- Page 1 Installation & Operation Manual DVD-021-0x-x Digital Video Disc Player Document # 540125 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
-
Page 2: Table Of Contents
Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. Document # 540125, Rev B, 12/2000... -
Page 3: Front Panel
Audio International, Inc. DVD-021-0x-x Installation & Operation Manual Table of Contents Section Description Page General Information……………………………………………… Introduction…………………………………………………………. Purpose of the Equipment………………………………………… Operational Features……………………………………………… Optional Equipment……………………………………………….. Technical Specifications………………………………………….. Application………………………………………………………….. Video/Audio Disc and Unit Care ………………………………… INSTALLATION…………………………………………………… Prior to Installation…………………………………………………. Unpacking and Inspection…………………………………………... - Page 4 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual DVD-021-0x-x Digital Video Disc Player Document # 540125, Rev B, 12/2000 Page 3 of 31...
-
Page 5: General Information
133 minutes of full-motion video per side on a 5" DVD compact disc. Also, the DVD unit plays standard 5" audio CD’s. The DVD-021-0x-x can be mounted in a cabinet or bulkhead. A unique strapping feature allows up to four (4) similar devices to be used in the same system at the same time while maintaining independent control. -
Page 6: Typical Application
DVD-021-0x-x Installation & Operation Manual Optional Equipment The DVD-021-0x-x can be optionally controlled by infrared remote or AI’s touch screen panel. Digital codes allow the unit to interface with an infrared handheld remote via an infrared receiver, IFR-9A or IFR-485. -
Page 7: Video/Audio Disc And Unit Care
(i.e. entertainment control panels). The panels are on AI’s proprietary RS-485 digital data bus system and configured to control the operational features of the DVD-021-0x-x. Video/Audio Disc and Unit Care When playing a disc for the first time, check that there are no burrs stuck in the center hole of the disc. -
Page 8: Installation
Mounting screws are required to secure the unit. Long low-level audio runs may introduce noise into the audio signal. Refer to Section 6.0 for mounting hole diameters and configurations. The DVD-021-0x-x shall not be mounted on its side, at an angle or in an inclined position. Unpacking and Inspection Carefully open the packaging and remove the DVD-021-0x-x. -
Page 9: Cautions & Warnings
International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from AI. Refer to the front cover of this manual for address and telephone number of Audio International, Inc. Repackage the unit in its original packaging materials and return it to AI following instructions given by the AI representative. -
Page 10: Wiring Requirements
Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 3.11 DO NOT expose to sun or bright light. Damage to the sensor will result. 3.12 ESD (Electro Static Discharge) guidelines shall be followed. Wiring Requirements Introduction The installing agency shall supply and fabricate all external cables. The length and routing of external cables should be carefully studied and planned before attempting installation of the equipment. -
Page 11: Electrical Specifications
DVD-021-0x-x Installation & Operation Manual AI’s Proprietary RS-485 Data Bus 4.4.1 The DVD-021-0x-x is designed to interface with other Audio International equipment via AI’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair cable in accordance with the standard military specification of MIL-DTL-27500 or equivalent. -
Page 12: Mating Connector Information
IFR-9A or IFR-485 module being utilized. If this is not possible, then the infrared ground reference connection for the DVD-021-0x-x should be made within 12" of the unit. Mating Connector Information... -
Page 13: Pinout Assignment And Descriptions
Verify all connections before supplying power to the unit. Load the DVD with DVD disc. Use the DVD-021-0x-x front panel controls or the handheld remote control unit to select PLAY. Verify that a picture can be viewed on the appropriate monitor and that the audio can be heard through the speaker/headphone system. -
Page 14: Troubleshooting Chart
Audio International, Inc. DVD-021-0x-x Installation & Operation Manual Troubleshooting Chart Problem Possible Cause Solution ½ Unit is improperly • No sound / No picture Verify +28 VDC power and video installed input is present ½ No disc in source •... -
Page 15: Reference Drawings
Audio International, Inc. DVD-021-0x-x Installation & Operation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the DVD-021-0x-x. Document # 540125, Rev B, 12/2000 Page 14 of 31... - Page 16 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual Document # 540125, Rev B, 12/2000 Page 15 of 31...
-
Page 17: Operation
SECTION III – OPERATION General Information The DVD-021-0x-x can be operated via front panel ‘buttons’ or optionally controlled by infrared remote or AI’s touch screen panel. Digital codes allow the unit to interface with an infrared handheld remote via an infrared receiver, IFR-9A or IFR-485. -
Page 18: Front Panel Controls
DVD-021-0x-x Installation & Operation Manual Front Panel Controls The names and functions of the DVD-021-0x-x are as follows: Open / Close button – Press to eject a disc from the disc tray or to load a disc onto the disc tray. -
Page 19: Infrared Remote Control
Audio International, Inc. DVD-021-0x-x Installation & Operation Manual Infrared Remote Control ILLUSTRATION OF TYPICAL DVD-021-0x-x REMOTE CONTROL Remote Control User Special Instructions 4.1.1 In case batteries begin to lose power, all indicators will flash when any button is pressed. 4.1.2 To replace batteries, remove the battery compartment cover on the back of the unit. - Page 20 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual Remote Operation 4.2.1 Basic Playback - Playing Back a Disc 4.2.1.1 To start playback from a menu screen, press one of the UP, DOWN, LEFT or RIGHT arrow buttons ( on the Menu Selection keypad or the number buttons or the numerical keypad to select the desired title.
- Page 21 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.2.1.8 To play back a DVD in slow motion, during playback, press the SLOW button. The playback speed will reduce to half of the normal speed. Each time the SLOW button is pressed, the slow-motion speed changes: 1/2 normal speed, 1/8 normal speed, 1/16 normal speed.
- Page 22 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.2.2.3 To locate a specific chapter or track number, press T. Press the down arrow ( ) to highlight the space next to chapter. Press the corresponding number on the numerical keypad to select the chapter or track desired.
- Page 23 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.2.3.3 To repeat a specific segment repeatedly, press A-B RPT at the beginning of the segment (point A) you want to play repeatedly. Press A-B RPT again at the end of the segment (point B).
- Page 24 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.2.4.4 Press while the MEMORY menu appears on the monitor screen and the DVD will start memory playback. 4.2.4.5 To change the programmed items, while the MEMORY menu appears on the monitor screen, press move the highlighted bar to the item to be changed.
- Page 25 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.2.6.2 The camera angle can be changed during still playback. The camera angle changes to the new setting when normal playback is resumed. While playing back a title that contains at least one scene recorded from multiple angles, the angle icon indicator illuminates in the DVD display.
- Page 26 PCM recording systems and cannot play back DVD discs recorded in any other recording system. AC-3 5.1 channel is displayed as “AC-3 6CH”. The total channels available in AC-3 may vary from 1 to 6. (NOTE: The DVD-021-0x-x unit only provides for stereo audio outputs. True AC-3 output is not possible with this unit.)
- Page 27 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.2.8.2 To select a Subtitle Language, press SUBTITLE SELECT during playback. The abbreviation of the language appears instead of the language name. Refer to the appendix for languages and their abbreviations. Press...
- Page 28 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual Function Setup-Customizing the Function Settings 4.3.1 Displaying the SET UP MENU screen: 4.3.1.1 The default settings can be changed to customize the performance to your preference. 4.3.1.2 The SET UP MENU screen will ask you to select a setting...
- Page 29 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.3.2.3 When AUDIO OUT SEL. is selected, select the output sound type AC-3 or PCM by pressing and then pressing ENTER. Select the output sound type according to the system connection. 4.3.2.4 When D RANGE CONTROL is selected, select ‘ON’ or ‘OFF’...
- Page 30 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.3.3.6 Press SET UP and the setting screen will disappear. If the RETURN button is pressed while a menu appears on the screen, the screen will return to the previous menu screen displayed.
- Page 31 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual 4.3.4.6 When DISC MENU is selected, select a preferred language by pressing one of the arrow buttons ( ) and then press ENTER. To change the language while a disc is inserted, press the TITLE or MENU button to display the disc menu.
- Page 32 Audio International, Inc. DVD-021-0x-x Installation & Operation Manual ½ Press to select the parental lock level and press ENTER. DVD discs are rated higher than the level selected cannot be played unless the parental lock function has been cancelled. The parental lock level is equivalent to the following...
