General Safety and Maintenance Manual
Model
Exhaust
Number
Direction
49 RA
49 RAZ
REAR
49 RAC
The henry Tool Co., ManufaCTured by henry Tools
498 so. belvoir blvd., souTh euClid, oh 44121 u.s.a.
Ph: (216) 291-1011 or (800) 826-5257 ● Fax: (216) 291-5949 or (800) 303-2800
Email: daviidh@msn.com ● WEbsitE: WWW.hEnrytools.com
REAR EXHAUST RIGHT ANGLE GRINDER
MODEL 49 RA grinder featuring a rear exhaust.
Throttle
Speed
Power
Type
Output
12000
(L) Lever
to 14000
or
0.9 H.P.
R.P.M
(K) Safety
(675 W)
(13500rpm is
Lever
standard)
Case
Weight
Length
Material
Aluminum
Alumi-
2 1/2 lbs
8 5/16"-
num
1.1kg
211mm
MODELS
49 RA
49 RAZ
49 RAC
Air
Spindle
Diameter
Consumption
Thread
3/8-24 x 0.98
Inch
5/8-11 x 0.98
1 3/4"
25 CFM
Inch (25mm)
4.4cm
(11.8 L/S)
1/4 Inch Burrs/
Mounted
Points
