- Page 1 Installation and Operation Manual DVD-9101-201-x Serial Digital Video Disc Player Document # 540339 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
- Page 2 26-27 INFORMATION NOTICE: Despite any other copyright notice, this document and information disclosed herein contains confidential, proprietary designs owned by Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc.
-
Page 3: Table Of Contents
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Table of Contents Section Description Page General Information....... . -
Page 4: General Information
Audio International’s DVD-9101-201-x is a small form-factor DVD player compatible in size to current Audio International Single-Disc CD players. The DVD-9101-201-x contains three (3) SDI video outputs and three (3) AES-3 audio output channels. Audio, video, and control commands are handled via AI’s RS-485 data bus. -
Page 5: Operational Features
Menu and Set-Up. While the DVD-9101-201-x is a complete and fully functional standalone DVD Player, it is strongly recommended that a remote control device also be employed for thorough enjoyment of the unit. -
Page 6: Application
Media and Format Compatibilities DVD-9101-201-x is compatible with standard commercial audio CD and video DVD. Note that since DVD disc format standards are constantly evolving, some DVD discs may not play properly or may cause the unit to malfunction. -
Page 7: Typical System Block Diagram
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Typical System Block Diagram 2.4.1 This system is fully compatible with Audio International’s RS-485 digital data bus system. It can be configured for IR remote control utilizing AI’s remote control unit AI-RC5-17xxxx and IFR-485. -
Page 8: Installation
• Length of cable runs • Location of other aircraft systems (oxygen delivery) 3.1.2 The DVD-9101-201-x shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 9: Cautions & Warnings
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Cautions & Warnings 3.3.1 It is important to do a pin-to-pin power and ground check on all connectors. Ensure that power and ground are applied only where specified. Damage to the unit may result if power or ground is applied to the wrong points. -
Page 10: Wiring Requirements
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Wiring Requirements 3.4.1 Introduction The installing agency shall supply and fabricate all external cables. The length and routing of external cables shall be carefully studied and planned before attempting installation of the equipment. Allow adequate space for installation of cable and connectors. -
Page 11: Physical Characteristics
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual 3.4.6 RS-485 Data Bus Wiring The DVD-9101-201-x is designed to interface with other Audio International equipment via AI’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair cable in accordance with NEMA WC 27500. -
Page 12: Electrical Characteristics
Three outputs IR Signal 5V active low 3.7.2 The DVD-9101-201-x utilizes one (1) 25-pin connector for electrical connections, which provides power, data bus control, infrared input, and four (4) address strapping pins and a strapping common for unit identification on the RS-485 data bus and for IR control. -
Page 13: Pinout Assignments And Descriptions
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Pinout Assignment and Descriptions DVD-9101-201-x Pin # Description +28 VDC Power Input Circuit Ground No Connect RS-485 Serial Data Bus A (HI) RS-485 Serial Data Bus B (LO) RS-485 Serial Data Bus SHIELD... -
Page 14: Post Installation Test
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual 3.10 Post Installation Test This section is designed to assist the user in determining whether the DVD Player has been properly installed. First, before applying power, ensure the unit is connected correctly, especially concerning Power and Ground wiring. - Page 15 If sound cannot be immediately heard through speakers or headphones, it may be that the volume is too low and should be increased appropriately. Note that there are no audio controls on the DVD-9101-201-x. desired adjustments must be performed through other audio distribution devices.
-
Page 16: Operation
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Operation Front Panel Controls From left to right, the buttons are: PLAY PAUSE STOP REVERSE SKIP (top) FORWARD SKIP (bottom) EJECT The next several pages detail the functions of these buttons. Document # 540339, Rev IR, 11/2006... -
Page 17: Front Panel Control Functions
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Typical Control Functions: EJECT BUTTON The Eject Button allows the user to eject the DVD. Pressing the Eject Button will allow the user to gently pull the DVD out of the mechanism. - Page 18 Audio International, Inc. DVD-9101-201-x Installation & Operation Manual REVERSE SKIP BUTTON During movie or audio play, press to skip to the beginning of the previous chapter or CD track. Press and hold for approximately one (1) second to enter fast reverse (x8) mode.
- Page 19 Audio International, Inc. DVD-9101-201-x Installation & Operation Manual FORWARD SKIP BUTTON DVD Video – Forward: During movie or audio play, press to skip to the beginning of the next chapter or CD track. Press and hold for approximately one (1) Also used to navigate (as Right curser) in second to enter fast forward (x8) mode.
- Page 20 Audio International, Inc. DVD-9101-201-x Installation & Operation Manual PAUSE BUTTON DVD Video – Pause: Press the Pause Button once to place the DVD Player in PAUSE Mode. Several functions become available when the DVD Player is in PAUSE mode: The User can enter Slow Reverse Mode by pressing the Reverse Button.
-
Page 21: Other Supported Rs-485 And Ir Commands
Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Supported RS-485 and IR Commands EJECT This Button functions exactly as the front panel EJECT button: The Eject Button allows the user to eject the DVD. Pressing the Eject Button will allow the user to gently pull the DVD out of the mechanism. - Page 22 Audio International, Inc. DVD-9101-201-x Installation & Operation Manual PREFERENCES TV Display: The User can choose to display the video they are watching in one of the following aspect ratios: Wide (16:9) – Displays video using a 16:9 aspect ratio recommended for widescreen TVs.
- Page 23 Audio International, Inc. DVD-9101-201-x Installation & Operation Manual AUDIO LANGUAGE SELECT This option allows the User to change the preferred audio language if available on the DVD. SEARCH PREV (REW) During movie or audio play, press to “scan” backward through media. Material will scan while the button is held, and, depending on media, video input will be available.
- Page 24 Repeat Chapter: The DVD-9101-201-x will repeat the current chapter until the User exits Repeat Chapter Mode. Repeat Title: The DVD-9101-201-x will repeat the current title until the User exits Repeat Title Mode. Repeat Disc: The DVD-9101-201-x will repeat the disc until the User exits Repeat Disc Mode.
-
Page 25: Instructions For Continued Airworthiness
DVD-9101-201-x Recommended Cleaning Method DVD-9101-201-x should be cleaned routinely at least once every three months to ensure proper functionality. Use a standard DVD cleaning disc (not included with the DVD-9101-201-x) and follow the listed directions. -
Page 26: Troubleshooting Chart
Airworthiness Limitations No periodic scheduled maintenance or calibration is required for continued airworthiness of the DVD-9101-201-x. If the unit fails to perform to specifications, it must be removed and serviced by a qualified service facility Document # 540339, Rev IR, 11/2006... -
Page 27: Specifications
9.95" x 6.10" x 2.09" (l x w x h) 25.3 cm x 15.5 cm x 5.3 cm * Dimensions provided are for the base unit, DVD-9101-201-x. They do not include cover bezel information. Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the DVD-9101-201-x. - Page 28 Audio International, Inc. DVD-9101-201-x Installation & Operation Manual Document # 540339, Rev IR, 11/2006 Page 27 of 27...
