Overview The Power over Ethernet Splitter split data and power out, and output Ethernet data and DC power to the network device that is not compliant with IEEE802.3af standard. The network device can accept the power and Ethernet data from the Splitter The following figure shows the how Power over Ethernet Splitter work.
Page 4
2 power cable with straight plug and a right angle plug Power jack diameter Plug dimension: 5.5 x 2.0mm, 5.5 x 2.5mm 4-Segment switch for output voltage Adjust Switch selection Data and power in: 1 x RJ-45.Data pin 1,2,3,6 Power pin: 4,5(V+), 7,8(V-) and 1,2(V+), 3,6(V-) Connector Data out: 1 x RJ-45, Data pin 1,2,3,6...
outside plant. Hardware Description The Power over Ethernet Splitter has three connection ports, one LED indicator, and Dipswitch for voltage adjusting. We will description each in following. Data In port: It is a RJ-45 Ethernet interface port for data transmit to the PoE Splitter.
System power LED indicator DIPswitch: It uses for switching the voltage to PD. It provides four-voltage value – 5V, 7.5V, 9V and 12V. The default is 5V. When you adjust the Dipswitch, please power off the Power over Ethernet Splitter.
Installation To install the Power over Ethernet Splitter, please follow the below steps. 1. Using RJ-45 cable to connect the Data in port on the Power over Ethernet Splitter with the PoE Switch/HUB (which is Data out port). If the Switch/HUB does not support PoE function, you need to install a PoE injector between Switch/HUB and Power over Ethernet Splitter.
