General Safety and Maintenance Manual
Model
Number
65VL
65VS
The henry Tool Co., ManufaCTured by henry Tools
498 so. belvoir blvd., souTh euClid, oh 44121 u.s.a.
Ph: (216) 291-1011 or (800) 826-5257 ● Fax: (216) 291-5949 or (800) 303-2800
Email: daviidh@msn.com ● WEbsitE: WWW.hEnrytools.com
4 HORSEPOWER
SUPER HEAVY DUTY VERTICAL GRINDERS
4 HORSEPOWER
Throttle
Power
Weight
Type
Output
LEVER
4 H.P.
(3000 W)
11.0 Lbs.
SAFETY
(5.0 Kg)
LEVER
4 Horsepower Vertical Grinders
Height over
Air
Spindle
Consump-
tion
50 cfm
4500 RPM w/ 9 Inch T27 Wheel Guard
(23.6 L/s)
4500 RPM w/ 9 Inch T28 Wheel Guard
6000 RPM w/ 7 Inch T27 Wheel Guard
6000 RPM w/ 7 Inch T28 Wheel Guard
7.7 Inches
6000 RPM w/ 9 Inch T27 Wheel Guard
(196 cm)
6000 RPM w/ 9 Inch T28 Wheel Guard
8000 RPM w/ 7 Inch T27 Wheel Guard
8000 RPM w/ 7 Inch T28 Wheel Guard
(NOTE: Standard RPM is 6000RPM)
MODELS
65 VL
65 VS
Rated Speed/Wheel Capacity
