INSTALLATION MANUAL AND USERS GUIDE
Single Split Series – Ductless Split System Heatpump
SWM - Single Split Series
R-410A Ultra High Efficiency Ductless Heat Pump
2,6 – 7 kw Capacity
Sedna Aire now offers ductless single split heat pumps that use the more efficient and
environmentally friendly refrigerant (R-410A). The ductless system allows very easy
integration into existing surroundings without major investment in ducts or radiators. It
contains one outdoor and one indoor unit and is especially dedicated to straight forward
applications where only one indoor unit is needed.
The new SWM Series of Sedna Aire heat pumps offers outstanding performance as well
as environmental protection. These models with their high efficient compressors in DC-
TM
Inverter technology offer when matched with our Solarcool
panel efficiency rates 2-3
times better than current comparables best-in class systems: EER: 8 (Cooling) and COP:
8 (Heating).
TM
SolarCool
... The Hotter it Gets, The Better It Works!
04005020101
© Sedna Aire Europe GmbH
1
12/2012
Advertisement
Table of Contents
Related Manuals for Sedna Aire Solar Cool SWM Single
Summary of Contents for Sedna Aire Solar Cool SWM Single
- Page 1 R-410A Ultra High Efficiency Ductless Heat Pump 2,6 – 7 kw Capacity Sedna Aire now offers ductless single split heat pumps that use the more efficient and environmentally friendly refrigerant (R-410A). The ductless system allows very easy integration into existing surroundings without major investment in ducts or radiators. It contains one outdoor and one indoor unit and is especially dedicated to straight forward applications where only one indoor unit is needed.
-
Page 2: Table Of Contents
The installation and especially the connection between the outdoor unit and the Solarpanel shall be only performed by trained and skilled service personnel having the appropriate instruments. Sedna Aire does not take over any responsibility for direct and indirect damages causing from installation by unskilled and/or untrained persons. -
Page 3: Name And Descriptions Of The Parts
1. NAME AND DESCRIPTION OF THE PARTS Setting Display Indoor unit Air intake Air outlet Surface panel Louver Remote Control Drain hose Outdoor unit Air intake Refrigerant pipe and connecting wire Condenser fan Air outlet 04005020101 © Sedna Aire Europe GmbH 12/2012... -
Page 4: Instructions Before Installation And Use
1 m away from the It can decrease the air on it. Falling off the outdoor units. conditioning capacity or a unit may cause damage to It may cause fire or malfunction you and somebody else explosion 04005020101 © Sedna Aire Europe GmbH 12/2012... - Page 5 It destroy the air guidance like, drying clothes, food, and unit. etc. It may overheat and the unit may be damaged. 04005020101 © Sedna Aire Europe GmbH 12/2012...
-
Page 6: Remote Control Description And Manual
If locked, is displayed. When you press Air Function: any button, blinks 3 times Press to turn on or off °F ↔ °C: Switch unit off and press simultaneously MODE and “-“ 04005020101 © Sedna Aire Europe GmbH 12/2012... -
Page 7: Battery Change
Press the TIMER button to set a predefined start and Stop time, for example when you are not around and want to get it started half an hour before you return Note: In the AUTO mode the unit will automatically adjust its running mode according to the room temperature. 04005020101 © Sedna Aire Europe GmbH 12/2012... - Page 8 Dehumidify mode: Room temperature below 18°C lf the unit is running for long time in the cool or humidify mode with relative humidity higher than 80% (door and windows are open), dew might drop near the air outlet. 04005020101 © Sedna Aire Europe GmbH 12/2012...
-
Page 9: Care And Maintenance
40 °C, then dry it and wipe off the dirty spots. NOTE: The indoor units contains microcomputer components and circuit board in the display which are very sensitive against water. So don’t put any water into the interior of the indoor unit. 04005020101 © Sedna Aire Europe GmbH 12/2012... - Page 10 Check whether the batteries in your remote control are still operational Check if the outdoor unit is standing firm on its base or rack. If not, contact your service center. 04005020101 © Sedna Aire Europe GmbH 12/2012...
-
Page 11: Trouble Shooting
Is the remote control too far away from indoor unit or blocked by any obstacles? Check the battery in remote controller for power Ievel. lf low power, replace the battery. Check, if remote controller is damaged. 04005020101 © Sedna Aire Europe GmbH 12/2012... - Page 12 Air break switch or leakage protection switch trips STOP THE AIR CONDITIONER AND frequently. PULL OUT THE POWER PLUG Liquids or water are poured into the machine or remote controller. Abnormal overheating of power cord and plug. 04005020101 © Sedna Aire Europe GmbH 12/2012...
-
Page 13: Location Of Installation
Right side: min. 50 cm to any wall Top: min. 50 cm to any cover Front: min. 200 cm to any wall or greater obstacle Back: min. 30 cm to any wall 04005020101 © Sedna Aire Europe GmbH 12/2012... -
Page 14: Electrical Wiring
OUTROOM: Ambient temperature outside RD: Red EXHAUST: Outlet of the air YE/GN: Yellow/Green STEP MOTOR: POWER: DISPLAY: FAN MOTOR: TRANSFORMER: INDOOR UNIT: MAIN: Main board COMP: Compressor PUMP: Condensate pump indoor unit TEM: Temperature 04005020101 © Sedna Aire Europe GmbH 12/2012... - Page 15 INSTALLATION MANUAL AND USERS GUIDE Single Split Series – Ductless Split System Heatpump SWM 09, 12 - 200-230V 04005020101 © Sedna Aire Europe GmbH 12/2012...
- Page 16 INSTALLATION MANUAL AND USERS GUIDE Single Split Series – Ductless Split System Heatpump SWM 18 - 200-230V 04005020101 © Sedna Aire Europe GmbH 12/2012...
- Page 17 INSTALLATION MANUAL AND USERS GUIDE Single Split Series – Ductless Split System Heatpump SWM 24 - 200-230V 04005020101 © Sedna Aire Europe GmbH 12/2012...
-
Page 18: Installation Of The Indoor Unit
Insulating tube Connected Bulge Distortion Pay attention to avoid twists, ridges and distortion of the drainage pipe in the Iayout and not to immerse the outlet in water. Flooded 04005020101 © Sedna Aire Europe GmbH 12/2012... - Page 19 Hung the claws at the rear side of the indoor unit to the hook on the wall- Power cord mounting frame. Move the unit left and right to see if it is steady. The installation height of the indoor unit must be at least 2,0 m. Drainage hose 04005020101 © Sedna Aire Europe GmbH 12/2012...
-
Page 20: Installation Of The Outdoor Unit
Mount the outdoor unit with heavy and suited bolts on to the ground or an appropriate rack. Perpendicular ground plates provide four holes for mounting. Make sure that the outdoor unit is assembled safe and may withstand vibrations, major wind and other weather forces. 04005020101 © Sedna Aire Europe GmbH 12/2012... -
Page 21: Air Purge And Leakage Test
Ø 16 - 5/8” or Ø 19- 3/4” Ø 12- 1/2” Ø 19 - 3/4” or Ø 22- 7/8” Ø 16- 5/8” Ø 25,4- 1” or Ø 31,8- 1 1/4” Ø 19- 3/4” Ø 22- 7/8” 04005020101 © Sedna Aire Europe GmbH 12/2012... -
Page 22: Test Operation
Have the length of refrigerating pipe and The wrong amount of refrigerant has be installed refrigerant charge amount been recorded? and causes insufficient cooling and heating 04005020101 © Sedna Aire Europe GmbH 12/2012... -
Page 23: Warranty
Limited warranty by Sedna Aire Europe Valid is the warranty claim as published on the Homepage of Sedna Aire Europe at the time of purchase date. Sedna Aire hereby warrants to the consumer that all units are free from defects in materials and workmanship, and will replace or repair system components in accordance with the terms of this Limited Warranty.
