Kappa WST-916 Operation Manual

One gang wireless wall switch with built in timer

Advertisement

Quick Links

Operation Manual
Model:
One gang wireless wall switch with built in timer.
Item No.: WST-916

Overview:

Eco friendly one gang wireless wall switch with built in 'OFF' timer.
Nor just simple manual ON / OFF / Dim functions, it comes with additional 7 selection of delay 'OFF' time.
5s / 30s / 5m / 10m / 30m / 1hr / 3hrs
Easy installations with either screw fix into current wall box or affix any location with adhesive tape.

Installation

1. Screw base into wall or wall box.
2. Affix frame onto base.
3. Affix rocker onto frame.

Pairing

Pairing using LEARNING MODE:
1. First choose the desired receiver(s) that you wish to control.
2. Press the 'Learn' button once (LED will flash), this will now enter learning mode.
3. On the wall switch press the 'ON' button; the load will flash twice to confirm that the wall switch is now paired.
! If pairing with CFR-2022 & CFR-2027, the rotary dialer must first be positioned in '0' in order to function correctly.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WST-916 and is the answer not in the manual?

Questions and answers

Danny
July 14, 2025

Where is the learn button

Summary of Contents for Kappa WST-916

  • Page 1 Operation Manual Model: One gang wireless wall switch with built in timer. Item No.: WST-916 Overview: Eco friendly one gang wireless wall switch with built in ‘OFF’ timer. Nor just simple manual ON / OFF / Dim functions, it comes with additional 7 selection of delay ‘OFF’ time.
  • Page 2 NOTE: Learning mode lasts for 12 seconds; if no signal is given to the receiver then it will automatically exit learning mode without pairing the device. To exit learning mode manually, simply press the ‘Learn’ button again. !If, during learning mode the load does not flash to confirm, this means that the receiver’s memory is FULL and no further remote control may be paired unless one of the existing remote control is first unpaired (see below).
  • Page 3 1. Switch ‘ON’ the living room load (light). 2. Timer will start the countdown until it reaches 3 hours. 3. After 3 hours, wall switch will automatically send an ‘OFF’ signal to the load (light). NOTE: During countdown interval for ON/OFF receiver(s) if; ‘ON’...
  • Page 4 ON again the load (light) will return to the previous stipulated brightness. Battery Replacement 3V CR2032 lithium battery is included. When the battery voltage is low, the transmission range will be reduced accordingly. Press the battery holder. Remove battery. Replace fresh battery making sure ‘+’ positive terminal is facing up Push battery firmly into battery compartment.
