-3010AVB - 10/100/1000Base-T Adapter with AVB, PCI Express x1, 1 x RJ-45 Standard Compliance IEEE 802.3u (Ethernet and Fast Ethernet) IEEE 802.3ab and IEEE 802.3z (Gigabit Ethernet) IEEE 802.3ad (Link Aggregation) IEEE 802.3x (Flow control and Auto-negotiation) IEEE 802.1p (Quality of Service) IEEE 802.1q and IEEE 802.3ac (VLAN and VLAN tagging)
- Page 23 N-3010AVB - 10/100/1000Base-T Adapter with AVB, PCI Express x1, 1 x RJ-45 Environment Specifi cations Storage: -20°C to +70°C, 30% to 80% rel. humidity (non-condensing) Operating: -0°C to +50°C, 10% to 95% rel. humidity (non-condensing) ROHs Compliant with EN 2002/95/EU Power Consumption @ +3.3V / VCC max.
-
Page 24: Appendix A. License And Warranty Information
S2Konnect’s entire liability and your exclusive remedy shall be, at S2Konnect’s option, either return of the price paid, or repair or replacement of the SOFTWARE or HARD- WARE that does not meet S2Konnect’s Limited Warranty and which is returned to S2Konnect GmbH with a copy of your receipt. This Limited Warranty is void if failure of the SOFTWARE or HARDWARE has resulted from accident, abuse, or misapplication. -
Page 25: Europe
S2Konnect’s entire liability and your exclusive remedy shall be, at S2Konnect’s option, either return of the price paid, or repair or replacement of the SOFTWARE or HARD- WARE that does not meet S2Konnect’s Limited Warranty and which is returned to S2Konnect with a copy of your receipt. This Limited Warranty is void if failure of the SOFTWARE or HARDWARE has resulted from accident, abuse, or misapplication. -
Page 26: Deutschland, Schweiz, Österreich, Lichtenstein
Weitere Beschränkungen Sie dürfen die Software oder Hardware weder vermieten noch verleihen, aber Sie dürfen die Rechte aus diesem S2Konnect Lizenzund Kaufvertrag auf Dauer auf einen an- deren übertragen, vorausgesetzt, dass Sie alle Kopien der Software und das gesamte schriftliche Begleitmaterial übertragen und der Empfänger sich mit den Bestimmungen dieses Vertrages einverstanden erklärt.
