- Page 1 LDK 4019 LDK 4019 LDK 4019 LDK 4019 LDK 4019 7-inch HDTV Viewfinder 3922 496 48891 St.01...
-
Page 2: Declaration Of Conformity
Declaration of Conformity We, Thomson Broadcast Solutions Nederland B.V., Kapittelweg 10, 4827 HG Breda, The Netherlands declare under our sole responsibility that this product is in compliance with the following standards: EN60065 : Safety EN55103-1 : EMC (Emission) EN55103-2 : EMC (Immunity) following the provisions of: a. - Page 3 LDK 4019/00 7-inch HDTV Viewfinder User's Guide Contents About This Manual ..........1-2 Viewfinder Connector ......... 1-8 Installation ............1-3 Dimensions ............1-9 Operation ............1-4 Specifications ..........1-10 02.34.5 User's Guide LDK 4019/00 - 7-inch HDTV Viewfinder...
-
Page 4: About This Manual
The first line detection and repair of faults If the unit is being returned to Thomson Multimedia requires a general knowledge of test and measurement Broadcast Solutions for servicing, try to use the techniques. - Page 5 Installation Viewfinder Hood Support Slots Hood Support Knobs Viewfinder Locking Levers Viewfinder Hood Locking Knobs The 7-inch HDTV viewfinder LDK 4019/00 is intended b. Push both locking levers inwards and slide the for use with the LDK6000 HDTV camera equipped. viewfinder until it firmly engages the connector.
- Page 6 Operation 7-inch Viewfinder Red On-air Lamps Power Switch These two red tally lamps on either side of the back This switch is used to switch the power supply to the of the viewfinder light when the camera picture is on- viewfinder on and off.
- Page 7 Front View LED's Call LED ISO LED This green LED lights to attract the cameraman's This yellow LED lights to indicate that the camera attention. signal is being used though not necessarily on-air. On-air LEDs These red LEDs light to indicate that the camera is on-air.
- Page 8 Front View Switches Brightness Control Cursor Frame Selection Controls the brightness of the viewfinder display. Selects the cursor frame mode for display on the viewfinder: Deactivated Aperture Correction Control Lines This control varies the amount of aperture correction applied to the viewfinder signal when the aperture Deactivated correction switch is in the ON position.
- Page 9 Positioning the Viewfinder Transport Lock Lever Hood Lock Levers Unlocking Locking To swing out viewfinder Locking the viewfinder a. Unlock the transport lock lever. a. Rotate the two unlocking knobs marked FIXED/ FREE simultaneously in FREE direction and push b. Turn both unlocking knobs marked FIXED/FREE the back of the viewfinder down all the way.
- Page 10 Viewfinder Connector Video Video R-Y Video B-Y +12 V return Shield +12 V Video ground Video ground R-Y / B-Y +12 V +12 V return Shield On-air lamp +12V = on / 0V = off 15-pin male D-connector User's Guide LDK 4019/00 - 7-inch HDTV Viewfinder 02.34.5...
- Page 11 Dimensions 192mm 272mm 441mm 306mm 02.34.5 User's Guide LDK 4019/00 - 7-inch HDTV Viewfinder...
-
Page 12: Specifications
Specifications Systems 1920x1080i60, 1920x1080i50 1280x720p60, 1280x720p50 automatic switching aspect ratio 16:9 Power Supply +10.5 Vdc to +17Vdc Power Consumption Max: 24W Aperture Switchable, boost at 12.5MHz with 6dB Video input signal Nom. 1Vpp (+6dB/-3dB) VBS Input impedance 75 Ohm ±5% Environmental conditions: Operating temp.: -20 to +45 °C...
