SERVICE MANUAL
Ver. 1.0 2006.10
• US and Canadian models include the
connection box (XA-123).
US and foreign patents licensed from Dolby
Laboratories.
Copyrights
This product incorporates copyright
protection technology that is protected by
method claims of certain U.S. patents, other
intellectual property rights owned by
Macrovision Corporation, and other rights
owners. Use of this copyright protection
technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only
unless otherwise authorized by Macrovision
Corporation. Reverse engineering or
disassembly is prohibited.
Manufactured under license from Dolby
Laboratories.
"Dolby", "Pro Logic", and the double-D
symbol are trademarks of Dolby
Laboratories.
"DTS" and "DTS 2.0 + Digital Out" are
trademarks of Digital Theater Systems, Inc.
Sony Corporation
9-887-461-01
eVehicle Division
2006J05-1
Published by Sony Techno Create Corporation
© 2006.10
DVD
Section
OPEN/CLOSE
Section
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
22 watts per channel minimum continuous average power into 4 ohms, 4 channels driven
from 20 Hz to 20 kHz with no more than 5 % total harmonic distortion.
CEA2006 Standard
Power Output: 17 Watts RMS × 4 at
4 Ohms < 1% THD+N
SN Ratio: 82 dBA
(reference: 1 Watt into 4 Ohms)
System
Laser
Semiconductor laser
Signal format system
NTSC (US, CND)
PAL (AEP, RU, E, AUS, CH)
Monitor section
Display type Wide LCD color monitor
Size
7 in.
System
TFT active matrix
Number of pixel
336,960 pixels
DVD/CD Player section
Signal-to-noise ratio
100 dB
Frequency response
10 − 20,000 Hz
Wow and flutter
Below measurable limit
Harmonic distortion (DVD)
0.01%
XAV-C1
Canadian Model
Australian Model
Chinese Model
Model Name Using Similar Mechanism
DVD Mechanism Type
Optical Pick-up Name
Model Name Using Similar Mechanism
Open/Close Mechanism Type
SPECIFICATIONS
Tuner section
FM
Tuning range
87.5 - 108MHz (AEP, RU, E, AUS, CH)
87.5 - 107.9 MHz (US, CND)
Intermediate frequency
10.7 MHz/550 kHz
Usable sensitivity
9 dBf
Frequency response
30 - 15,000 Hz
Selectivity
75 dB (400 kHz)
S/N ratio
64 dB (stereo)
69 dB (mono)
Harmonic distortion at 1 kHz
0.5% (stereo)
0.4% (mono)
Separation
35 dB at 1 kHz
– Continued on next page –
US Model
AEP Model
E Model
NEW
MDAU51
HPD-60
NEW
DB-M03
AV CENTER
