- Page 1 InstallatIon and operatIon manual Solibro Solar Modules SL2 and SL2-F from the Generation 1.4...
-
Page 2: Table Of Contents
The data sheets and customer information current at the point in time at which the relevant module was manufactured apply for the carrying out of installation, mounting or maintenance work on the solar modules. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE GEnERatIon G1.4... -
Page 3: Introduction
Approved clamps list installation and assembly manual. ƒ Packaging and transport of ciGS modules A pplicable documents (country-specific regulations on pres- ƒ sure equipment, operational safety, hazardous material and environmental protection). ƒ Plant-specific regulations and requirements. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... -
Page 4: Planning
61646 (Ed. 2); iEc 61730 (Ed. 1) class A; McS, uL 1703 (cSA), Golden Sun (cGc) Application class A; McS, uL 1703 (cSA) Fig. 1: External dimensions (in mm) and components for SL2 and SL2-F sl2-F 789.5 796.1 –1... -
Page 5: Requirements
Ensure that the substructure is de-energized / is on ground po- tential (R ≤ 10 Ohm). For further notes, see chapter 3 ¼ InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... - Page 6 Active surface 12-16 16,5 > 1 All measurements in mm. „ clamp (schematic) Glass (module bottom side) ‚ Rubber Active surface ƒ Glass (module top side) InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE GEnERatIon G1.4...
-
Page 7: Mounting Variants
The listed mounting variants are valid for point module mounting and linear module mounting. For the usage of an expanded clam- ping area a special release is required. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... -
Page 8: Electrical Layout
A safety factor of +2.5 % must always positive. therefore be taken into account in the system layout for v and v note! Further information is available in Chapter 5.1 Specifications for functional grounding. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE GEnERatIon G1.4... -
Page 9: Installation
Follow the packaging instructions. Leave the modules in the original packaging ƒ right up until installation. Store the modules securely in dry rooms. The ƒ packaging is not weatherproof! InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... - Page 10 Do not drop the modules. ¼ never stand on the modules. ¼ Do not apply mechanical stress to the modules. ¼ Do not drop objects on the modules. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE GEnERatIon G1.4...
-
Page 11: Preparation For Installation
Solibro in writing. Confirmation letter only install modules and components which ¼ are free from damage. ¼ Do not add any holes. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... -
Page 12: Module Installation
Please note the requirements on the clamping system outli- ¼ ned in chapter 2. ¼ Tighten the clamps with a torque of 18 nm. ¼ Keep a minimum distance of 10 mm between 2 modules. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE GEnERatIon G1.4... -
Page 13: Electrical Connection
¼ Do not touch both poles at the same time. danger! danger due to electric shock! ƒ insulate exposed cable ends. ¼ ¼ only connect cables with plugs. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... -
Page 14: Safety During Electrical Installation Work
SWITCH danger! danger due to electric shock! cover modules that need to be separated. ƒ A lways comply with the specified time inter- ¼ vals from switching off the inverter to starting further work. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE GEnERatIon G1.4... -
Page 15: Module Connection
SOLAR danger! danger due to electric shock! ƒ ¼ Ensure that all electrical components are in a correct, dry and safe state. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... -
Page 16: After The Installation
Avoid having the connections on a level carry- tests according to the current state of ing water. technology. ¼ Ensure that the substructure is on ground ¼ Protect the cabling from dirt and wet. potential (R ≤ 10 Ohm). InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE GEnERatIon G1.4... -
Page 17: Grounding
¼ negative generator poles should be grounded with an ground- ing kit recommended by the inverter manufacturer. F ollow the specifications of the inverter manufacturer. ¼ InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... -
Page 18: Cleaning And Maintenance
10 °c and 30 °c, e.g. in the early morning or late evening. Do not wear electrically conductive parts. Don’t clean damaged Remove soiling from the substructure ¼ modules. This can cause an electric shock. (leaves, bird nests etc.). InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE GEnERatIon G1.4... -
Page 19: Faults
(not insulated), 14 AWG (min. 2.5 mm²). I n order to fulfil the requirements in accordance with the Ca- ƒ nadian Standard uLc/oRD-c1703-1, the installation must be carried out in accordance with cSA-c22.1, Safety standard for electrical installations, canadian Electrical code, Part 1. InstallatIon and oPERatIon ManUal FoR sl2 solaR ModUlEs oF tHE G1.4 GEnERatIon... - Page 20 SOLIBRO GMBH OT Thalheim, Sonnenallee 32–36 EMAIL service@solibro-solar.com www.solibro-solar.com 06766 Bitterfeld-Wolfen, Germany...
